651M-L/650GM-L Series
MS-7005 (v1.X) Micro ATX Mainboard
Version 1.0
G52-M7005X1-K01
i

Advertisement

Table of Contents
loading

Related Manuals for MSI MS 7005 - 651M-L Motherboard - Micro ATX

Summary of Contents for MSI MS 7005 - 651M-L Motherboard - Micro ATX

  • Page 1 651M-L/650GM-L Series MS-7005 (v1.X) Micro ATX Mainboard Version 1.0 G52-M7005X1-K01...

  • Page 2: Fcc-B Radio Frequency Interference Statement

    Manual Rev: 1.0 Release Date: June 2003 FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equip- ment is operated in a commercial environment.

  • Page 3: Copyright Notice

    Copyright Notice The material in this document is the intellectual property of MICRO-STAR INTERNATIONAL. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice.

  • Page 4: Safety Instructions

    Safety Instructions Always read the safety instructions carefully. Keep this User’s Manual for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equipment from overheating.

  • Page 5: Table Of Contents

    Safety Instructions ..................iv Chapter 1. Getting Started ................ 1-1 Mainboard Specifications ..............1-2 Mainboard Layout ................1-4 MSI Special Features ................1-5 PC Alert™ 4 ................... 1-5 Live BIOS™/Live Driver™ ............1-6 Live Monitor™ ................1-7 Chapter 2. Hardware Setup ............... 2-1 Quick Components Guide ..............
  • Page 6 VGA Connector ................2-12 RJ-45 LAN Jack ................2-13 Audio Port Connectors ............... 2-13 Midi/Joystick Connector ............. 2-14 Parallel Port Connectors: LPT1 ............ 2-14 Connectors ..................2-15 Front Disk Drive Connector: FDD1 ..........2-15 CD-In Connector: JCD1 ............... 2-15 Hard Disk Connectors: IDE1 & IDE2 ........... 2-16 Fan Power Connectors: CPUFAN1/SYSFAN1 ......
  • Page 7 Advanced BIOS Features ..............3-8 Advanced Chipset Features ............... 3-12 Integrated Peripherals ................ 3-14 Power Management Setup ..............3-18 PNP/PCI Configurations ..............3-22 PC Health Status ................3-24 Frequency/Voltage Control ..............3-25 Load Fail-Safe/Optimized Defaults ............. 3-27 Set Supervisor/User Password ............3-28 Appendix: Using 4- or 6-Channel Audio Function ........

  • Page 8: Chapter 1. Getting Started

    Hardware Setup Getting Started Thank you for purchasing 651M-L/650GM-L Series (MS-7005) v1.X Micro ATX mainboard. The 651M-L/650GM-L ® ® series is based on SiS 651/650GX (702 pin BGA) & SiS 962L MuTIOL Media I/O (371 BGA) chipsets and provides 6 USB 2.0 ports for high-speed data transmission.

  • Page 9: Mainboard Specifications

    MS-7005 Micro ATX Mainboard Mainboard Specifications Socket 478 for P4 processors (Willamette 478 / Northwood 478 / Celeron 478) at 400 MHz/ 533 MHz Supports up to 3.06GHz. Hyper-Threading CPU for SiS651 only. Chipset SiS 651/650GX (702 pin BGA) - High performance host interface 400 MHz/533 MHz - Supports 64 Bit high performance DDR200/266 (for SiS650GX) / DDR200/ 266/333 (for SiS 651) memory controller - Supports AGP 4X/2X interface with fast write transaction...
  • Page 10 Hardware Setup Can connect up to four IDE devices. On-Board Peripherals On-Board Peripherals include: - 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88 Mbytes. - 1 serial port (COMA) and 1 VGA port - 1 parallel port supports SPP/EPP/ECP mode - 6 USB 2.0/1.1 ports (Rear * 2 / Front * 4) - 1 Line-In/Line-Out/Mic-In port - 1 game port...

  • Page 11: Mainboard Layout

    MS-7005 Micro ATX Mainboard Mainboard Layout CPUFAN1 Top : mouse Bottom: keyboard BIOS Winbond W83697HF Top : Parallel Port Bottom: COM A VGA Port Top : Game port Bottom: Line-Out 651/ 650GX ATX12V Line-In T: LAN jack B: USB ports AGP Slot BATT Realtek...

