A16697-R0-Ei129-UC-ENG
Alarm Trigger Module
Connects to Sprinkler & EN54 Fire Systems (24V)
Instruction Manual
Contains vital information on the product's operation and
installation. Read and retain carefully. If you are just installing
this product the manual MUST be given to the householder.
The Ei129 is designed to sound interconnected Ei Electronics
Mains Powered Alarms to give a fire warning. When the
external normally open contacts connected to it, close.
Its main applications are:
1. To trigger the Smoke/Heat/Fire Alarms to sound when a
Sprinkler System is activated.
2. To trigger all the Smoke/Heat/Fire Alarms in an apartment
to sound when the EN54 Fire System in the common areas
of the HMO* sense fire. This greatly increases the alarm
sound level throughout the apartment (this helps meet the
recommendations of the BS5839-6: 2004 Clause 13.2e)
which requires 85dB(A) at each bedroom doorway. (It can
also help meet the recommendations of Clause 13.2f) of
75dB(A) at each bed head where the fire risk assessment
warrants it).
* HMO - House in Multiple Occupancy
2. Installation Instruction
2.1 Installation of Ei129 under Ei Electronics Easi-Fit Alarms.
WARNING: Mains powered Alarm Trigger Modules should be
installed by a qualified electrician in accordance with the
regulations for Electrical Installations published by the
Institution of Electrical Engineers (UK) (i.e. BS7671). Failure
to install the unit correctly may expose the user to shock or fire
hazards. This unit is not waterproof and must not be exposed
to dripping or splashing.
WARNING: First disconnect the mains from the circuit to be
used.
2.1.1 Choose a mounting position following the siting
instructions in the Smoke/Heat/Fire Alarm leaflet. Bring the
wiring from the external N/O contacts to this position. (With
an EN54 System an Input/Output Module is required and with
a Sprinkler System Changeover contacts should be specified
when it is being installed).
28/7/09
2:30 PM
Model: Ei129
230V~ with
Battery Backup
1. Introduction
1
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ei Electronics EI129
Summary of Contents for Ei Electronics EI129
- Page 1 Read and retain carefully. If you are just installing this product the manual MUST be given to the householder. 1. Introduction The Ei129 is designed to sound interconnected Ei Electronics Mains Powered Alarms to give a fire warning. When the external normally open contacts connected to it, close.
- Page 2 A16697-R0-Ei129-UC-ENG 28/7/09 2:30 PM Page 2 Caution: The N/O contacts in the external device connected to the Ei129, must be electrically isolated and rated for 230V~. 2.1.2 Where the incoming wiring is on the surface of the ceiling, the appropriately sized ducting/conduit must be chosen to mate with the unit.
- Page 3 A16697-R0-Ei129-UC-ENG 28/7/09 2:30 PM Page 3 2.1.5 Connect the two wires from the external N/O contacts to the “Contacts In” terminals. 2.1.6 Connect the three short wires (“L” Brown, “N” Blue and “IC White) from the Ei129 Module to the connector block on the Smoke/Heat/Fire Alarm Easi-Fit Mounting Plate.
- Page 4 Base was purchased and date of purchase. 5. Five Year Guarantee Ei Electronics, guarantees the Ei129 Module for five years from date of purchase against any defects that are due to faulty materials or workmanship. This guarantee only applies...
- Page 5 Aico Ltd Mile End Business Park, Maesbury Road, Oswestry, Shropshire SY10 8NN, U.K. Telephone: 0870 7584000 www.aico.co.uk Ei Electronics Shannon Industrial Estate, Shannon, Co. Clare, Ireland. www.eielectronics.com...
-
Page 6: Technical Specifications
C to 40 Humidity Range: 0% to 95% R.H. Dimensions: 141mm (dia) x 25mm (height) Weight: 160g Guarantee: 5 year (limited) Electrical Safety: Complies with BSEN60065: 2002 (Tested by BSI) Approvals: CE Marked P/N A16697 Rev0 © Ei Electronics 2009...
