- Page 1 ® Intel SBT2 Server Board Product Guide ® A Guide for Technically Qualified Assemblers of Intel Identified Subassemblies/Products Order Number: A28554-001...
- Page 2 Intel assumes no responsibility for any errors that may appear in this document. Intel makes no commitment to update nor to keep current the information contained in this document. No part of this document may be copied or reproduced in any form or by any means without prior written consent of Intel.
-
Page 3: Table Of Contents
Contents 1 Description Server Board Features ......................7 Back Panel Connectors ....................8 Server Board Connector and Component Locations ............ 9 Processor ........................10 Memory ........................10 Add-in Board Slots ......................11 Video...........................12 SCSI Controller ........................12 IDE Controller........................12 Network Controller.......................13 Network Teaming Features..................13 Keyboard and Mouse ......................15 ACPI ...........................15 Security ..........................16... - Page 4 Starting the SSU ......................45 Customizing the SSU....................47 Launching a Task .......................47 SEL Manager Add-in ....................48 SDR Manager Add-in....................48 FRU Manager Add-in....................49 Exiting the SSU ......................50 FRUSDR Load Utility......................50 When to Run the FRUSDR Load Utility...............50 What You Need to Do....................50 How You Use the FRUSDR Load Utility..............51 Upgrading the BIOS ......................53 Preparing for the Upgrade ..................53...
- Page 5 5 Technical Reference Server Board Jumpers......................67 General Procedure to Change Jumper Setting ............68 CMOS Jumper......................68 Password Jumper .......................69 6 Regulatory and Integration Information Product Regulatory Compliance ..................71 Product Safety Compliance ..................71 Product EMC Compliance...................71 Product Regulatory Compliance Markings ..............71 Electromagnetic Compatibility Notices.................72 USA ..........................72 FCC Verification Statement ..................73 ICES-003 (Canada) ....................73...
- Page 6 Tables Server Board Features ....................7 Software Security Features ..................17 Configuration Utilities....................33 Hot Keys........................33 CPU Clock Speed (7C10) Jumper ................67 Configuration Jumper (3N7)..................67 Power Usage Worksheet 1 ..................78 Power Usage Worksheet 2 ..................79 Contents...
-
Page 7: Description
Server Board Features Table 1. Server Board Features Feature Description ® ® Processor Installed: Up to two Intel Pentium III Xeon processors. You must use an ® Intel boxed processor with one of the following product codes: BX80526KB866256, BX80526KB001256 Memory (DRAM) Four 72 bit sockets for 168-pin, gold contact, 133 MHz, 3.3V, PC/133 compliant,... -
Page 8: Back Panel Connectors
Back Panel Connectors OM10424 USB connectors Serial port 2 connector C. Serial port 1 connector D. NMI switch Keyboard connector Mouse connector G. Parallel port connector H. Video connector Network connector Figure 1. Back Panel Connectors Description... -
Page 9: Server Board Connector And Component Locations
Server Board Connector and Component Locations OM10423 Fan connector Q. Floppy drive connector Fan connector R. Fan connector C. CPU speed jumper block Fan connector D. Primary processor Configuration jumper block Secondary processor U. Reset switch connector DIMM slot 4 SE SCSI connector G. -
Page 10: Processor
NOTE Use DIMMs that have been tested for compatibility with the server board. Contact your sales representative or dealer for a current list of approved memory modules. Check the Intel Customer Support website for the latest tested memory list: http://support.intel.com/support/motherboards/server/SBT2/compat.htm... -
Page 11: Add-In Board Slots
Add-in Board Slots The server board has three full length and one half length standard PCI (PCI-33/32 bit) connectors. PCI features: Bus speed up to 33 MHz 32 bit memory addressing 5 V signaling environment Burst transfers of up to 133 Mbps 8, 16, or 32 bit data transfers Plug and Play ready Parity enabled... -
Page 12: Video
Video The system has an integrated ATI Rage IIC 64 bit high-performance SVGA subsystem that supports the following: BIOS compatibility with VGA, EGA, CGA, Hercules Graphics, and MDA 4 MB of 10 ns onboard Synchronous Graphics Memory (SGRAM) Pixel resolutions up to 1280 X 1024 Analog VGA monitors (single and multiple frequency, interlaced and noninterlaced) with a maximum vertical retrace noninterlaced frequency of 100 Hz. -
Page 13: Network Controller
To ensure EMC product regulation compliance, the end system must be used with a shielded LAN cable. The server board includes a 10BASE-T/100BASE-TX network solution based on the Intel 82559 single chip Fast Ethernet PCI Bus Controller. As a PCI bus master, the controller can burst data at up to 132 MB/s. - Page 14 General Configuration Notes 1. Windows NT versions prior to 4.0 don’t support Adapter Teaming options. 2. Adapter Teaming options require NT 4.0 with Service Pack 4.0 or Service Pack 3.0 and Hotfix. 3. In Windows NT, teaming options cannot be implemented on adapters that have been configured for VLANs.
