Page 1: Installation Guide
Installation Guide 613-000818 Rev. B Layer 2+ Fast Ethernet Switches AT-8516F/SC AT-8524M AT-8524POE AT-8550GB AT-8550SP... - Page 2 Allied Telesis, Inc. reserves the right to make changes in specifications and other information contained in this document without prior written notice. The information provided herein is subject to change without notice. In no event shall Allied Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis, Inc.
-
Page 3: Electrical Safety And Emissions Standards
European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment This Allied Telesis RoHS-compliant product conforms to the European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment. Allied Telesis ensures RoHS conformance by requiring supplier Declarations of Conformity, monitoring incoming materials, and maintaining manufacturing process controls. -
Page 4: Translated Safety Statements
Translated Safety Statements Important: The indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” (613-000405) posted on the Allied Telesis website at www.alliedtelesis.com. -
Page 5: Table Of Contents
Preface ...11 Safety Symbols Used in this Document...12 Where to Find Web-based Guides ...13 Contacting Allied Telesis ...14 Online Support ...14 Email and Telephone Support ...14 Returning Products...14 For Sales or Corporate Information ...14 Warranty ...14 Management Software Updates ...14 Chapter 1: Overview ...15... - Page 6 Contents Selecting a Site for the Switch ...51 Planning the Installation...52 Unpacking the Switch ...54 Installing the Switch in a Rack ...55 Installing an Optional Expansion or Stacking Module...58 Installing an Optional GBIC...60 Installing an Optional SFP Transceiver...62 Cabling the Switch ...64 Cabling Twisted Pair Ports ...64 Cabling Fiber Optic Ports...65 Cabling Expansion Modules ...67...
- Page 7 Figures Figure 1. AT-8516F/SC Switch Front and Back Panels 9 Figure 2. AT-8524M Switch Front and Back Panels 10 Figure 3. AT-8524POE Switch Front and Back Panels 11 Figure 4. AT-8550GB Switch Front and Back Panels 12 Figure 5. AT-8550SP Switch Front and Back Panels 13 Figure 6.
- Page 8 Figures Figure 1. AT-8516F/SC Switch Front and Back Panels...17 Figure 2. AT-8524M Switch Front and Back Panels ...18 Figure 3. AT-8524POE Switch Front and Back Panels ...19 Figure 4. AT-8550GB Switch Front and Back Panels...20 Figure 5. AT-8550SP Switch Front and Back Panels ...21 Figure 6.
- Page 9 Tables Table 1. Safety Symbols ...12 Table 2. Model Configurations ...16 Table 3. IEEE 802.3af Class vs. Power Levels ...28 Table 4. LEDs for the 10/100Base-TX Twisted Pair Ports on the AT-8524M, AT-8550GB, and AT-8550SP Switches ...31 Table 5. LEDs for Ports 49R and 50R on the AT-8550GB and AT-8550SP Switches ...32 Table 6.
- Page 10 Tables...
-
Page 11: Preface
Preface This guide provides the hardware installation instructions for you managed, Layer 2+ AT-8500 Series Fast Ethernet switch. This preface contains the following sections: “Safety Symbols Used in this Document” on page 12 “Where to Find Web-based Guides” on page 13... -
Page 12: Safety Symbols Used In This Document
Preface Safety Symbols Used in this Document This document uses the safety symbols defined in Table 1. Symbol Table 1. Safety Symbols Meaning Caution Performing or omitting a specific action may result in equipment damage or loss of data. Warning Performing or omitting a specific action may result in electrical shock. -
Page 13: Where To Find Web-Based Guides
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Where to Find Web-based Guides The installation and user guides for all Allied Telesis products are available in portable document format (PDF) on our web site at www.alliedtelesis.com. You can view the documents online or download... -
Page 14: Contacting Allied Telesis
Internet sites: Software Updates If you prefer to download new software from the Allied Telesis FTP server from your workstation’s command prompt, you will need FTP client software and you must log in to the server. Enter “anonymous” for the user name and your email address for the password. -
Page 15: Chapter 1: Overview
Chapter 1 Overview The AT-8500 Series switches are managed, Layer 2+ Fast Ethernet switches. These switches are designed to simplify the task of creating or expanding an Ethernet or Fast Ethernet network. This chapter contains the following sections: “Model Configurations” on page 16 “Model Descriptions”... -
Page 16: Model Configurations
Chapter 1: Overview Model Configurations Table 2 lists the basic model configurations. AT-8516F/SC AT-8524M AT-8524POE AT-8550GB AT-8550SP Table 2. Model Configurations Model 16 100Base-FX ports with dual SC connectors plus two expansion slots for optional fiber optic and twisted pair port expansion modules. 24 10/100Base-TX ports plus two expansion slots for optional fiber optic and twisted pair port expansion modules. -
Page 17: Model Descriptions
62.5/125 micron (core/cladding) multimode fiber optic cable. Figure 1 illustrates the front panel of the AT-8516F/SC switch. Module Expansion Slots 100-240VA C AC Power Connector AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Port LEDs PORT ACTIVITY LINK / ACTIVITY... -
