Configuring Performance Metrics to Select a Service

Configuring the Performance Manager on a CE-Facing PE

The performance subsystem (PFS) on a CE-facing PE runs both the performance manager (PFM) and the
performance adapter (PFA). It is responsible to:
• Receive requests from a remote PFM through the Extensible Messaging and Presence Protocol (XMPP).
• Use PFA APIs to enable the CE device to obtain performance data from the PDP.
• Use the PFA to filter and format the data for the CE device.
Configure the PFM on all CE-facing PEs.
It is also possible to configure the CE-facing PFM on a DC-facing PE. In this scenario, both the CE-facing
Note
PE configuration and the DC-facing PE configuration are performed on all DC-facing PE routers. Then
the PFM is not configured on any CE-facing PE routers.
SUMMARY STEPS
1. xmpp server type pfm hostname
2. pfm local-host ip-address
3. ce-table name
4. ce-address ipv4 ip-address pfr-mc
5. exit
6. pfm ce-facing
7. entity number
8. ce-table name
9. pfr-mc {enable | disable}
10. wsma agent
11. host ip-address username user password pass
12. do show pfm entity-number
DETAILED STEPS
Command or Action
Step 1
xmpp server type pfm hostname
Example:
switch(config)# xmpp server type pfm
ccnsr.com
Step 2 pfm local-host ip-address
Example:
switch(config)# pfm local-host 10.1.0.2
OL-25794-01
Purpose
Specifies the name of the XMPP server for PFM.
Specifies the IP address that the external world uses to reach the PFM.
Cisco Network Positioning System Configuration Guide for the Cisco ASR 1000 Router, Release 1.0
Configuring the Performance Manager on a CE-Facing PE
15