  • Page 12: Msi Special Features

    Hardware Setup MSI Special Features PC Alert™ 4 The PC Alert 4 is a utility you can find in the CD-ROM disk. The utility is just like your PC doctor that can detect the following PC hardware status during real time operation: monitor CPU &...

  • Page 13: Live Bios™/Live Driver

    BIOS/drivers online so that you don’t need to search for the correct BIOS/driver version throughout the Web site. To use the function, you need to install the “MSI Live Update 2” application. After the installation, the “MSI Live Update 2”...

  • Page 14: Live Monitor

    Live Monitor™ The Live Monitor™ is a tool used to schedule the search for the latest BIOS/drivers version on the MSI Web site. To use the function, you need to install the “MSI Live Update 2” application. After the installation, the “MSI Live Monitor” icon (as shown on the right) will appear on the screen.

  • Page 15: Chapter 2. Hardware Setup

    Hardware Setup Chapter 2. Hardware Setup Hardware Setup This chapter tells you how to install the CPU, memory modules, and expansion cards, as well as how to setup the jumpers on the mainboard. It also provides the instructions on connecting the peripheral devices, such as the mouse, keyboard, etc.

  • Page 16: Quick Components Guide

    MS-7005 Micro ATX Mainboard Quick Components Guide DDR DIMMs, p.2-7 CPU, p.2-3 ATX12V, p.2-9 CPUFAN1, p.2-17 CONN1, p.2-9 Back Panel FDD1, p.2-15 I/O, p.2-10 SYSFAN1, p.2-17 AGP Slot, p.2-24 IDE1, IDE2, p.2-16 JCD1, p.2-15 JBAT1, p.2-23 JSP1, p.2-21 JCI1, p.2-22 JFP1, p.2-18 PCI Slots, p.2-24 JFP2, p.2-18...

  • Page 17: Central Processing Unit: Cpu

    Memory Speed/CPU FSB Support Matrix Memory DDR 266 DDR 333 400 MHz 533 MHz MSI Reminds You... Overheating Overheating will seriously damage the CPU and system, always make sure the cooling fan can work properly to protect the CPU from overheating. Replacing the CPU While replacing the CPU, always turn off the ATX power supply or unplug the power supply’s power cord from grounded outlet...

  • Page 18: Cpu Installation Procedures For Socket 478

    MS-7005 Micro ATX Mainboard CPU Installation Procedures for Socket 478 1. Please turn off the power and unplug the power cord before Open Lever installing the CPU. 2. Pull the lever sideways away Sliding 90 degree Plate from the socket. Make sure to raise the lever up to a 90- degree angle.

  • Page 19: Installing The Cpu Fan

    Hardware Setup Installing the CPU Fan As processor technology pushes to faster speeds and higher performance, thermal management becomes increasingly important. To dissi- pate heat, you need to attach the CPU cooling fan and heatsink on top of the CPU. Follow the instructions below to install the Heatsink/Fan: 1.
  • Page 20 MS-7005 Micro ATX Mainboard 5. Connect the fan power cable from the mounted fan to the 3-pin fan power connec- tor on the board. fan power cable NOTES...

  • Page 21: Memory

    Hardware Setup Memory The mainboard provides two 184-pin unbuffered DDR200/DDR266/ DDR333 DDR SDRAM, and supports the memory size up to 2GB. To operate properly, at least one DIMM module must be installed. DDR DIMM Slots (DDR 1~2) Introduction to DDR SDRAM DDR (Double Data Rate) SDRAM is similar to conventional SDRAM, but doubles the rate by transferring data twice per cycle.

  • Page 22: Ddr Module Combination

    3. The plastic clip at each side of the DIMM slot will automatically close. Volt Notch MSI Reminds You... You can barely see the golden finger if the module is properly inserted in the socket.

  • Page 23: Power Supply

    Hardware Setup Power Supply The mainboard supports ATX power supply for the power system. Before inserting the power supply connector, always make sure that all components are installed properly to ensure that no damage will be caused. ATX 20-Pin Power Connector: CONN1 This connector allows you to connect to an ATX power supply.

  • Page 24: Back Panel

    MS-7005 Micro ATX Mainboard Back Panel The back panel provides the following connectors: Parallel Midi/Joystick Mouse Keyboard COMA VGA Port L-out L-in MIC USB Ports Mouse Connector The mainboard provides a standard PS/2 ® mouse mini DIN connector for ® ®...

