L
3
P
OCATION
ROGRAMMING THE
(4 segments of binary data)
Segment 1
Unit Options:
LED1 -
LED2 -
LED3 -
LED4 -
LED5 -
LED6 -
LED7–8
Segment 2
Door Options
LED1 -
LED2 -
LED3 -
LED4 -
LED5 -
LED6 -
LED7 -
LED8 -
Segment 3
Enabling the Schedules for the Onboard Relay:
LED1 -
LED2 -
LED3 -
LED4 -
LED5 -
LED6 -
LED7 -
LED8 -
Segment 4
Door Control Partition:
LED1 -
LED2 -
LED3 -
LED4 -
LED5 -
LED6 -
LED7 -
LED8 -
Segment 5
Weigand Format Enables:
LED1 -
"On" if Weigand Format #1 is enabled. (Default is "On")
LED2 -
"On" if Weigand Format #2 is enabled. (Default is "On")
LED3 -
"On" if Weigand Format #3 is enabled. (Default is "On")
LED4 -
"On" if Weigand Format #4 is enabled. (Default is "On")
LED5 -
"On" if Weigand Format #5 is enabled. (Default is "On")
LED6 -
"On" if Weigand Format #6 is enabled.
LED7 -
"On" if Weigand Format #7 is enabled.
LED8 -
"On" if Weigand Format #8 is enabled.
14
O
PTIONS AND
"On" if door control module is enabled for User Card Programming.
"On" if tamper is enabled.
"On" if disabling on-board zone.
Reserved.
"On" if an RTE from a scanned card is to be logged as Code Entry.
"On" if an RTE from a zone or the egress input is logged as Code Entry.
Reserved.
"On" if locking mechanism is a Maglock or Drop Bolt.
"On" if access is allowed regardless of Armed status of the system.
"On" if the door is not to be latched unlocked during an open schedule.
"On" if onboard relay only triggers during an open schedule.
"On" if onboard relay only triggers during a close schedule.
"On" if Forced Entry Alarm is logged.
"On" if access allowed without an RTE.
"On" if relay operates normally during off-schedule
"On" if driver follows Schedule 1. (Default is "On")
"On" if driver follows Schedule 2. (Default is "On")
"On" if driver follows Schedule 3. (Default is "On")
"On" if driver follows Schedule 4. (Default is "On")
"On" if driver follows Schedule 5. (Default is "On")
"On" if driver follows Schedule 6. (Default is "On")
"On" if driver follows Schedule 7. (Default is "On")
"On" if driver follows Schedule 8. (Default is "On")
"On" if door control is in Partition 1. (Default is "On")
"On" if door control is in Partition 2. (Default is "On")
"On" if door control is in Partition 3. (Default is "On")
"On" if door control is in Partition 4. (Default is "On")
"On" if door control is in Partition 5. (Default is "On")
"On" if door control is in Partition 6. (Default is "On")
"On" if door control is in Partition 7. (Default is "On")
"On" if door control is in Partition 8. (Default is "On")
D
C
P
OOR
ONTROL
ARTITIONS
(outside regular operating hours).