-
Page 15: Keyboard And Mouse
Cisco Fast EtherChannel Fast EtherChannel (FEC) is a performance technology developed by Cisco to increase your server’s throughput. Unlike ALB, FEC can be configured to increase both transmission and reception channels between your server and switch. FEC works only with FEC-enabled switches, such as the Catalyst 5000 series. -
Page 16: Security
Security ® To help prevent unauthorized entry or use of the server, Intel Server Control server management software monitors the system intrusion switch. Security with Mechanical Locks and Monitoring If installed, you can activate the chassis intrusion alarm switch. When the side door is opened, the switch transmits an alarm signal to the server board, where BMC firmware and server management software process the signal. -
Page 17: Software Security Features
May enter either password to boot the server if Password on Boot is enabled in either the BIOS Setup or SSU. May enter either password to exit secure mode. Secure Mode Configure and enable the secure boot mode by using the SSU. When secure mode is in effect: You can boot the server and the operating system will run, but you must enter the user password to use the keyboard or mouse. - Page 18 Table 2. Software Security Features (continued) Feature Description Set a time out period so Specify and enable an inactivity time out period of from 1 to 120 minutes. that keyboard and mouse If no keyboard or mouse action occurs for the specified period, attempted input are not accepted keyboard and mouse input will not be accepted.
-
Page 19: Upgrading
2 Upgrading Tools and Supplies Needed Phillips (cross head) screwdriver (#1 bit and #2 bit) Jumper removal tool or needle nosed pliers Pen or pencil Antistatic wrist strap and conductive foam pad (recommended) Cautions These warnings and cautions apply throughout this chapter. Only a technically qualified person should configure the server board. -
Page 20: Memory
DIMMs must be installed in order from slot 1 to slot 4, no empty slots between installed DIMMs. Slot 1 is the slot farthest from the processors. Installed DIMMs must be the same speed and must all be registered. For a list of supported memory, call your service representative or visit the Intel Support website: http://support.intel.com/support/motherboards/server/SBT2/compat.htm OM10426 Figure 3. -
Page 21: Processors
Intel Customer Support website: http://support.intel.com/support/motherboards/server/SBT2 Heat sink must be appropriate: You must use an Intel boxed processor with one of the following product codes: BX80526KB866256, BX80526KB1000256, BX80526KB8001M ESD and handling processors: Reduce the risk of electrostatic discharge (ESD) damage to the processor by doing the following: (1) Touch the metal chassis before touching the processor or server board. -
Page 22: Adding Or Replacing A Processor
The second processor must be compatible with the first processor (within one stepping, same voltage, see the Intel support website for specifics). 1. Observe the safety and ESD precautions at the beginning of this chapter and the additional cautions given here. -
Page 23: Remove Auxiliary Fans
4. Remove the auxiliary cooling fans from their brackets. Do not disconnect them from the board. OM10419 Fans Figure 5. Remove Auxiliary Fans SBT2 Server Board Product Guide... -
Page 24: Remove Bottom Epac
5. Remove the bottom piece of foam epac. It lifts straight out; do not tilt it. OM10616 Epac Figure 6. Remove Bottom Epac Upgrading... -
Page 25: Disengage Retention Wires
6. Lift the plastic ejectors on the processor or termination card to disengage the retention wires. OM10617 Retention wires Ejectors Figure 7. Disengage Retention Wires 7. Pull the processor or termination card from the system. SBT2 Server Board Product Guide... -
