B16009-R0-160RC SERIES-U&C
2. ALARM REMOVAL
LOCATE REMOVAL SLOT
LOCATE THE ARROW ON THE FRONT FACE OF THE ALARM.
THE SLOT IS LOCATED DIRECTLY ABOVE THE ARROW.
INSERT SCREWDRIVER
INSERT A FLAT-BLADED SCREWDRIVER HORIZONTALLY
APPROX. 1cm INTO THE CENTRE OF THE REMOVAL SLOT
SLIDE ALARM OFF BASE
WITH THE SCREWDRIVER STILL INSERTED, PUSH THE LOWER
HALF OF THE ALARM AWAY FROM THE SCREWDRIVER, IN THE
DIRECTION OF THE ARROW ON THE COVER
REMOVE ALARM
HOLD THE LOWER HALF OF THE ALARM AND REMOVE FROM
THE BASE PLATE BY MOVING IT VERTICALLY DOWNWARDS,
TOWARDS THE FLOOR.
17/1/07
11:13 AM
Page 1
2
Advertisement
Table of Contents
Related Manuals for Ei Electronics B16009-R0-160RC Series
Summary of Contents for Ei Electronics B16009-R0-160RC Series
-
Page 1: Alarm Removal
B16009-R0-160RC SERIES-U&C 17/1/07 2. ALARM REMOVAL LOCATE REMOVAL SLOT LOCATE THE ARROW ON THE FRONT FACE OF THE ALARM. THE SLOT IS LOCATED DIRECTLY ABOVE THE ARROW. INSERT SCREWDRIVER INSERT A FLAT-BLADED SCREWDRIVER HORIZONTALLY APPROX. 1cm INTO THE CENTRE OF THE REMOVAL SLOT... -
Page 2: Important Information
B16009-R0-160RC SERIES-U&C 17/1/07 11:13 AM Page 2 3. IMPORTANT INFORMATION Do not paint your alarm. Do not allow paint, water or dust to contaminate your alarm. Your alarm is a mains 230V AC electrical appliance. Do not open or insert anything into the alarm. -
Page 3: Testing & Maintaining Your Alarm
B16009-R0-160RC SERIES-U&C 17/1/07 4. CHANGING THE BATTERY (Models Ei141 / 144 / 146 only) 1. Switch off mains power to alarm (green light on cover should go out). 2. Remove unit as shown in “ALARM REMOVAL” section on page 2. - Page 4 (i) battery snaps not connected properly. (ii) On the Optical Smoke Alarm only (Ei146) if the unit beeps and the red light does not flash at the same time it indicates a problem with the smoke chamber - see “CLEANING YOUR ALARM”...
-
Page 5: Cleaning Your Alarm
Fully charged, the cells will provide up to 6 months back-up without mains power. (ii) On the Optical Smoke Alarm only (Ei166RC) if the unit beeps and the red light does not flash at the same time it indicates a problem with the smoke chamber - see “CLEANING YOUR ALARM”... -
Page 6: Nuisance Alarms
Check the house carefully in case there is a small fire smouldering somewhere. Check whether there is some source of smoke or fumes, for example cooking fumes being drawn past the Smoke Alarm by an extractor. If there are frequent nuisance/false alarms it may be necessary to re-locate the device away from the source of the fumes or replace an Ionisation Alarm with an Optical Alarm. -
Page 7: Planning Your Escape Route
Alarms contains a small amount of radioactive material (33kBq of Amercium 241). Do not tamper with the chamber. You may safely install and clean the Smoke Alarm following this leaflet’s instructions. • Do not dispose of your Alarm in a fire. - Page 8 B16009-R0-160RC SERIES-U&C 17/1/07 1. Check room doors for heat or smoke. Do not open a hot door. Use an alternate escape route. Close doors behind you as you leave. 2. If smoke is heavy, crawl out, staying close to floor. Take short breaths, if possible, through a wet cloth or hold your breath.
-
Page 9: Five Year Guarantee
If this Alarm should become defective within the guarantee period, it must be returned to Ei Electronics, with proof of purchase, carefully packaged, with the problem clearly stated. (see “Getting Your Alarm Serviced”) We shall at our discretion repair or replace the faulty unit. -
Page 10: Troubleshooting
B16009-R0-160RC SERIES-U&C 17/1/07 The crossed out wheelie bin symbol that is on your product indicates that this product should not be disposed of via the normal household waste stream. Proper disposal will prevent possible harm to the environment or to human health. When disposing of this product please separate it from other waste streams to ensure that it can be recycled in an environmentally sound manner. -
Page 11: Table Of Contents
(2) One or more of the connections may not be correctly connected. We recommend you consult a qualified electrician. Aico Ltd. Mile End Business Park, Maesbury Rd, Oswestry, Shropshire SY10 8NN, U.K. www.aico.co.uk Ei Electronics. Shannon, Co Clare, Ireland. Tel: 061 471277 www.eielectronics.com INDEX 1. REGULAR CHECKS 2. ALARM REMOVAL 3. -
Page 12: Regular Checks
Constant green light Red light flash every 40 sec. Press test button for 10 sec. Alarm will sound loudly. P/N B16009 Rev0 11:13 AM Page 12 Ei146 - Optical Ei166RC - Optical Vacuum around side vents to clean. © Ei Electronics 2006...
