Mamiya C330S Manual
Mamiya C330 Professional
file:///E|/c330s/index.html [22-10-2003 15:26:30]
Mamiya C330S & C330
This manual was adapted for the web from scans of an original
C330S manual. The scans were done by Erik Jonker. During the
conversion to the web version I made a few style changes as well
as a couple of grammer changes, mainly to make the document
more web friendly. Also thanks to Keven Fedirko for finding all
of my typos.
There are also a few additions that I made; pointing out where the
C330S differs from the original C330, and the color photos on
page 3 are of a C330, and not a C330s. (the color photos are by
Bob
Erdman).
Scans of the tables on pages 40 and 41 were difficult to read and I
am hoping to get some better scans so that I can complete them.
At the moment they are empty...eventually they should contain
the depth of field tables for the 7 lenses listed in the manual.
Hope you find this
helpful...John M. Brewer
propellerheads.
[START] |
of
Table of Contents
|
Next ->
a few

Advertisement

Table of Contents
loading

Related Manuals for Mamiya C330S

Summary of Contents for Mamiya C330S

  • Page 1 Mamiya C330S Manual Mamiya C330 Professional Mamiya C330S & C330 This manual was adapted for the web from scans of an original C330S manual. The scans were done by Erik Jonker. During the conversion to the web version I made a few style changes as well as a couple of grammer changes, mainly to make the document more web friendly.

  • Page 2: Table Of Contents

    The Mamiya C330S accepts all interchangeable lenses of the current Mamiya C series as well as all of the accessories except the single exposure attachment. file:///E|/c330s/page_01.html (1 of 2) [22-10-2003 15:26:31]...
  • Page 3 With the wide selection of all these interchangeable lenses and accessories, you can further widen your scope of photography by making the most of the unlimited versatility of Mamiya C330S offers. <- Prev | Table of Contents | Next -> file:///E|/c330s/page_01.html (2 of 2) [22-10-2003 15:26:31]...

  • Page 4: Specifications

    Mamiya C330S: Page 2 Specifications Type 6 x 6 Twin-Lens Reflex Camera with Interchangeable Lens System Picture Size 56 x 56 mm (actual picture area) Film Size 120 roll film (12 exposures), 220 roll film (24 exposures) Changeover effected by turning pressure plate Lens (standard) Mamiya/Sekor 80 mm f/2.8...

  • Page 5: Names Of Parts

    Mamiya C330S: Page 3 Names of Parts Lens clamp bracket Accessory shoe Synchro socket Parallax correcting dial M-X synchro selector Lens lock knob Shutter cocking lever Distance scale window Aperture ring Distance scale revolving knob Shutter speed ring Focusing knob fixing lever...
  • Page 6 Mamiya C330S: Page 4 Names of Parts Back cover lock button Focusing screen frame lock Back cover open knob and spool change knob (upper) Take-up spool chamber Spool change knob (lower) Start marks Eye opening for sportsfinder Film chamber Focusing hood lock screw Film pressure plate <- Prev...

  • Page 7: Lens Mounting/Removal

    Mamiya C330S: Page 5 Lens Mounting/Removal Wind up the film advance crank Place the camera so that the Insert the lens into the lens and fold it into the camera lens mount faces upward and mount so that the lens shutter body.
  • Page 8 Mamiya C330S: Page 6 Lens Mounting/Removal (cont.) Precautions 1 If the film advance crank is not kept positioned diagonally upward, (the same angle as the crank housing position), the cocking lever cannot be connected to the cocking lever on the camera body.

  • Page 9: Handling The Neck Strap

    Mamiya C330S: Page 7 Handling the Neck Strap Attaching to Camera Place the neck strap fastener over the neck strap lug on the camera body and slide it toward the hanging direction while pressing it toward the body until it clicks and locks in place...

  • Page 10: Handling The Focusing Hood

    Mamiya C330S: Page 8 Handling the Focusing Hood Raising the Focusing Hood Raise the rear of the focusing hood; it will automatically spring up into position. By pushing in the top of the Using the Magnifier sportsfinder flap (19) at the...

  • Page 11: Handling Focusing Hood

    Mamiya C330S: Page 9 Handling Focusing Hood Using the Focusing Hood as a Sportsfinder 1. By setting up the magnifier 2. After pushing down the flap 3. When using the 105mm, and pushing down the (19), also, fold down the finder...
  • Page 12 Mamiya C330S: Page 10 Handling Focusing Hood (cont.) Using the Focusing Hood as a Sportsfinder Folding the Focusing Hood 4. To return the sportsfinder 5. To fold the magnifier, simply Return the sportsfinder frame frame (17), and the flap (19) depress the base plate of the and flap;...

  • Page 13: Opening And Closing The Back Cover

    Mamiya C330S: Page 11 Opening & Closing the Back Cover To familiarize yourself with the operation of your camera, practice the shutter release before loading film. Push the back cover open knob When closing the back cover, (31) while the back cover lock...