  • Page 25: Keyboard Connector

    Hardware Setup Keyboard Connector ® The mainboard provides a standard PS/2 keyboard mini DIN connector ® ® for attaching a PS/2 keyboard. You can plug a PS/2 keyboard directly into this connector. Pin Definition SIGNAL DESCRIPTION Keyboard DATA Keyboard DATA No connection Ground Keyboard Clock...

  • Page 26: Serial Port Connectors: Coma

    MS-7005 Micro ATX Mainboard Serial Port Connectors: COMA The mainboard offers one 9-pin male DIN connector as serial port COM A. This port is 16550A high speed communication ports that send/receive 16 bytes FIFOs. You can attach a serial mouse or other serial device directly to it. 1 2 3 4 5 Pin Definition SIGNAL...

  • Page 27: Rj-45 Lan Jack

    CD player, Tape player, or other audio devices. Mic is a connector for microphones. 1/8” Stereo Audio Connectors Line Out Line In MSI Reminds You... For advanced audio application, Realtek ALC 655 is provided to offer support for 6-channel audio operation and can turn rear audio connectors from 2-channel to 4-/6-channel audio.

  • Page 28: Midi/Joystick Connector

    MS-7005 Micro ATX Mainboard Midi/Joystick Connector You can connect a joystick or game pad to this connector. Parallel Port Connector: LPT1 The mainboard provides a 25-pin female centronic connector as LPT. A parallel port is a standard printer port that supports Enhanced Parallel Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.

  • Page 29: Connectors

    Hardware Setup Connectors The mainboard provides connectors to connect to FDD, IDE HDD, case, LAN, USB Ports, IR module and CPU/System/Power Supply FAN. Floppy Disk Drive Connector: FDD1 The mainboard provides a standard floppy disk drive connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. FDD1 CD-In Connector: JCD1 The connector is for CD-ROM audio connector.

  • Page 30: Hard Disk Connectors: Ide1 & Ide2

    IDE2 (Secondary IDE Connector) IDE2 can also connect a Master and a Slave drive. MSI Reminds You... If you install two hard disks on cable, you must configure the second drive to Slave mode by setting its jumper. Refer to the hard disk documentation supplied by hard disk vendors for jumper setting instructions.

  • Page 31: Fan Power Connectors: Cpufan1/Sysfan1

    CPUFAN1 +12V SENSOR SYSFAN1 MSI Reminds You... 1. Always consult the vendors for proper CPU cooling fan. 2. CPUFAN1 supports the fan control. You can install the PC Alert utility that will automatically control the CPU fan speed according to the actual CPU temperature.

  • Page 32: Front Panel Connectors: Jfp1 & Jfp2

    MS-7005 Micro ATX Mainboard Front Panel Connectors: JFP1 & JFP2 The mainboard provides two front panel connectors for electrical ® connection to the front panel switches and LEDs. JFP1 is compliant with Intel Front Panel I/O Connectivity Design Guide. JFP1 Power Reset Power...

  • Page 33: Front Panel Audio Connector: Jaud1

    Left channel audio signal to front panel AUD_RET_L Left channel audio signal return from front panel MSI Reminds You... If you don’t want to connect to the front audio header, pins 5 & 6, 9 & 10 have to be jumpered in order to have signal output directed to the rear audio ports.

  • Page 34: Front Usb Connectors: Jusb1/Jusb2

    MS-7005 Micro ATX Mainboard Front USB Connectors: JUSB1/JUSB2 The mainboard provides two USB 2.0 pin headers JUSB1 & JUSB2 that ® are compliant with Intel I/O Connectivity Design Guide. USB 2.0 technology increases data transfer rate up to a maximum throughput of 480Mbps, which is 40 times faster than USB 1.1, and is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like.

  • Page 35: Spdif Connector: Jsp1(Optional)

    Hardware Setup SPDIF Connector: JSP1 (Optional) The connector is used to connect SPDIF (Sony & Philips Digital Inter- connect Format) interface for digital audio transmission. JSP1 Pin Definition SIGNAL VCCS SPDIF0 JSP1 The JSP1 supports SPDIF output only and can be connected to an external SPDIF Bracket for digital audio transmission.

