Systemwide Options - AT&T MERLIN Plus Release 1 Customization Chart

BASIC ADMINISTRATION
NUMBER OF OUTSIDE LINES
DIAL 4
DIAL one digit for the number of lines (1–8)
TOUCH Administer
DIAL SIGNALS
38 Touch-Tone (F‡)
DIAL
39 Rotary
TOUCH Administer
LONG DISTANCE DIALING
36 Toll prefix (0 or 1) needed (F)
DIAL
37 Area code only needed
TOUCH Administer
TRANSFER RETURN INTERVAL
DIAL 2
DIAL one digit for the number of rings before
a transferred call returns to the attendant
(0–9) (F= 4 rings)
TOUCH Administer
GROUP PAGING
71 Group 1 (voice terminals
DIAL
10–19) (F)
72 Group 2 (voice terminals
20–29) (F)
TOUCH Auto Intercom button (or dial
appropriate code from dial code chart)
Green light on = telephone assigned
Green lighf off = telephone removed
(or TOUCH Drop to remove all telephones
from a paging group)
TOUCH Administer
CALL REPORT AND SYSTEM
FEATURE REPORT
DIAL
82 Call Reports (SMDR)
85 System Feature Report
TOUCH Auto Intercom button (or dial
intercom number) of jack (F = jack 19)
Green light on = jack assigned
Green light off = jack not assigned
TOUCH Administer
† If you are using a 10-button voice terminal for
administration, dial #01 in place of touching
Administer when following these procedures.
‡ F=Factory setting.
AT VOICE TERMINAL 10
TO ENTER ADMINISTRATION MODE: SLIDE the T/P switch to P
TO LEAVE ADMINISTRATION MODE: SLIDE the T/P switch to center position
LINE ADMINISTRATION
ASSIGN LINES TO A VOICE TERMINAL
TOUCH Auto Intercom button (or dial intercom
number)
TOUCH line buttons
Green light on = line assigned
Green light off = line not assigned
TOUCH Administer
BUTTON - FREE LINE OPERATION
TOUCH Auto Intercom button (or dial intercom
number)
TOUCH line buttons
Green light on = line assigned
Green light off = line not assigned
(or DIAL 34 to reassign lines to
separate buttons)
31 Incoming calls ring
DIAL
32 Incoming calls don't ring
TOUCH Administer
TOUCH Administer or dial #01†

SYSTEMWIDE OPTIONS

ALLOWED LIST ENTRIES
DIAL three-digit list code ( 01– 08)
DIAL two-digit item number (01–10)
To add an entry:
DIAL the allowed number (up to six digits)
TOUCH Administer
To remove an entry:
TOUCH Drop
TOUCH Administer
ASSIGN CALL RESTRICTIONS
TOUCH Auto Intercom button (or dial intercom
number)
TOUCH Restrict until:
Green light on steady = Unrestricted
(all calls)
Green light flashing = Toll Restricted (no
long distance calls)
Green light off = Outward Restricted
(no outside calls)
TOUCH Administer
ASSIGN ALLOWED/DISALLOWED LISTS
DIAL three-digit list code:
01– 08 Allowed list codes
DIAL 00
TOUCH Auto Intercom button (or dial
appropriate code from dial code chart)
Green light on = list assigned
Green light off = list not assigned
TOUCH Administer
SYSTEM SPEED DIAL
DIAL code (#60—#99)
88 Account code assignment
92 Restriction override
DIAL
90 No restriction override
DIAL to make the number private
DIAL Telephone number
Account number
TOUCH Administer
MUSIC VOLUME
MUSIC-ON-HOLD VOLUME
12 Off
13 Low
DIAL
14 Medium (F)
15 High
TOUCH Administer
BACKGROUND MUSIC VOLUME
16 Off
17 Low
DIAL
18 Medium (F)
19 High
TOUCH Administer