Page 18: At-8524M
Chapter 1: Overview AT-8524M The AT-8524M switch has 24 10/100Base-TX twisted pair ports and two module expansion slots. The twisted pair ports feature RJ-45 connectors and have a maximum operating distance of 100 meters (328 feet) using Category 3 or better 100 ohm twisted pair cable for 10Base-T operation and Category 5 or 5E 100 ohm twisted pair cable for 100Base-TX operation. -
Page 19: At-8524Poe
AT-STACKM stacking module. Figure 3 shows the front and back panels of the AT-8524POE switch. Module Expansion Slots 100-240VA C AC Power Connector AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide 10/100Base-TX Ports with PoE RPS INPUT VDC A Max 8.5A... -
Page 20: At-8550Gb
(GBICs). You can use the GBICs to add 1000Base-X fiber optic ports to the switch to extend the distance of your network. For a list of GBICs supported by the switch, contact your Allied Telesis sales representative or refer to the Allied Telesis web site: www.alliedtelesis.com. -
Page 21: At-8550Sp
You can use the slots to add 1000Base-X fiber optic ports to the switch. For a list of supported SFP transceivers, contact your Allied Telesis sales representative or refer to the Allied Telesis web site: www.alliedtelesis.com. Figure 5 shows the front and back panels of the AT-8550GB switch. -
Page 22: Port Descriptions
Chapter 1: Overview Port Descriptions This section provides information on the following port types found on the AT-8500 Series switches: 10/100Base-TX This section applies to the AT-8524M, AT-8524POE, AT-8550GB, and AT-8550SP switches. Twisted Pair Ports Type of Connector The 10/100Base-TX twisted pair ports feature 8-pin RJ-45 connectors. - Page 23 AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Note In order for a switch port to successfully Auto-Negotiate its duplex mode with an end node, the end node should also be using Auto- Negotiation. Otherwise, a duplex mode mismatch can occur. A switch port using Auto-Negotiation will default to half-duplex if it detects that the end node is not using Auto-Negotiation.
-
Page 24: 10/100/1000Base-T Twisted Pair Ports
Chapter 1: Overview 10/100/ This section applies to Port 49R and Port 50R on the AT-8550GB and AT-8550SP switches. 1000Base-T Twisted Pair Type of Connector Ports The ports have 8-pin RJ-45 connectors. The ports use four pins when operating at 10 or 100 Mbps and all eight pins when operating at 1000 Mbps. -
Page 25: 100Base-Fx Fiber Optic Ports
Each fiber optic port has a maximum operating distance of two kilometers (1.25 miles) when operating in full-duplex mode and 412 meters (1,360 feet) when operating in half-duplex mode. AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Note The auto-MDI/MDI-X feature on a 10/100/1000Base-T port is functional only when the port is set to Auto-Negotiation. - Page 26 Chapter 1: Overview Type of Cable The fiber optic ports can use either 50/125 or 62.5/125 micron multimode fiber optic cable. Note Do not use single-mode fiber optic cable with these ports.
-
Page 27: Power Over Ethernet
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Power Over Ethernet The following discussion applies only to the AT-8524POE switch. The twisted pair ports on the AT-8524POE switch feature Power over Ethernet (PoE). PoE is a mechanism for supplying power to network devices over the same twisted pair cables used to carry network traffic. -
Page 28: Implementation
Chapter 1: Overview described in Table 3. . A port connected to a network node that is not a powered device (that is, a device that receives its power from another power source) functions as a regular Ethernet port, without PoE. The PoE feature remains enabled on the port but no power is delivered to the device. -
Page 29: Gbic And Sfp Slots
Port 49R or 50R, changes to a redundant status. A link on a GBIC or SFP port always takes precedence over that of the corresponding 10/100/ 1000Base-T twisted pair port. AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Figure 6. GBIC Module Figure 7. SFP Transceiver... -
Page 30: Module Expansion Slots
100Base and 1000Base fiber optic and twisted pair ports to the switch. Note For a list of the Allied Telesis expansion modules supported by the switches, contact your Allied Telesis sales representative or refer to our web site at: www.alliedtelesis.com. -
Page 31: Leds
Table 4 describes the LEDs for the 10/100Base-TX twisted pair ports on the AT-8524M, AT-8550GB, and AT-8550SP switches. LINK Mode - COL AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Note Toggling the Mode Selection button does not affect the normal operations of the switch. - Page 32 Chapter 1: Overview Mode - 100 (AT-8524M) Mode - SPD (AT-8550GB AT-8550SP) Mode - FULL (AT-8524M) MODE - FDX AT-8550GB AT-8550SP) Mode - ACT Table 5 describes the LEDs for the 10/100/1000Base-TX twisted pair ports, Ports 49R and 50R, on the AT-8550GB and AT-8550SP switches. Table 5.
- Page 33 AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Table 5. LEDs for Ports 49R and 50R on the AT-8550GB and AT-8550SP Switches (Continued) State Mode - SPD Indicates that the port is operating at 10 or 100 Mbps. Green Indicates that the port is operating at 1000 Mbps.