  • Page 36: Chassis Intrusion Switch Connector: Jci1

    MS-7005 Micro ATX Mainboard Chassis Intrusion Switch Connector: JCI1 This connector is connected to 2-pin connector chassis switch. If the Chassis is open, the switch will be short. The system will record this status. To clear the warning, you must enter the BIOS setting and clear the status. JCI1 2-22...

  • Page 37: Jumpers

    JBAT1 Keep Data Clear Data MSI Reminds You... You can clear CMOS by shorting 2-3 pin while the system is off. Then return to 1-2 pin position. Avoid clearing the CMOS while the system is on; it will damage the mainboard.

  • Page 38: Slots

    MS-7005 Micro ATX Mainboard Slots The motherboard provides one AGP slot, three 32-bit PCI bus slots and one CNR slot. AGP Slot PCI Slots CNR Slot AGP (Accelerated Graphics Port) Slot The AGP slot allows you to insert the AGP graphics card. AGP is an interface specification designed for the throughput demands of 3D graphics.

  • Page 39: Pci Interrupt Request Routing

    Hardware Setup PCI Interrupt Request Routing The IRQ, abbreviation of interrupt request line and pronounced I-R-Q, are hardware lines over which devices can send interrupt signals to the microprocessor. The PCI IRQ pins are typically connected to the PCI bus INT A# ~ INT D# pins as follows: Order 1 Order 2...

  • Page 40: Chapter 3. Bios Setup

    BIOS Setup Chapter 3. BIOS Setup BIOS Setup This chapter provides information on the BIOS Setup program and allows you to configure the system for optimum use. You may need to run the Setup program when: An error message appears on the screen during the system booting up, and requests you to run SETUP.

  • Page 41: Entering Setup

    MS-7005 Micro ATX Mainboard Entering Setup Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press <DEL> key to enter Setup. Press DEL to enter SETUP If the message disappears before you respond and you still wish to enter Setup, restart the system by turning it OFF and On or pressing the RESET button.

  • Page 42: Getting Help

    Press <Esc> to exit the Help screen. MSI Reminds You... The items under each BIOS category described in this chapter are under continuous update for better system performance.

  • Page 43: The Main Menu

    MS-7005 Micro ATX Mainboard The Main Menu ® Once you enter Award BIOS CMOS Setup Utility, the Main Menu (figure below) will appear on the screen. The Main Menu allows you to select from twelve setup functions and two exit choices. Use arrow keys to select among the items and press <Enter>...
  • Page 44 BIOS Setup Frequency/Voltage Control Use this menu to specify your settings for frequency/voltage control. Load Fail-Safe Defaults Use this menu to load the BIOS values for the best system performance, but the system stability may be affected. Load Optimized Defaults Use this menu to load factory default settings into the BIOS for stable system performance operations.

  • Page 45: Standard Cmos Features

    MS-7005 Micro ATX Mainboard Standard CMOS Features The items in Standard CMOS Features Menu are divided into 11 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 46 BIOS Setup If you select Manual, related information is asked to be entered to the following items. Enter the information directly from the keyboard. This information should be provided in the documentation from your hard disk vendor or the system manufacturer. Access Mode The settings are CHS, LBA, Large, Auto.

  • Page 47: Advanced Bios Features

    MS-7005 Micro ATX Mainboard Advanced BIOS Features Quick Boot Setting the item to Enabled allows the system to boot within 5 seconds since it will skip some check items Settings: Disabled, Enabled. Virus Warning The item is to set the Virus Warning feature for IDE Hard Disk boot sector protection.
  • Page 48 The system will boot from the Network drive. Disabled Disable this sequence. MSI Reminds You... If you want to boot from any of the USB-interface devices, please set USB Keyboard/Mouse Support in SiS OnChip PCI Device of Integrated Peripherals to Enabled.
  • Page 49 MS-7005 Micro ATX Mainboard MSI Reminds You... Enabling the functionality of Hyper-Threading Technology for your computer system requires ALL of the following platform Components: ® ® *CPU: An Intel Pentium 4 Processor with HT Technology; *Chipset: A chipset that supports HT Technology;...
  • Page 50 BIOS Setup Security Option This specifies the type of BIOS password protection that is implemented. Settings are described below: Option Description Setup The password prompt appears only when end users try to run Setup. System A password prompt appears every time when the com- puter is powered on or when end users try to run Setup.

