Page 1: User Manual
iQ SERIES USER MANUAL iQ 10, iQ 10P, iQ 10C AND iQ 10PC MODELS... -
Page 3: Table Of Contents
CONTENTS Introduction Unpacking Connectors/Cabling Amplification & Power Handling Operation Equalisation Arraying Dimensions Rigging & Suspension General Safety Advice Skeletal Flying SECUR – ET VPC Pole Clamp SECUR ET – VEB Eyebolt Suspension Truss Performance Data Technical Specifications System Configuration & OEM Controllers Bi-amp System Parameters (iQ 10 &... -
Page 4: Introduction
EQ amongst other features. Tannoy’s, iQ 10 is a weatherproof skeletal design suitable for use both indoors and out, where the compact and lightweight unit allows for flying into tight corners. The iQ 10 has two Speakon™... -
Page 5: Amplification & Power Handling
For optimal performance, the iQ 10 has been designed to operate in conjunction with the Tannoy TDX1 & TDX2 System Controllers, and iQ 18B bass unit for extended bass performance. The TDX controllers have been factory preset to provide the recommended eq, crossover points, and overall system balance. -
Page 6: Equalisation
6. Equalisation Over equalisation can reduce system headroom, and introduce phase distortion resulting in greater problems than cures. If equalisation is required then it should be applied gently and smoothly. Violent equalisation will be detrimental to the overall sound quality. 7. -
Page 7: Dimensions
8. Dimensions IQ 10 & iQ 10P... - Page 8 iQ 10C & iQ 10PC 540.0 680.0 508.0...
-
Page 9: Rigging & Suspension
Rigging & Suspension General Safety Advice The Tannoy Professional hardware covered in this guide has been designed to offer quick, simple, cost effective and secure solutions for mounting specific Tannoy Professional loudspeakers. This hardware has been designed and manufactured with a high safety load factor for its specific role. -
Page 10: Skeletal Flying
The following optional flying kit is available: Skeletal Flying The iQ 10 ‘skeletal’ enclosure include a yoke as standard. The unit can be flown from a flying bar or relevant rigging via the flying loop, by utilising a Tannoy SECUR-ET VPC hook clamp or equivalent. -
Page 11: Secur - Et Vpc Pole Clamp
M10 x 50mm Screw M10 Nyloc Nut (Black) SECUR ET – VEB Eyebolt The Tannoy iQ 10C & iQ 10PC loudspeakers can be flown with high quality VEB M10 eyebolts with collar to BS4278:1984. The loudspeakers are equipped with internal steel braces, which also double as the flying points, and accept VEB M10 eyebolts. - Page 12 Suspension Truss The iQ Suspension Truss is a "semi-custom" product line that is built to order. Please contact your Tannoy or ATM Fly-Ware dealer with the loudspeaker model numbers along with the array application. Full assembly instructions for the iQ Suspension Truss accompany the product.
- Page 13 Typical Suspension Truss applications – 2 x iQ 10C 2 x iQ 10C & 2 x iQ 18B...
-
Page 14: Performance Data
Performance Data FREQUENCY RESPONSE (iQ 10) Unprocessed Anechoic Frequency Response, 1 watt @ 1 metre on axis System Frequency Response (with system controller) @ 1m on axis FREQUENCY RESPONSE – Midrange (iQ 10) - Page 15 FREQUENCY RESPONSE – High Frequency (iQ 10) INPUT IMPEDANCE – Midrange (iQ 10)
- Page 16 INPUT IMPEDANCE – High Frequency (iQ 10) FREQUENCY RESPONSE – Passive (iQ 10P) System Frequency Response @ 1m on axis (iQ 10P)
- Page 17 10P INPUT IMPEDANCE A comprehensive range of measurements including off axis frequency response curves, octave & third octave polar diagrams (single & two cabinet arrays) and beamwidth plots as well as Ease™ data can be downloaded from http://www.tannoy.com/...
-
Page 18: Technical Specifications
- or can be found in the IQ 10 user manual Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the publish which Tannoy reserves the right to alter without prior notice. -
Page 19: Bi-Amp System Parameters (Iq 10 & Iq 10C)
12. System Configurations & OEM Controllers Passive or Biamp? The iQ 10 is supplied as standard for bi-amp operation, therefore there is no internal passive crossover network between the mid & hf units. The Bi-amp controller parameters below must be adhered to for optimum performance. An optional iQ 10P (passive version) can be ordered if (part no. -
Page 20: Passive System Parameters (Iq 10P & Iq 10Pc)
Passive System Parameters (iQ 10P & iQ 10PC) With the vast array of digital loudspeaker management systems available it is inevitable that the user may opt to use a controller other than the TDX1 or TDX2 as part of a large scale integrated system. Use the parameters in the table below for optimised performance:- Parameter Unit/Name... -
Page 21: Warranty
Warranty No maintenance of the iQ 10 loudspeaker is necessary. All Tannoy professional loudspeaker products are covered by a 5 year warranty from the date of manufacture subject to the absence of misuse, overload or accidental damage. Claims will not be considered is the serial number has been altered or removed. -
Page 22: Declaration Of Conformity
15. Declaration of Conformity The following apparatus is/are manufactured in the United Kingdom by Tannoy Ltd of Rosehall Industrial estate, Coatbridge, Scotland, ML5 4TF and conform(s) to the protection requirements of the European Electromagnetic Compatibility Standards and Directives relevant to Domestic Electrical Equipment. The apparatus is... - Page 24 T: 00 1 (519) 745 1158 E: inquiries@tannoyna.com Tannoy Deutschland T: 00 49 (180) 1111 881 anfragen@tannoy.com Tannoy France T: 00 33 (0)1 7036 7473 E: ventes@tannoy.com Tannoy adopts a policy of continuous improvement and product specification is subject to change.