Page 26: Installing A Processor
8. Clip two plastic ejectors (Figure 8, A) to the new processor (Figure 8, B). 9. Slide the new processor into the processor slot. Push down firmly, with even pressure on both sides of the top, until the processor is seated in the processor connector on the server board. OM10413 Ejectors Processor... -
Page 27: Engage Retention Wires
10. Move the retention wires over the plastic ejectors to hold the processor in place. OM10415 Ejectors Retention wires Figure 9. Engage Retention Wires 11. After you have installed the processor(s), you must configure the speed jumpers. See the CPU Clock Speed table on page 67. -
Page 28: Install Bottom Epac
12. Place the bottom piece of epac into the chassis as shown. Make sure it is fully seated in the chassis. If it isn’t, the cover will not fit properly. NOTE The epac drops straight in. Do not tilt it in; trying to straighten in will break the epac. -
Page 29: Install Fans
13. Clip the fans into place. Make sure that the label on the fan faces the air holes in the chassis (away from the processors). OM10419 Fans Figure 11. Install Fans SBT2 Server Board Product Guide... -
Page 30: Install Top Epac
14. Place the top piece of foam epac into the chassis as shown. OM10420 Epac Figure 12. Install Top Epac Upgrading... -
Page 31: Replacing The Back Up Battery
Replacing the Back up Battery The lithium battery on the server board powers the real time clock (RTC) for up to 10 years in the absence of power. When the battery starts to weaken, it loses voltage, and the server settings stored in CMOS RAM in the RTC (for example, the date and time) may be wrong. - Page 32 Upgrading...
-
Page 33: Configuration Software And Utilities
3 Configuration Software and Utilities This chapter describes the Power On Self Test (POST) and server configuration utilities. The table below briefly describes the utilities. Table 3. Configuration Utilities Utility Description and brief procedure Page BIOS Setup If the system does not have a diskette drive, or the drive is disabled or misconfigured, use Setup to enable it. -
Page 34: Power-On Self Test (Post)
Power-On Self Test (POST) Each time you turn on the system, POST starts running. POST checks the server board, processor, memory, keyboard, and most installed peripheral devices. During the memory test, POST displays the amount of memory that it is able to access and test. The length of time needed to test memory depends on the amount of memory installed. -
Page 35: Using Bios Setup
Using BIOS Setup This section describes the BIOS Setup options. Use Setup to change the server configuration defaults. You can run Setup with or without an operating system being present. Setup stores most of the configuration values in battery backed CMOS; the rest of the values are stored in flash memory. -
Page 36: Setup Menus
Setup Menus Press Get general help <F1> or <Alt+H> Move between menus Go to the previous item Go to the next Item Change the value of an item + or - Select an item or display a submenu <Enter> Leave a submenu or exit Setup <Esc>... -
Page 37: Primary Master/Slave Submenu
Primary Master/Slave Submenu Feature Choices Description Type User User defines parameters Auto Auto type selection CD ROM CD ROM is installed ATAPI Removable Removable disk is installed Multimode Transfers Disabled Enabled LBA Mode Control Disabled Enables large block addressing Enabled 32 Bit I/O Disabled Enabled... - Page 38 Memory Reconfiguration Submenu Feature Choices Description DIMM Group #1 This field is informational only. Status DIMM Group #2 This field is informational only. Status DIMM Group #3 This field is informational only. Status DIMM Group #4 This field is informational only. Status Clear DIMM Press <Enter>...