  • Page 51: Advanced Chipset Features

    MS-7005 Micro ATX Mainboard Advanced Chipset Features MSI Reminds You... Change these settings only if you are familiar with the chipset. Advanced DRAM Control 1 Press <Enter> and the following sub-menu appears: System Performance This setting particularly provided by SiS gives the proper suggestion for user to set timing.
  • Page 52 BIOS Setup MA 1T/2T Select This setting controls the SDRAM command rate. Selecting Auto allows SDRAM signal controller to run at 1T (T=clock cycles) rate. Selecting MA 1T makes SDRAM signal controller run at 2T rate. 1T is faster than 2T.

  • Page 53: Integrated Peripherals

    MS-7005 Micro ATX Mainboard Integrated Peripherals SiS OnChip IDE Device Press <Enter> and the following sub-menu appears: Internal PCI/IDE The field specifies the internal primary and secondary PCI/IDE controllers. Settings: Disabled, Primary, Secondary, Both. IDE Primary/Secondary Master/Slave PIO The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports.
  • Page 54 BIOS Setup hard drive supports it and the operating environment includes a DMA driver (Windows ME, XP or a third-party IDE bus master driver). If your hard drive and your system software both support Ultra DMA/33, Ultra DMA/66, Ultra DMA/100 and Ultra DMA/133, select Auto to enable BIOS support.
  • Page 55 MS-7005 Micro ATX Mainboard SiS S/W Modem This item is used to enable/disable the SiS S/W Modem. Settings: Auto, Disabled. SiS 10/100M Ethernet This item is used to enable/disable the 10/100M Ethernet function. Settings: Enabled, Disabled. Onboard Lan Boot ROM This item is used to decide whether to invoke the Boot ROM of the Onboard LAN Chip.
  • Page 56 BIOS Setup SPP: Standard Parallel Port EPP: Enhanced Parallel Port ECP: Extended Capability Port ECP + EPP: Extended Capability Port + Enhanced Parallel Port Normal: Standard Parallel Port + Bi-Directional Mode. EPP Mode Select This item selects the EPP mode. Settings: EPP1.9, EPP1.7. ECP Mode Use DMA The ECP mode has to use the DMA channel, so choose the onboard parallel port with the ECP feature.

  • Page 57: Power Management Setup

    MS-7005 Micro ATX Mainboard Power Management Setup Sleep State This item specifies the power saving modes for ACPI function. Options are: S1/POS The S1 sleep mode is a low power state. In this state, no system context is lost (CPU or chipset) and hardware maintains all system context.
  • Page 58 BIOS Setup MODEM Use IRQ This setting names the interrupt request (IRQ) line assigned to the modem (if any) on your system. Activity of the selected IRQ always awakens the system. Setting options: 3, 4, 5, 7, 9, 10, 11, Auto. HDD Off After After the selected period of system inactivity, the Hard Disk will be shut off.
  • Page 59 MS-7005 Micro ATX Mainboard MSI Reminds You... S3-related functions described in this section are available only when your BIOS supports S3 sleep mode. IRQ [3-7, 9-15], NMI; IRQ 8 Break Suspend These fields specify whether the system will be awakened from power saving modes when activity or input signal of the specified hardware peripheral or component is detected.
  • Page 60 BIOS Setup Time (hh:mm:ss) Alarm When Resume By Alarm is set to Enabled, the field specifies the time for Resume By Alarm. Format is <hour><minute><second>. ** Reload Global Timer Events ** Primary/Secondary IDE, FDD/COM/LPT Ports, PCI PIRQ [A-D]# The global timer is the hardware timer that counts down to the power saving modes.

  • Page 61: Pnp/Pci Configurations

    MS-7005 Micro ATX Mainboard PNP/PCI Configurations This section describes configuring the PCI bus system and PnP (Plug & Play) feature. PCI, or Peripheral Component Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its special components.
  • Page 62 BIOS Setup IRQ Resources The items are adjustable only when Resources Controlled By is set to Manual. Press <Enter> and you will enter the sub-menu of the items. IRQ Resources list IRQ 3/4/5/7/9/10/11/12/14/15 for users to set each IRQ a type depending on the type of device using the IRQ.

  • Page 63: Pc Health Status

    MS-7005 Micro ATX Mainboard PC Health Status This section shows the status of your CPU, fan, overall system status, etc. Monitor function is available only if there is hardware monitoring mechanism onboard. Case Open Warning The field enables or disables the feature of recording the chassis intrusion status and issuing a warning message if the chassis is once opened.

