Specifications - Alpine CDA-117 Owner's Manual

Specifications

FM TUNER SECTION
Tuning Range
Mono Usable Sensitivity
50 dB Quieting Sensitivity
Alternate Channel Selectivity
Signal-to-Noise Ratio
Stereo Separation
Capture Ratio
AM TUNER SECTION
Tuning Range
Sensitivity (IEC Standard)
CD PLAYER SECTION
Frequency Response
Wow & Flutter (% WRMS)
Total Harmonic Distortion
Dynamic Range
Signal-to-Noise Ratio
Channel Separation
USB SECTION
USB requirements
Max. Power Consumption
USB Class
File System
MP3 Decoding
WMA Decoding
AAC Decoding
Number of Channels
*
Frequency Response
Total Harmonic Distortion
Dynamic Range
Signal-to-Noise Ratio
Channel Separation
Frequency response may differ depending on the encoder software/bit
rate.
PICKUP
Wave length
Laser power
REMOTE CONTROL
Battery Type
Width
Height
Depth
Weight
GENERAL
Power Requirement
Power Output
Maximum Pre-Output Voltage
Weight
Primary amplifier ratings per CEA-2006 Standard
• Power output: measured at 4 Ohms and ≤ 1% THD+N
• S/N: 80 dBA (reference: 1 W into 4 Ohms)
48
-EN
87.7-107.9 MHz
9.3 dBf (0.8 μV/75 ohms)
13.5 dBf (1.3 μV/75 ohms)
80 dB
65 dB
35 dB
2.0 dB
530-1,710 kHz
22.5 μV/27 dB
5-20,000 Hz (±1 dB)
Below measurable limits
0.008% (at 1 kHz)
95 dB (at 1 kHz)
105 dB
85 dB (at 1 kHz)
USB 1.1/2.0
500 mA
Mass Storage
FAT 12/16/32
MPEG-1/2 AUDIO Layer-3
Windows Media™ Audio
AAC-LC format ".m4a" file
2-Channel (Stereo)
5-20,000 Hz (±1 dB)
0.008% (at 1 kHz)
95 dB (at 1 kHz)
105 dB
85 dB (at 1 kHz)
795 nm
CLASS I
AAA batteries (2 pcs.)
42 mm (1-21/32")
121 mm (4-25/32")
23 mm (29/32")
50 g (1.8 oz)
14.4 V DC
(11-16 V allowable)
*
18 W RMS × 4
4 V/10 k ohms
1.6 kg (3 lbs. 8 oz)
CHASSIS SIZE
Width
Height
Depth
NOSEPIECE SIZE
Width
Height
Depth
Note
• Due to continuous product improvement, specifications and design are
subject to change without notice.
178 mm (7")
50 mm (2")
160 mm (6-1/4")
170 mm (6-3/4")
46 mm (1-13/16")
23 mm (15/16")
