Systems with After Power Loss set to ON in F10 BIOS will remain ON and proceed to boot
to the operating system. Systems with After Power Loss set to OFF in F10 BIOS will shut down
after the ME obtains system memory.
This option must be set to Always for Wake-On-ME to function.
See "Appendix B: Power / Sleep / Global States Explained" on page 29
sleep/power states and an example reading of the ME Power State During Host Sleep State
chart.
See "Appendix C: Wake-On-ME Explained" on page 30
c. Skip LAN Power Well.
Default Setting = WOL_EN Pin, Recommended Setting = WOL_EN Pin
This option defines which power well is connected to the NIC. This option in the HP Compaq
dc7700 Business PC is defined by hardware routing and is not subject to firmware or software
change.
d. Skip ME Visual LED Indicator.
Default Setting = Off, Recommended Setting = Off
This option enables or disables the LED indicator on a system board to indicate an active ME.
The purpose of this option is to warn that the ME and memory subsystem is powered and you
must remove AC power before removing DIMMs. The HP Compaq dc7700p does not implement
the ME LED. There is a separate Vaux LED located next to the DIMM slots that also indicates a
powered system board.
e. Select Return to previous menu.
11. Return to previous menu to exit the MEBx Setup and save AMT configuration. The system will display
an Intel ME Configuration Complete message and reboot.
After the ME Configuration is complete, you can configure the AMT on the next boot.
12. Press Ctrl-P during POST to enter MEBx Setup again.
13. Type the MEBx password.
for an explanation of
for an explanation of Wake-On-ME.
9