  • Page 64: Frequency/Voltage Control

    BIOS Setup Frequency/Voltage Control Use this menu to specify your settings for frequency/voltage control. Set CPU Ratio User may select to set the CPU ratio manually or use the default value of the motherboard manufacturer. Settings: Manual, Default CPU Clock Ratio End users can overclock the processor (only if the processor supports so) by specifying the CPU ratio (clock multiplier) in this field.
  • Page 65 MS-7005 Micro ATX Mainboard slight jitter can introduce a temporary boost in clock speed which may just cause your overclocked processor to lock up. CPU Frequency Use this item to select the appropriate clock frequency of the CPU host bus. Options are: 100MHz, 133MHz, Default.

  • Page 66: Load Fail-Safe/Optimized Defaults

    BIOS Setup Load Fail-Safe/Optimized Defaults The two options on the main menu allow users to restore all of the BIOS settings to the default Fail-Safe or Optimized values. The Optimized Defaults are the default values set by the mainboard manufacturer specifically for optimal performance of the mainboard.

  • Page 67: Set Supervisor/User Password

    Security Option is set to System, the password is required both at boot and at entry to Setup. If set to Setup, password prompt only occurs when you try to enter Setup. MSI Reminds You... About Supervisor Password & User Password: Supervisor password: Can enter and change the settings of the setup menu.

  • Page 68: Appendix: Using 4- Or 6-Channel Audio Function

    Using 4- or 6-Channel Audio Function Appendix: Using 4- or 6-Channel Audio Function The motherboard is equipped with Realtek ALC655 chip, which provides support for 6-channel audio output, including 2 Front, 2 Rear, 1 Center and 1 Subwoofer channel. ALC655 allows the board to attach 4 or 6 speakers for better surround sound effect.

  • Page 69: Installing The Audio Driver

    (Please note the screen below might be different depending on the different mainboard you purchased.) 2. Click Realtek AC97 Audio Drivers. MSI Reminds You... The AC97 Audio Configuration software utility is under con- tinuous update to enhance audio applications. Hence, the program screens shown here in this appendix may be slightly different from the latest software utility and shall be held for reference only.
  • Page 70 Using 4- or 6-Channel Audio Function 3. Click Next to start installing files into the system. 4. Click Finish to restart the system. Select this option...

  • Page 71: Using 4- Or 6-Channel Audio Function

    MS-7005 Micro ATX Mainboard Using 4- or 6-Channel Audio Function After installing the audio driver, you are able to use the 4-/6-channel audio feature now. To enable 4- or 6-channel audio operation, first connect 4 or 6 speakers to the appropriate audio connectors, and then select 4- or 6- channel audio setting in the software utility.
  • Page 72 Using 4- or 6-Channel Audio Function...
  • Page 73 MS-7005 Micro ATX Mainboard Connecting the Speakers When you have set the Multi-Channel Audio Function mode properly in the software utility, connect your speakers to the correct phone jacks in accordance with the setting in software utility. 2-Channel Mode for Stereo-Speaker Output Refer to the following diagram and caption for the function of each phone jack on the back panel when 2-Channel Mode is selected.
  • Page 74 Line Out function when 4-Channel Mode for 6-Speaker Output is selected. MSI Reminds You... If the Center and Subwoofer speaker exchange their audio chan- nels when you play video or music on the computer, a converter may be required to exchange center and subwoofer audio...

  • Page 75: Testing The Connected Speakers

    Front Left Rear Right Rear Left Subwoofer MSI Reminds You... 6 speakers appear on the “Speaker Test” window only when you select “6-Channel Mode” in the “No. of Speakers” column. If you select “4-Channel Mode”, only 4 speakers appear on the...
  • Page 76 Using 4- or 6-Channel Audio Function 4. While you are testing the speakers in 6-Channel Mode, if the sound com- ing from the center speaker and subwoofer is swapped, you should select Swap Center/Subwoofer Output to readjust these two channels. Select this function...

  • Page 77: Playing Karaok

    MS-7005 Micro ATX Mainboard Playing KaraOK The KaraOK function will automatically remove human voice (lyrics) and leave melody for you to sing the song. Note that this function applies only for 2-channel audio operation. Playing KaraOK 1. Click the audio icon from the window tray at the lower-right corner of the screen.

