For information on how to interpret the output on
the port analyzer, refer to its accompanying docu-
mentation.

Using the System Tools

The System Tools menu includes five administration
items:
Restart
■
Configuration
■
Upgrade
■
Spanning Tree
■
802.1p Prioritization
■

Restarting the Switch

Pressing the Restart the Switch button has the same
effect as power cycling the unit. No configuration
information will be lost. Restart the Switch if you are
experiencing problems and you want to re-establish
your Internet connection.
Figure 24 Restart Screen
Any network users that are currently accessing the
Internet will have their access interrupted while the
restart takes place, and they may need to reboot their
computers when the restart has completed and the
Switch is operational again.

Resetting and Backing Up/Restoring Configuration

Select the Configuration tab to display the Configura-
tion screen.
Figure 25 Configuration Screen
Click BACKUP to save the current configurations of
■
the Switch. You will be prompted to download
and save a file to disk.
Using the System Tools 39
