Cisco ASR1002 - ASR 1002 Router Configuration Manual page 23

Configuring Performance Metrics to Select a Service
Command or Action
Step 12
do show pfm entity-number
Example:
switch# show pfm
Configuring the PFM on a CE-facing PE: Example
The CE-facing PE configured in this example has one CE that is not PfR MC-enabled, and two CEs that are
PfR MC-enabled.
pfm ce-facing
entity 1
entity 2
entity 3
pfm local-host 10.1.1.2
ce-table table1
ce-address ipv4 10.1.1.1
ce-address ipv4 20.1.12.1
ce-address ipv4 20.1.13.1
ce-address ipv4 20.1.10.2
ce-table table2
ce-address ipv4 50.1.1.1 pfr-mc
ce-address ipv4 50.1.2.1
ce-table table10
ce-address ipv4 60.1.1.1 pfr-mc
ce-address ipv4 60.1.2.1
ce-address ipv4 60.1.3.1
show pfm: Example
This example shows sample output from the show pfm command:
switch# show pfm
Entity-ID
1
5
What to Do Next
Configure any DC-facing PEs.
OL-25794-01
ce-table table1
pfr-mc disable
ce-table table2
pfr-mc disable
ce-table table10
PFM-ID
PFM-26.0.0.2-1
PFM-26.0.0.2-5
Cisco Network Positioning System Configuration Guide for the Cisco ASR 1000 Router, Release 1.0
Configuring the Performance Manager on a CE-Facing PE
Purpose
Displays the configured performance management information.
• entity-number—Displays information for a specific entity. When
not used, information for all configured entities is displayed.
Active-PDP-Address CE-Table
192.168.1.1 cet123
10.74.5.32
17