  • Page 78: Troubleshooting

    Troubleshooting Troubleshooting Troubleshooting How do I know that the product that I have is from MSI? All MSI product starts with the character MS-XXXX or Marketing Name (MS-XXXX) wherein XXXX refers to numbers. You should be able to find the Model number in between the PCI slots. For Example: MS-6368...
  • Page 79 If problem still persists, you would need to purchase new BIOS chip from Websites like www.flashbios.org where you can order a new BIOS or you can also contact MSI office near your place to purchase new BIOS chip. Please refer to http://www.msi.com.tw/html/contact/contact.htm My motherboard BIOS sticker is "Phoenix BIOS", but when I boot up...
  • Page 80 CPU type 3. For Optical product firmware, refer to http://www.msi.com.tw/program/ support/driver/dvr/spt_dvr_list.php?part=4 Where can I find MSI developed software such as Fuzzy Logic or PC Alert? Refer to http://www.msi.com.tw/program/support/software/swr/ spt_swr_list.php Where can I find the manual? 1.
  • Page 81 2. Try to clear the CMOS. If problem still persists, ask your reseller for new BIOS chip or contact one of MSI office near your place for new BIOS chip. Please refer to http://www.msi.com.tw/contact/main.htm Should I update my BIOS, once a new BIOS is released? 1.
  • Page 82 3. For Server motherboard, refer to http://www.msi.com.tw/program/sup- port/driver/dvr/spt_dvr_list.php?part=3 4. For Optical product firmware, refer to http://www.msi.com.tw/program/ support/driver/dvr/spt_dvr_list.php?part=4 5. For MSI special product like bluetooth or TV tuner, refer to http:// www.msi.com.tw/program/support/driver/dvr/spt_dvr_list.php? part=5 How can I know what CPU does my motherboard support? 1.
  • Page 83 How can I find MSI distributor in my country? Refer to http://www.msi.com.tw/program/contact/where2buy/. Select the country & you will find MSI distributor in that country. If in case you cannot find the country listed, then it means MSI still don’t have dis-...
  • Page 84 - Move the PCI card to different PCI slots - Update the card BIOS or drivers - Update the motherboard BIOS What should I do if my MSI VGA card have compatibility issue with another brand of motherboard? Update the video driver...

  • Page 85: Glossary

    Glossary Glossary Glossary ACPI (Advanced Configuration & Power Interface) This power management specification enables the OS (operating system) to control the amount of power given to each device attached to the computer. Windows 98/98SE, Windows 2000 and Windows ME can fully support ACPI to allow users managing the system power flexibly.
  • Page 86 MS-7005 MicroATX Mainboard contents of frequently accessed RAM locations and the addresses where these data items are stored. Chipset A collection of integrated chips designed to perform one or more related functions. For example, a modem chipset contains all the primary circuits for transmitting and receiv- ing data;...
  • Page 87 Glossary ECC Memory (Error Correcting Code Memory) A type of memory that contains special circuitry for testing the accuracy of data and correcting the errors on the fly. EEPROM Acronym for Electrically Erasable Programmable Read-Only Memory. An EEPROM is a special type of PROM that can be erased by exposing it to an electrical charge. Like other types of PROM, EEPROM retains its contents even when the power is turned off.
  • Page 88 MS-7005 MicroATX Mainboard IDE (Integrated Drive Electronics) A type of disk-drive interface widely used to connect hard disks, CD-ROMs and tape drives to a PC, in which the controller electronics is integrated into the drive itself, eliminating the need for a separate adapter card. The IDE interface is known as the ATA (AT Attachment) specification.
  • Page 89 Glossary LBA (Logical Block Addressing) Logical block addressing is a technique that allows a computer to address a hard disk larger than 528 megabytes. A logical block address is a 28-bit value that maps to a specific cylinder-head-sector address on the disk. 28 bits allows sufficient variation to specify addresses on a hard disk up to 8.4 gigabytes in data storage capacity.
  • Page 90 MS-7005 MicroATX Mainboard PS/2 Port A type of port developed by IBM for connecting a mouse or keyboard to a PC. The PS/2 port supports a mini DIN plug containing just 6 pins. Most modern PCs equipped with PS/2 ports so that the special port can be used by another device, such as a modem.
