Appendix
Appendix
Nothing is displayed and the
touch panel keys cannot be
used.
There is no response when the
touch panel key are touched or
a different key responds.
Problems in the AV screen
Symptom
CD or DVD playback is not pos-
sible.
The screen is covered with the
caution message and the video
cannot be shown.
No video output from connected
equipments.
No video output from connected
iPod.
The audio or video skips.
No sounds are produced.
The volume level will not rise.
The icon 9 is displayed, and op-
eration is not possible.
The picture stops (pauses) and
the navigation system cannot be
operated.
158
En
The setting for the rear view camera
is incorrect.
The shift lever was placed in [R]
when the rear view camera was not
connected.
The touch panel keys deviate from
the actual positions that respond to
your touch for some reason.
Cause
The disc is inserted upside down.
The disc is dirty.
The disc is cracked or otherwise da-
maged.
The files on the disc are an irregular
file format.
The disc format cannot be played
back.
The loaded disc is a type this system
cannot play.
The parking brake lead is not con-
nected or applied.
The parking brake interlock is acti-
vated.
[AV1 Input] or [AV2 Input] setting
is incorrect.
The connection of the USB interface
cable for iPod is incorrect.
The navigation system is not firmly
secured.
Cables are not connected correctly.
The system is performing still, slow
motion, or frame-by-frame playback
with DVD-Video.
The system is paused or performing,
fast reverse or forward during the
disc playback.
The operation is not compatible
with the video configuration.
The reading of data is impossible
during disc playback.
Select the appropriate setting for the rear
view camera.
Press MAP button, and then press MENU
button to return to the "Top Menu" and then
select the correct polarity setting for [Back
Camera]. (Page 136)
Perform the touch panel calibration. (Page
136)
Action (See)
Insert the disc with the label upward.
Clean disc.
Insert a normal, round disc.
Check the file format.
Replace disc.
Check what type of disc it is. (For more cau-
tions about handling each type of media,
refer to Page 171.)
Connect the parking brake lead correctly, and
apply the parking brake.
Park your vehicle in a safe place and apply
the parking brake.
Please read the following page and establish
the setting correctly. (Page 120)
Connect both USB plug and RCA cable side.
(If only either connection has made, iPod will
not works properly.) (Page 16)
Secure the navigation system firmly.
Connect the cables correctly.
There is no sound during still, slow motion, or
frame-by-frame playback with DVD-Video.
For the media other than music CD (CD-DA),
there is no sound on fast reverse or forward.
This operation is not possible. (For example,
the DVD playing does not feature that angle,
audio system, subtitle language, etc.)
After touching g once, start playback once
more.