  • Page 14: Winding And Shutter Test Without Film

    Mamiya C330S: Page 12 Winding & Shutter Test Without Film the shutter will be released. By turning the film advance crank until it stops the shutter button may be depressed again. ·Depending on Open the back cover and make sure...

  • Page 15: Before Loading Film

    Mamiya C330S: Page 13 Before Loading Film This camera accepts either 120 or 220 roll film. It has an automatic film stopper and a double exposure prevention device. Take the following steps before loading film: 1. Preventing Double 2. Adjust the film pressure...

  • Page 16: Loading Film

    Mamiya C330S: Page 14 Loading Film 1. Open the back cover and pull 2. Pull out the lower spool · If either spool change knob is out the upper spool change change knob (32), and insert a not returned to its original...
  • Page 17 Mamiya C330S: Page 15 Loading Film (cont.) 3. Pull out the leader paper of 4. Close the back cover. When Memo Holder the film and insert it into the slit closing the back cover, firmly As a reminder of the type and...
  • Page 18 Mamiya C330S: Page 16 Loading Film (cont.) 5. Turn the film advance crank number of pictures taken, the clockwise until it stops. The figure crank always stops at a diagonally 1 appears on the exposure counter upward position. In this position,...

  • Page 19: Photographing

    Mamiya C330S: Page 17 Photographing 1. After focusing, turn the shutter speed ring and set the shutter speed, then adjust the aperture of the lens by turning the aperture control knob (23). Any of three procedures mentioned above can be performed first.
  • Page 20 Mamiya C330S: Page 18 Photographing (cont.) How to Remove Film When all film frames have been exposed, the film winding stop mechanism is automatically disengaged. Remove the film after winding the remaining backing paper on the film end. Winding Up the Roll Film...

  • Page 21: Distance Scale

    Mamiya C330S: Page 19 Distance Scale A distance scale is provided on the left side (viewing the camera held for photographing). By turning the knob (13), set the distance scale to coincide with the lens used, so that the scale faces horizontally.
  • Page 22 Mamiya C330S: Page 20 Distance Scale (cont.) Replacing the Distance Scale To remove the distance scale, first, fully extend the bellow by turning the focusing knob, then remove the scale end cover by sliding it to the front. Next, detach the distance scale from the bearing, while pressing in the distance scale shaft with a pointed, fine wire.

  • Page 23: Close-Up Photography

    Mamiya C330S: Page 21 Close-up Photography Setting the Parallax Correcting Dial: By turning the parallax correcting dial (10), set the dial index to the focal lenght of the lens used. Subsequently, while the lens is being extended, the pointer will appear on the upper left portion of the focusing screen.
  • Page 24 Mamiya C330S: Page 22 Close-up Photography (cont.) When Using a 55mm or 65mm Lens: When using a 55mm or 65mm lens, set the dial (10) to 80 and attach the parallax correction plate for 55mm/65mm lenses to the focusing hood.

  • Page 25: Changing The Focusing Hood

    Mamiya C330S: Page 23 Changing the Focusing Hood The focusing hood can be replaced with various finders available for this camera as optional accessories. Removing the Focusing Hood Attaching the Focusing Hood Turn the focusing hood lock screw Match the grooves on the hood's...

  • Page 26: Changing The Magnifier

    However, before making a purchase, test the diopter lens at your Mamiya dealer to make sure it matches your eye. Changing Method 1. Raise the focusing hood; then depress the sportsfinder flap and frame.

  • Page 27: Changing The Focusing Screen

    Mamiya C330S: Page 25 Changing the Focusing Screen Various types of focusing hoods are available to meet individual needs or preferences. Removing the Focusing Attaching the Focusing After checking to make sure the Screen Screen screen is correctly fitted into...

  • Page 28: Flash Photography

    Mamiya C330S: Page 26 Flash Photography When a falsh unit is used for photographing, connect the synchro cord to the synchro socket (2). When using an electronic flash unit, set the M-X synchro selector on X to synchronize all shutter speeds.
  • Page 29 Mamiya C330S: Page 27 Handling the 105mm f/3.5 DS Lens The 105mm f/3.5 DS lens is equiped with diaphragms on the viewing lens, thus enabling you to observe the depth-of-field on the focusing screen. In addition, this lens-shutter has a built in self- timer.
  • Page 30 Mamiya C330S: Page 28 Handling the 105mm f/3.5 DS Lens (cont.) The M-X synchro selector be moved before or after cocking the shutter. After finishing photographing with the self-timer, return the selector to the X position. If left on the V position, the self-timer will be activated for the next picture.