-
Page 39: Peripheral Configuration Submenu
Peripheral Configuration Submenu Feature Choices Description Serial Port 1 Disabled 3F8, IRQ 3 3F8, IRQ 4 2F8, IRQ 3 2F8, IRQ 4 3E8, IRQ 3 3E8, IRQ 4 2E8, IRQ 3 2E8, IRQ 4 Auto Auto forces BIOS to configure the port. Serial Port 2 Disabled 3F8, IRQ 3... - Page 40 PCI Device Submenu Feature Choices Description PCI IRQ 1-14 Disabled Configure which IRQ resource to allocate for 14 interrupt Auto Select signal in PCI bus. IRQ3 IRQ4 IRQ5 IRQ6 IRQ7 IRQ9 IRQ10 IRQ11 IRQ12 Option ROM Submenu Feature Choices Description On Board SCSI Enabled Enables option ROM scan of the onboard SCSI chip.
-
Page 41: Security Menu
Security Menu You can make the following selections on the Security Menu itself. Enabling the Supervisor Password field requires a password for entering Setup. The passwords are not case-sensitive. Feature Choices Description Supervisor Password is Clear Status only; user cannot modify. User Password is Clear Status only;... -
Page 42: System Hardware Menu
System Hardware Menu You can make the following selections on the Server Menu itself. Feature Choices Description Wake On Event Enters submenu. AC-LINK Stay Off Sets what happens when AC power is lost and restored. Last State Stay Off means the server will not power up. Last State Power On means the server will power up if it was powered when AC was lost. -
Page 43: Exit Menu
ATAPI CD-ROM Drive Attempts to boot from an ATAPI CD-ROM drive. Hard Drive Attempts to boot from a hard drive device. Intel UNDI, PXE-2.0 Attempts to boot from a network connection. Requires the presence of a PXE server. Hard Drive Submenu... -
Page 44: Using The System Setup Utility
Using the System Setup Utility The System Setup Utility (SSU) is on the Server Board Resource software CD shipped with the server board. The SSU provides a graphical user interface (GUI) over an extensible framework for server configuration. The SSU framework supports the following functions and capabilities: allows viewing and clearing of the system’s critical event log allows the viewing of the system management FRU information allows the viewing of the system management SDR repository... -
Page 45: Running The Ssu Remotely Via An Emergency Management Card
Running the SSU Remotely via an Emergency Management Card Using graphical hardware redirection via the emergency management card 2, you can see the SSU Console in VGA graphics mode, control the mouse, and control the keyboard from a local system connected to a remote server by a network or modem. -
Page 46: System Setup Utility Main Window
Figure 13. System Setup Utility Main Window Configuration Software and Utilities... -
Page 47: Customizing The Ssu
Customizing the SSU The SSU lets you customize the user interface according to your preferences. The AF sets these preferences and saves them in the AF.INI file so that they take effect the next time you start the SSU. There are four user customizable settings: Color - this button lets you change the default colors associated with different items on the screen with predefined color combinations. -
Page 48: Sel Manager Add-In
SEL Manager Add-in Clicking on the SEL Manager Add-in task brings up the Server Event Log (SEL) viewer. You can load and view the current SEL data stored in the BMC, save the currently loaded SEL data to a file, view previously saved SEL data, or clear the SEL. -
Page 49: Fru Manager Add-In
The SDR Viewer has the following menus: File Menu The File menu has the following options: Open Open a SDR data file for viewing. Save As… Save the currently loaded SDR data to a file. Exit Quits the SDR Viewer. SDR Menu The SDR menu has the following options: Properties Displays SDR information from the BMC. -
Page 50: Exiting The Ssu
Exiting the SSU Exiting the SSU causes all windows to close. 1. Exit the SSU by opening the menu bar item File in the SSU Main window. 2. Click on Exit. Highlight Exit, and press <Enter>. FRUSDR Load Utility The Field Replacement Unit (FRU) and Sensor Data Record (SDR) Load Utility is a DOS-based program used to update the server management subsystem’s product level FRU, SDR, and the SM BIOS (SMB) nonvolatile storage components (EEPROMs). -
Page 51: How You Use The Frusdr Load Utility
How You Use the FRUSDR Load Utility † This utility is compatible with ROM-DOS Ver. 6.22, MS-DOS Ver. 6.22, and later versions. The utility accepts CFG, SDR and FRU load files. The executable file for the utility is frusdr.exe. The utility requires the following supporting files: one or more .fru files describing the system’s field replaceable units a .cfg file describing the system configuration... - Page 52 Displaying SM BIOS Area The SM BIOS area is displayed in ASCII format when the field is ASCII or as a number when the field is a number. Each SM BIOS area displayed is headed with the SM BIOS area designated name.
