DK3000 and PDK3000 - Installation Instructions
DK3000 Remote
Access Controller
PDK3000 Remote
Access Controller
with PROX
WALL INSTALLATION
1. Use Mounting Plate as a
template to trace and drill
four 7/32" diameter holes
for wall anchors and 1"
hole for wires.
GANG BOX INSTALLATION
A. Pull all existing wires
through wall Gang
Box and Mounting
Plate.
ALARM LOCK SYSTEMS, INC. is a division of the NAPCO Security Group
345 Bayview Avenue, Amityville, New York 11701 (631) 789-4871 1-800-252-5625 Fax: (631) 789-3383
©
2. Pull all existing
3. Position Mounting Plate and
wires through
fasten with four wall anchor
wall and Mount-
screws. Connect wires as
ing Plate.
necessary using wire nuts
supplied. Push wires inside.
Lip
Mounting Plate
Screw tab
B. Position Mounting
Plate and fasten with
two flathead screws
TECH SUPPORT: 1-800-ALA-LOCK
4. Position unit so that the
5. Press unit flush with
Short Plate can be placed
Mounting Plate and pull
over the lip on the Mount-
down. Fasten with screw.
ing Plate.
Short
Plate
Lip
Screw
tab must
be inside
Part No. WI 1130A 5/03
