- Page 1 Zilla Dual-Speed Hub-3008R Quick Installation Guide...
- Page 3 Quick Installation Guide Introduction Accton’s Zilla Hub is a compact dual-speed hub featuring 8 10BASE-T/100BASE-TX auto-sensing ports. This hub is completely plug and play, no configuration necessary. This dual-speed hub contains two internal repeater buses – one for 10Mbps traffic and another for 100Mbps traffic. Traffic passing between attached devices that operate at the same speed is confined within the appropriate repeater bus.
-
Page 4: Check The Package
Zilla Hub Check the Package The Zilla Hub includes: • 1 Zilla Hub • 1 DC Power Adapter • This user guide • 1 registration card (please return) RJ-45 Connectors Accton’s Zilla Hub features 8 10BASE-T/100BASE-TX ports with RJ-45 connectors located on the side panel of the hub. Ports 1-8 are (computer) station ports. - Page 5 Quick Installation Guide 2. Install a 10 or 100 Mbps (10BASE-T or 100BASE-TX) network adapter card and driver in each computer you want to network. 3. Prepare straight-through twisted-pair cables with RJ-45 plugs. Attach one end of the cable to the RJ-45 port of the computer’s network adapter card and the other end to any available port on the hub.
-
Page 6: Verify System Operation
Zilla Hub Verify System Operation Check each connection by viewing the port status indicators shown in the following table. The hub monitors the link status for each port. If the Port indicator fails to light when you connect a device to the hub, follow the troubleshooting advice detailed in the next section. -
Page 7: Application Diagram
Quick Installation Guide Application Diagram... -
Page 8: Specifications
Zilla Hub Specifications Standards Conformance IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX Number of Ports 8 10/100 Mbps RJ-45 ports (one of which serves as a daisy-chain port) Network Interface RJ-45: 100Š, UTP cable 10BASE-T: Category 3, 4 or 5 100BASE-TX: Category 5 Switching Method Store-and-forward MAC Address Table... -
Page 9: Fcc Class B Certification
Quick Installation Guide Certification FCC Class B Certification This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. - Page 10 Zilla Hub VCCI Class B Compliance (Japan) CE Mark Declaration of Conformance (for EMI and Safety - Europe) This is to certify that this product complies with ISO/IEC Guide 22 and EN45014. It conforms to the following specifications: EMC: EN55022(1988)/CISPR-22(1985) class B EN60555-2(1995) class B...
- Page 11 Quick Installation Guide Wichtige Sicherheitshinweise (German Safety Statement) 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
-
Page 12: Warranty
IT ANY OTHER LIABILITY. Copyright Copyright © 2000 by Accton Technology Corporation. All rights reserved. No part of this document may be copied or reproduced in any form or by any means without the prior written consent of Accton Technology Corporation.