-
Page 53: Upgrading The Bios
Updating the SDR Nonvolatile Storage Area After the utility validates the header area of the supplied SDR file, it updates the SDR repository area. Before programming, the utility clears the SDR repository area. The SDR file is loaded via the .cfg File. Then the utility filters all tagged SDRs depending on the product configuration set in the Configuration File. -
Page 54: Creating A Bootable Floppy Diskette
You can upgrade to a new version of the BIOS using the new BIOS files and the BIOS upgrade utility, PHLASH.EXE. You can obtain the BIOS upgrade file and the PHLASH.EXE utility through your computer supplier or from the Intel Customer Support website: http://support.intel.com/support/motherboards/server/SBT2... -
Page 55: Upgrading The Bios
6. Insert the bootable floppy disk into drive A. 7. To extract the BIOS.EXE file to the floppy disk, change to the temporary directory that holds the BIOS.EXE file and type: BIOS A: 8. Press <Enter>. 9. The floppy disk now holds the BIOS upgrade and recovery files. Upgrading the BIOS 1. -
Page 56: Changing The Bios Language
You can use the BIOS upgrade utility to change the language the BIOS uses for messages and the Setup program. Use a bootable floppy disk containing the Intel flash utility and language files. 1. Boot the computer with the bootable floppy disk in drive A. The BIOS upgrade utility screen appears. -
Page 57: Running The Scsi Utility
Running the SCSI Utility 1. When this message appears on the video monitor: Press Ctrl-A to run SCSI Utility... 2. Press <Ctrl+A> to run this utility. When it appears, choose the host adapter that you want to configure. Another Adaptec utility that is available on the SBT2 Resource CD is the Adaptec EZ SCSI utility. It is designed to be installed from diskettes on to a DOS or Windows operating system. - Page 58 Configuration Software and Utilities...
-
Page 59: Solving Problems
4 Solving Problems This chapter helps you identify and solve problems that might occur while you are using the system. Resetting the System To do this: Press: Soft boot reset, which clears system memory and reloads the <Ctrl+Alt+Del> operating system. Clear system memory, restart POST, and reload the operating Reset button system. -
Page 60: Running New Application Software
Is AC power available at the wall outlet? q Are all integrated components from the tested components lists? Check the tested memory, and chassis lists, as well as the supported hardware and operating system list on the Intel Customer Support website. -
Page 61: More Problem Solving Procedures
NOTE Random errors in data files: If you are getting random errors in your data files, they may be getting corrupted by voltage spikes on your power line. If you are experiencing any of the above symptoms that might indicate voltage spikes on the power line, you may want to install a surge suppressor between the power outlet and the system power cord. -
Page 62: Confirming Loading Of The Operating System
Confirming Loading of the Operating System Once the system boots up, the operating system prompt appears on the screen. The prompt varies according to the operating system. If the operating system prompt does not appear, see “Initial System Startup” on page 59. Specific Problems and Corrective Actions This section provides possible solutions for these specific problems: Power light does not light. -
Page 63: Characters Are Distorted Or Incorrect
If you are using an add-in video controller board, do the following: 1. Verify that the video controller board is fully seated in the server board connector. 2. Reboot the system for changes to take effect. 3. If there are still no characters on the screen after you reboot the system and POST emits a beep code, write down the beep code you hear. -
Page 64: Diskette Drive Activity Light Does Not Light
Diskette Drive Activity Light Does Not Light Check the following: q Are the diskette drive power and signal cables properly installed? q Are all relevant switches and jumpers on the diskette drive set correctly? q Is the diskette drive properly configured? q Is the diskette drive activity light always on? If so, the signal cable may be plugged in incorrectly. -
Page 65: Problems With Network
