IMPORTANT NOTICE
WHEN THE BATTERY IS
FIRST CONNECTED THE
ALARM MAY SOUND FOR
2-3 SECONDS.
THIS IS NORMAL.
IT MEANS THE BATTERY IS
CONNECTED CORRECTLY.
© Ei Electronics 2013
Ei100B
Standard Alarm
Ei100L
Emergency Light
INSTRUCTION LEAFLET (for all Models)
Contains vital information on unit operation and installation.
Read and retain carefully. If you are just installing this unit this
leaflet MUST be given to the householder.
www.acornfiresecurity.com
SMOKE ALARMS
9 VOLT IONISATION
Models
Ei100S
Ei100C
1
P/N B10277 Rev14
Silencer
Interconnect
Advertisement
Related Manuals for Ei Electronics Ei100BNX
Summary of Contents for Ei Electronics Ei100BNX
- Page 1 WHEN THE BATTERY IS FIRST CONNECTED THE ALARM MAY SOUND FOR 2-3 SECONDS. THIS IS NORMAL. IT MEANS THE BATTERY IS CONNECTED CORRECTLY. © Ei Electronics 2013 P/N B10277 Rev14 SMOKE ALARMS 9 VOLT IONISATION Models Ei100B Ei100S Standard Alarm...
- Page 2 www.acornfiresecurity.com Basic information about your Smoke Alarm A Smoke Alarm is an early warning device. Used correctly it can give you and your family valuable extra time to escape. Note:- • When the battery is first connected the Alarm may sound for 2-3 seconds - this is normal. • A Smoke Alarm does not prevent fires. • Install correctly, in the centre of the ceiling if possible.
- Page 3 www.acornfiresecurity.com Bedroom Kitchen Dining Bedroom Bedroom Figure 1: Single storey Dwelling Bedroom Dining Kitchen Recreation Living Bedroom Bedroom Figure 2: Single storey Dwelling with separate sleeping areas Figure 3: Two Storey Dwelling Recommended protection, Figure 1,2, & 3 Minimum protection • each storey • each sleeping area • every 7.5 metres (25ft) of hallways and rooms...
-
Page 4: Positioning Your Smoke Alarm
www.acornfiresecurity.com This is because an upstairs smoke alarm is unlikely to detect a fire on lower floors in sufficient time to ensure an adequate escape. (c) Maximum Protection. For maximum protection you should put individual Smoke Alarms in all the rooms where fire is most likely to break out (apart from the locations to avoid, mentioned on page 5). The living room is the most likely place for a fire to start at night, followed by the kitchen and then the dining room. - Page 5 www.acornfiresecurity.com (b) Wall Mounting. When a ceiling position is not practical (for example on a ceiling having exposed beams or joists, or built-in radiant heating) put the top edge of your Smoke Alarm between 15 and 30 cm (6 and 12 inches) below the ceiling. Keep at least 15cm (6 inches) from corners.
- Page 6 www.acornfiresecurity.com Installing your Smoke Alarm (a) Attaching to Ceiling or Wall. (NB: for wiring the Ei100C Interconnect model see page 9) The Smoke Alarm is battery operated and needs no wiring, (Ei100C excepted). Use figure 6 below, as a help in mounting.
- Page 7 www.acornfiresecurity.com Figure 7 9 Volt Battery Battery Connectors NOTE: You may hear a loud chirp when attaching the Battery Connectors to the Battery. N.B. The emergency light Smoke Alarm needs 2 batteries (see page 9 for details). Test the installed Smoke Alarm - see section 5(a) below. (c) Battery Missing Indicator All models are fitted with a warning flag which pops up when the battery is removed.
- Page 8 www.acornfiresecurity.com WARNING: DO NOT TEST WITH FLAME. This can set fire to the Alarm and damage the house. We do not recommend testing with smoke or heat as the results can be misleading unless special apparatus is used. (b) Replacing the Battery(ies) Test the alarm for correct operation using the test button whenever the battery(ies) is/are replaced.
- Page 9 www.acornfiresecurity.com batteries, an alkaline battery and a general purpose battery. 1. Connect an alkaline battery (use only Duracell MN1604 or Eveready 522) to the blue battery connector to power the light. This battery when fresh will normally last 1 year in the stand by mode and provide over 15 minutes of light when in alarm.
-
Page 10: Important Safeguards
www.acornfiresecurity.com After wiring together the Interconnect Smoke Alarms, test the first unit by pressing the button. All the detectors should alarm and the test button on the first unit will flash about once every 2 seconds. Check all the other units similarly. When interconnected units are in alarm, the red flashing light indicates the unit sensing smoke. These Smoke Alarms should be interconnected only within the confines of a single family living unit. - Page 11 www.acornfiresecurity.com • When removing battery, handle carefully to avoid possible eye damage or skin irritation if battery has leaked or corroded. • To maintain sensitivity to smoke, do not paint or cover smoke alarm in any manner; do not permit any accumulation of cobwebs, dust or grease. • The chamber located in the center of the Smoke Alarm contains a small amount of radioactive material.
- Page 12 www.acornfiresecurity.com Planning your Escape for when the Alarm goes off Use the Smoke Alarm Test Button to familiarize your family with the Alarm sound and to practice fire drills regularly with all family members. Draw up a floor plan that will show each member at least 2 escape routes from each room in the house. Children tend to hide when they don’t know what to do. Teach children how to escape, open windows, and use roll...
-
Page 13: Smoke Alarm - Optical Or Ionisation
Publication entitled “Smoke Detectors in the Home” (FB2) or from your local fire prevention officer. Smoke Alarm - Optical or Ionisation? Both types respond in all standard fires but each type may respond faster to particular fires as shown. Ei Electronics manufactures Optical Smoke...
