HP dc72 - Blade Workstation Client Setup And Configuration Manual page 11

c. Select IP Address, and then type a static address.
Default Setting = 10.0.0.2, Recommended Setting = Network Dependent
Example: 192.168.0.1
Make sure all AMT systems have a unique static IP address if more than one system is on the
same network. Multiple systems sharing the same static IP address can lead to network collisions,
which will cause the systems to not respond correctly.
d. Select Subnet Mask, and then type a subnet mask.
Default Setting = 255.255.255.0, Recommended Setting = Network Dependent
Example: 255.255.255.0
e. Select Default Gateway Address, and then accept the default and press Enter.
Default Setting = 0.0.0.0, Recommended Setting = Network Dependent,
Leave as 0.0.0.0 if this option is not needed.
f. Select Preferred DNS Address, and then accept the default value and press Enter.
Default Setting = 0.0.0.0, Recommended Setting = Network Dependent
Leave as 0.0.0.0 if this option is not needed.
g. Select Alternate DNS Address, and then accept the default value and press Enter.
Default Setting = 0.0.0.0, Recommended Setting = Network Dependent
Leave as 0.0.0.0 if this option is not needed.
h.Select Domain Name, and then type a domain name
Default Setting = none, Recommended Setting = Network Dependent
The domain name is blank by default. If not populated, then the default domain of
"Provisionserver" is used when connecting to a Setup and Configuration Server.
If the name of the S&CS is not "Provisionserver" and the domain name is blank, then an alias
must be set up in the DHCP server to redirect the connection for "Provisionserver" to the proper
S&CS domain name.
If the Domain Name field is populated, that is the domain used. However, if there is no
response after four DNS queries to the named domain, then that domain name is no longer used
and the default "Provisionserver" is used.
Skip Provisioning Server.
17.
Default Setting = 0.0.0.0, Recommended Setting = Network Dependent
This option is used in Enterprise mode when an Intel AMT Setup and Configuration (Provisioning)
server is available. This option disappears once SMB mode is set in step 18.
11
