AT&T MERLIN LEGEND Pocket Reference page 12

Hardware and Software Parameters
Item
Callback calls in queue
Calling Groups
Number of groups
Members per group*
Groups per member
Delay announcements per system
Delay announcements per group
Groups per delay announcement
External alerts per group
Coverage groups per group
Carriers
Slots per basic carrier
Slots per expansion carrier
Carriers per system
Total slots available
Coverage Groups
Number of groups
Senders per group
Groups per sender
Receiver buttons per group
Groups per QCC receiver
* QCCs cannot be members.
† The processor module must be placed in slot 00 in the basic
carrier.
‡ Software limits on the number of lines/trunks and stations
usually limit the number of carriers in a small system to 2 and
therefore the number of slots to 11.
§ For Hybrid/PBX systems, when queued call consoles (QCCs)
are used, the queue can also be assigned as a receiver but is
not counted in the 8-receiver maximum.
Page 8
†
§
(continued)
Large
Small
64
64
32
32
20 20
1 1
32
32
1 1
32
32
1 1
1 1
5
5
6
6
3
3
1 7 ‡
17
32
32
144
56
1 1
8 8
30 30
