VMware® Lab Manager User's Guide

Reviewing the Lab Manager User Interface

The Lab Manager Web console has a navigation pane on the left and a main display area
on the right.
The navigation pane provides access to major concepts and operations:
My Lab Manager
Build and Deploy
Monitor
Manage (administrator operations only)
Support (administrator operations only)
The main display area shows configuration, virtual machine, machine template, server,
and system administration information in table format. This area also displays data in
tabbed folders.
Default Landing Page
The default landing page is the Overview page.
N You must enable SupportLink if you want to view all statistics. See "Reviewing
OTE
the SupportLink Tab" on page 149.
The Performance Summary column includes these statistics:
Total Slots – Number of reserved spaces across all virtual machines on the
Managed Server systems.
Slots Used – Number of deployed machines.
Slots Available – Difference between Total Slots and Slots Used.
Maximum Memory – Physical memory of the Managed Server systems.
Total Deployments Over Time – Sum of all deployed virtual machines since the
installation of Lab Manager.
Configurations in Library – Number of virtual machine configurations stored in
the configuration library.
Total VMFS Disk Space – Sum of the disk space in the VMware Virtual Machine
File System (VMFS) storage.
VMs under management – Number of virtual machines (except routers) under
Lab Manager control.
