VMware® Lab Manager User's Guide

Viewing the Deployed Machines on a Managed Server

You can view the deployed machines on a specific Managed Server system. To view all
deployed machines across Managed Server systems, see "Monitoring Deployed
Machines" on page 110.
To view the deployed machines on a single Managed Server system
1 In the left pane, click Servers.
2 Move the pointer over the Managed Server name, and choose Deployed Machines
from the menu.
Review these elements of the page:
Console – Provides access to the virtual machine console through the thumbnail
icon.
Machine Name – Provides a mouseover menu to view the virtual machine console
or undeploy the virtual machine.
Status – Indicates whether the virtual machine is deployed or in the midst of an
operation.
Configuration – Specifies whether the virtual machine is a template (indicated by
a dash) or part of a configuration.
IP Address – Provides the IP address of the virtual machine or specifies DHCP.
External IP – Provides the external IP address for the virtual machine if it runs in
fenced mode. For details about fenced mode, see Appendix
on page 171.
Template – Shows the template that serves as the basis of the virtual machine. This
is useful when you plan to retire a template and need to evaluate its usage. When
a template is removed for a configuration or is deployed, a dash appears in the
column.
Managed Server– Displays the Managed Server name.
Deployed By – Indicates the person who deployed the virtual machine.
Sharing – Indicates whether the configuration is accessible for others to use.
Date Deployed – Displays the date and time of deployment.
Filter – Displays a subset of the total number of configurations. Enter text that
appears in the attributes of the machines you want to view.
122
C, "Network Fencing,"