  • Page 31: Multiple Exposures

    Mamiya C330S: Page 29 Multiple Exposures/Precautions on Shutter Ops. Turn the multiple exposure dial Precautions on Shutter (28) and set the word 'MULTI' to Operations In any of the following situations, the red dot, then the double the safety mechanism prevents the...
  • Page 32 Mamiya C330S: Page 29 <- Prev Table of Contents Next -> file:///E|/c330s/page_29.html (2 of 2) [22-10-2003 15:26:40]...
  • Page 33 Mamiya C330S: Page 30 Precautions on Shutter Operations (cont.) 250mm f/6.3 and 80mm f/3.7 lenses. Shutters of these lenses have no For certain lens-shutter self-cocking system, requiring assemblies (such as the formar the shutter to be set manually 80mm f/3.7 lens), the release after each film advance.
  • Page 34 Mamiya C330S: Page 31 Mamiya-Sekor Lenses 55mm f/4.5 65mm f/3.5 80mm f/2.8 105mm f/3.5DS 135mm f/4.5 Super 180mm f/4.5 250mm f/6.3 <- Prev Table of Contents Next -> file:///E|/c330s/page_31.html [22-10-2003 15:26:41]...
  • Page 35 Mamiya C330S: Page 32 Mamiya-Sekor Lenses (cont.) Close-Up Capabilities Filter Lens Hood Shortest Picture Minimum Lens Composition Diameter Diameter Distance Subject Angle Aperture (mm) (mm) from Film to Coverage Subject 9 element 9 1/2 in. 2 17/32 in. 55mm f/4.5 70°30'...

  • Page 36: Accessories

    Mamiya C Professional type. while focusing, due to a certain interchangeable lenses for the light condition, incline the side Mamiya C Professional or to plate to eliminate the annoying · To attach a filter to a lens of store accessories.
  • Page 37 Mamiya C330S: Page 34 Accessories (Focusing Screens) Type A: Matte Entirely matted with Fresnel lens. For general photography. Suitable for any focal length lens. Type A2: Matte for wide- angle lens Entirely matted with Fresnel lens. Clear view-field is objeained...
  • Page 38 Mamiya C330S: Page 34 <- Prev Table of Contents Next -> file:///E|/c330s/page_34.html (2 of 2) [22-10-2003 15:26:42]...
  • Page 39 Mamiya C330S: Page 35 Accessories (cont.) Nine types of lenses are CdS Magnifying Hood CdS Porrofinder provided from +2.5 to -2 diopter This is a spot metering finder This is a Porrofinder with built- (each diopter is +2.5, +2.0, +1.5, with a CdS exposure meter in CdS exposure meter.
  • Page 40 Mamiya C330S: Page 35 <- Prev Table of Contents Next -> file:///E|/c330s/page_35.html (2 of 2) [22-10-2003 15:26:42]...
  • Page 41 Mamiya C330S: Page 36 Accessories (cont.) A trigger-type design is adopted (4a) (4b) Grip Holder Grip Holder (for for this grip, interlocked with The grip holder is a very Mamiya C330 and RZ/RB) the camera shutter release convenient accessory for hand The camera shutter can be button.
  • Page 42 Mamiya C330S: Page 37 Accessories (cont.) Pistol Grip Model 2 (for Paramender Model 2 Focusing Knob Adapter Mamiya C330 and RZ/RB) This is a parallax-correcting DSF-2/DSM-2 (for Mamiya A trigger-type shutter release instrument used between the C330S and C220f) button is interlocked with the camera base and a tripod.
  • Page 43 Mamiya C330S: Page 38 Accessories (cont.) so it is highly convenient for As the bracket can be set to Quick-Show Model 2 close-up work and daylight three different angles, the Auto A two piece set in which one synchro flash.
  • Page 44 In addition to the Camera and Case effective shock absorption and Standard Lens set, this The Mamiya Custom Case is a sufficient protection of the convenient, heavy-duty camera smartly portable, luggage-type equipment. case holds interchangeable aluminum case.

  • Page 45: Depth Of Field Tables

    Mamiya C330S: Page 40 Depth of Field Tables 55mm f/4.5 Distance (in feet) " Aperture 2' 9 " 2' 4 " 1' 10 " 1' 5 " " " 4' 4 " 5' 9" 29' 1" 14' 11" 30' 1"...
  • Page 46 Mamiya C330S: Page 40 12" 6 " 8' 10 " 4' 8 " 1' 5 " 21' 4" 3' 10" 2' 11" 6' 5 " 71' 10 " 50' 9 " 4' 2 " 3' 1 " 18' 8 "...
  • Page 47 Mamiya C330S: Page 41 Depth of Field Tables (cont.) 135mm f/4.5 Distance (in feet) Aperture 13' 9 " 3' 11 " 3' 5 " 2' 11 " 25' 4 " 9' 5 " 6' 9" 5' 10" 159' 3 "...
  • Page 48 Mamiya C330S: Page 41 Distance (in feet) Aperture 6' 11 " 135' 44' 11" 28' 2" 19' 2" 14' 7" 11' 9" 9' 10" 7' 11" 412' 385' 131' 56' 5" 32' 1" 20' 10" 15' 5" 12' 3" 10' 2"...

  • Page 49: System Chart For Mamiya C330S

    Mamiya C330S: Page 42 System Chart for Mamiya C330S <- Prev Table of Contents | [END] file:///E|/c330s/page_42.html [22-10-2003 15:26:46]...