Problems with Network The server hangs when the drivers are loaded. q Change the PCI BIOS interrupt settings. Try the “PCI Installation Tips” below. Diagnostics pass, but the connection fails. q Make sure the network cable is securely attached. q Make sure you specify the correct frame type in your NET.CFG file. The Activity LED doesn’t light. -
Page 66: Problems With Application Software
Problems with Application Software If you have problems with application software, do the following: q Verify that the software is properly configured for the system. See the software installation and operation documentation for instructions on setting up and using the software. q Try a different copy of the software to see if the problem is with the copy you are using. -
Page 67: Technical Reference
5 Technical Reference Server Board Jumpers 7C10 OM10428 Figure 14. Jumper Locations Table 5. CPU Clock Speed (7C10) Jumper CPU Speed Pin 1-2 Pins 3-4 Pins 5-6 Pins 7-8 á á á á á 1000 Table 6. Configuration Jumper (3N7) Jumper Name Pins What it does at system reset... -
Page 68: General Procedure To Change Jumper Setting
General Procedure to Change Jumper Setting The short general procedure for changing a configuration setting is the same for most of the jumper functions, so we will describe it here. 1. Observe the safety and ESD precautions at the beginning of this chapter. 2. -
Page 69: Password Jumper
Password Jumper The jumper at pins 3-4 control whether the user and supervisor passwords are retained or cleared during a system reset. Procedure to clear the current password and then enter a new one: 1. See “General Procedure to Change Jumper Setting” on page 68. 2. - Page 70 Technical Reference...
-
Page 71: Regulatory And Integration Information
Product Regulatory Compliance The SBT2 complies with the following safety regulations, and has been verified to comply with the following electromagnetic compatibility (EMC) regulations when installed in a compatible host Intel product. Product Safety Compliance UL 1950 - CSA 950 (US/Canada) -
Page 72: Electromagnetic Compatibility Notices
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions related to the EMC performance of this product, contact: Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124... -
Page 73: Fcc Verification Statement
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions related to the EMC performance of this product, contact: Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124-6497... -
Page 74: Bsmi (Taiwan)
BSMI (Taiwan) The BSMI Certification number and the following warning is located on the product safety label which is located on the bottom side (pedestal orientation) or side (rack mount configuration). Replacing the Back up Battery The lithium battery on the server board powers the real time clock (RTC) for up to 10 years in the absence of power. -
Page 75: Equipment Log And Power Consumption Worksheets Equipment Log
7 Equipment Log and Power Consumption Worksheets Equipment Log Use the blank equipment log provided here to record information about your system. You will need some of this information when you run the SSU. Manufacturer Name and Item Model Number Serial Number Date Installed System... - Page 76 Equipment Log (continued) Manufacturer Name and Item Model Number Serial Number Date Installed Equipment Log and Power Consumption Worksheets...
-
Page 77: Current Usage
Current Usage NOTE Both processors pull power from +5V. This may limit the number of drives and/or add-in cards you may install. As an overall current usage limitation on the power supply, do not exceed a combined power output of 195 watts for the +5 and +3.3 volt outputs. The PCI slots on the server board are rated at a maximum of 5 amperes per slot. -
Page 78: Power Usage Worksheet 1
Worksheet, Calculating DC Power Usage 1. List the current for each board and device in the appropriate voltage level column. 2. Add the currents in each column. Then go to the next worksheet. Table 7. Power Usage Worksheet 1 Current (maximum) at voltage level: Device +3.3 V +5 V... -
Page 79: Power Usage Worksheet 2
Worksheet, Total Combined Power Used by the System 1. From the previous worksheet, enter the total current for each column. 2. Multiply the voltage by the total current to get the total wattage for each voltage level. 3. Add the total wattage for each voltage level to arrive at a total combined power usage on the power supply. - Page 80 Equipment Log and Power Consumption Worksheets...
-
