Edit mode

Edit mode
In Edit mode you can make detailed settings for each
effect, and modify the program name.
Press the EDIT/EXIT key and the LCD will indi-
cate " " showing that the AX1G is in Edit mode.
Press the EDIT/EXIT key once again and you will re-
turn to Play mode. You can edit the on/off setting of
each effect, and its parameters. When you edit a pro-
gram, the "." (decimal point) of the PROGRAM/NOTE
display will light.
lit in Edit mode
lit when you edit a Program
Edited programs will be lost if you change programs
or turn the power off before writing the edited pro-
gram. While editing, be sure to write your changes
frequently. For the Write procedure, refer to p.16
"WRITE".
It is not possible to switch modes when the unit
is bypassed (or muted). Defeat bypass (or
mute), and then switch the mode.
If you bypass (or mute) the AX1G in Edit mode,
it is not possible to perform editing operations.
Defeat bypass (or mute) before you continue
editing.

1. Selecting the parameter to edit

• Use the PAGE [√] or [®] key to select the
parameter that you wish to edit.
You can select effects and other parameter in
the order shown by the diagram below.
The currently selected effect display will blink.
Effects which are turned off cannot be edited. To
edit an effect which is turned off, use the PAGE
[√] or [®] key to select the effect, and then press
the ENTER key to turn on the effect.

2. Editing effect parameters

To edit a program, you can select an effect type Drive,
Tone, Modulation, Pedal, or Ambiance, and modify
the value of the parameter assigned to each effect
type.
For the type of effects which can be selected and the
available values of the parameters, refer to the Effect
Parameter table (
14
p.50).

DRIVE

This provides effects which process the tonal char-
acter, such as compressor, overdrive, and distortion.
ENTER key: Turn the effect on/off (the type name
is displayed when on, and "OFF" when
off)
TYPE [√]/[®] keys: Select the effect type
VALUE [-]/[+] keys: Specify the value of the param-
eter assigned to each effect
type (

TONE

This provides effects which adjust the tonal character.
ENTER key: Turn the effect on/off (the type name
is displayed when on, and "OFF" when
off)
TYPE[√]/[®] keys: Switch between LOW G (low
range gain), MID FC (mid
range frequency), MID G
(mid range gain), and HIGH
G (high range gain)
VALUE[-]/[+] keys: Set the frequency or gain ( p.
50)
Depending on the settings, the output sound
may distort (clip). If this occurs, adjust the level
( p.15 "LEVEL") so that the sound does not
distort.

MOD

This provides modulation-type effects such as cho-
rus, flanger, and phaser.
ENTER key: Turn the effect on/off (the type name
is displayed when on, and "OFF" when
off)
TYPE [√]/[®] keys: Select the effect type
VALUE [-]/[+] keys: Specify the value of the param-
eter assigned to each effect
type (
p.50)
p.51–52)
