Konica Minolta bizhub 501/421/361
Specification & Installation Guide
bizhub 501/421/361 Specifications
Type Black and white printer/copier/scanner/fax
with stationary platen
Document holder Stationary (mirror scanning)
Photoconductor OPC
Luminous source White inert gas fluorescent lamp
Copying system Laser exposure electrostatic copy system
Developing system Dry-type dual-component reverse
magnetic brush developing method
Fusing system Heat roller fixing
Resolution Scanning: 600 x 600 dpi
Copying: 2,400 x 600 dpi equivalent
Printing: 2,400 x 600 dpi equivalent
Document holder Types: Sheets, books (spreads),
three-dimensional objects
Size:
Maximum 11" x 17" (A3)
Weight: 15 lb. (three-dimensional objects)
Paper Plain paper (16 lb. to 28 lb.), Thick paper
(29 lb. to 56 lb.)*, Thin paper (13 lb. to 15 lb.),
overhead projector transparencies*,
letterheads, colored paper, envelopes*,
label sheets*, trace paper*
*Can only be fed through the bypass tray
Copy sizes 1st & 2nd tray:
11" x 17" to 5.5" x 8.5"
Bypass tray:
11" x 17" to 5.5" x 8.5"
Paper tray capacity 1st tray:
Plain paper: 500 sheets
2nd tray:
Plain paper: 500 sheets
Bypass tray:
Plain paper: 150 sheets
Thick paper, overhead projector
transparencies, label sheets, envelopes:
10 sheets or less, label sheets, blueprint
master: 1 at a time
Exit tray capacity 100 sheets
Warm-up time 501: Less than 60 seconds
421/361: Less than 30 seconds
(at room temperature)
Image area Copying: Leading edge: < 3 mm
Printing: Leading edge: < 3 mm
(Universal Cassette)
(Universal Cassette)
Trailing edge: < 6 mm
Left & Right Sides: < 3 mm
Trailing edge: < 4 mm
Left & Right Sides: < 2 mm
First copy 501: 3.2 seconds or less
421/361: 3.6 seconds or less
bizhub 501 (Simplex)
Print/copy speed:*
5.5" x 8.5" R
8.5" x 11" R
8.5" x 11"
8.5" x 14"
11" x 17"
bizhub 421 (Simplex)
5.5" x 8.5" R
8.5" x 11" R
8.5" x 11"
8.5" x 14"
11" x 17"
bizhub 361 (Simplex)
5.5" x 8.5" R
8.5" x 11" R
8.5" x 11"
8.5" x 14"
11" x 17"
*R = Reverse Orientation (Landscape)
Magnification ratios Full size: 100% ± 0.5% or less
Enlarge: 121%, 129%, 155%, 200%
Reduce: 79%, 77%, 65%, 50%
Minimal (93%)*
Zoom: 25% to 400% (in 0.1% increments)
Stored zoom ratios: 3
*Minimal zoom ratio: 90% to 99.9%
Multiple copies 1 to 999 copies
Density control Background density: Manual (9 levels);
Copy density: Automatic and manual
(9 levels)
Power requirements 120 V, 12 A, 60 Hz
Power consumption Less than 1,560 W (including option)
Main body + DF-613:
Dimensions
26.7" (W) x 27.9" (D) x 35.23" (H)
Main body + DF-613 + PC-206/PC-407:
26.7" (W) x 27.9" (D) x 45.28" (H)
Space requirements 38.5" (W) x 27.9" (D) (main body/DF-613)
Memory (available 1,024 MB RAM (205 MB file memory)
hard disk space) (Optional 120 GB HD)
Weight Approx. 215 lb. (Main unit and ADF)
03/2011
50 ppm
37 ppm
50 ppm
31 ppm
27 ppm
42 ppm
31 ppm
42 ppm
26 ppm
23 ppm
42 ppm
31 ppm
36 ppm
26 ppm
23 ppm