-
Page 34: Fiber Optic Port Leds
Chapter 1: Overview Mode - DC Mode - POE Fiber Optic Port This section applies to the AT-8516F/SC switch. The fiber optic ports on an AT-8516F/SC switch have two LEDs, labeled L/A and D/C. The LEDs LEDs Table 6. LEDs for the 10/100Base-TX Twisted Pair Ports on the AT-8524POE Switch (Continued) State Indicates that the port has not established a... -
Page 35: Gbic And Sfp Expansion Slot Leds
Table 8. LEDs for the Optional GBIC and SFP Ports on an AT-8550GB and LINK Mode - COL AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide State Indicates no link has been established between the port and the end node. -
Page 36: System Leds
Chapter 1: Overview Table 8. LEDs for the Optional GBIC and SFP Ports on an AT-8550GB and Mode - SPD Mode - FDX Mode - ACT System LEDs The system LEDs on the front panel display general status information, as described in Table 9. -
Page 37: Rs-232 Terminal Port
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Note You are not required to manage an AT-8500 Series switch. If the default switch settings are adequate for your network, you can use the unit as an unmanaged switch. For the default settings, refer to the AT-S62 Management Software User’s Guides. -
Page 38: Power Options And Connectors
AT-8550GB, and AT-8550SP switches. The AT-RPS3104 unit is used with the AT-8524POE switch. Do not use the AT-RPS3004 unit with the AT-8524POE switch. Figure 8. AT-RPS3004 Redundant Power Supply Unit Note DC models of the AT-8500 Series switches do not feature an RPS connector. -
Page 39: Ac Power Connector
Refer to Appendix A, “Technical Specifications” on page 81 for the input voltage range. DC Power Some models of the AT-8500 Series switch are offered with a DC terminal block on the back panel instead of an AC socket, for those network Connector installations that require DC equipment. -
Page 40: A Few Basics About Ethernet Switching
MAC address assigned to them by the adapter manufacturers. An AT-8500 Series Fast Ethernet Switch has a MAC address table capable of storing up to 8,000 MAC addresses. The switch uses the table to store the MAC addresses of the network end nodes connected to the ports, along with the port number on which each address was learned. -
Page 41: Store And Forward
Naturally, an end node capable of operating in full-duplex can handle data much faster than an end node that can only operate in half-duplex mode. The twisted pair ports on the AT-8500 Series switches can operate in either half- or full-duplex mode. The twisted pair ports are IEEE 802.3u- compliant and will Auto-Negotiate the duplex mode setting for you. - Page 42 Chapter 1: Overview How a switch signals an end node to stop transmitting data differs depending on the speed and duplex mode of the end node and switch port. A twisted pair port operating at 100 Mbps port and half-duplex mode stops an end node from transmitting data by forcing a collision.
-
Page 43: Figure 9. Power Workgroup Topology
This reduces the amount of unnecessary data traffic in each workgroup, freeing up bandwidth and improving network performance. AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Legend 10 Mbps 100 Mbps Figure 9. -
Page 44: Mixed Topology
Chapter 1: Overview Ethernet Hubs Mixed Topology You can always combine topologies as well as build a larger network by connecting different switches together. If the switches are within 100 meters (328 feet) of each other, you can use the twisted pair ports. If the switches are further apart, then you can use fiber optic ports. -
Page 45: Figure 11. Mixed Topology
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Figure 11 illustrates a network of three AT-8524M Fast Ethernet switches. The workstations and servers on the network are connected either directly to a switch or indirectly through an Ethernet hub. The switches themselves are connected together through 1000Base fiber optic ports on AT-A45/SC expansion modules, creating a high-speed backbone. - Page 46 Chapter 1: Overview...
-
Page 47: Chapter 2: Installation
Chapter 2 Installation This chapter provides the installation procedures for the switch and contains the following sections: “Reviewing Safety Precautions” on page 48 “Selecting a Site for the Switch” on page 51 “Planning the Installation” on page 52 “Unpacking the Switch” on page 54 “Installing the Switch in a Rack”... -
Page 48: Reviewing Safety Precautions
Note indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” (613-000405) on the Allied Telesis website at www.alliedtelesis.com. Warning: To prevent electric shock, do not remove the cover. No user-serviceable parts inside. This unit contains hazardous voltages and should only be opened by a trained and qualified technician. - Page 49 AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Warning: As a safety precaution, install a circuit breaker with a minimum value of 15 Amps between the equipment and the DC power source. Always connect the wires to the LAN equipment first before you connect the wires to the circuit breaker.
- Page 50 Chapter 2: Installation Warning: This unit might have more than one power source. To reduce the risk of electric shock, disconnect all power sources before servicing the unit. If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than the room ambient temperature.
-
Page 51: Selecting A Site For The Switch
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Selecting a Site for the Switch Observe the following requirements when choosing a site for your switch: If you plan to install the switch in an equipment rack, check to be sure that the rack is safely secured and that it will not tip over. -
Page 52: Planning The Installation
Chapter 2: Installation Planning the Installation Table 10 contains the cabling specifications for the twisted pair ports. AT-8524M AT-8524POE AT-8550GB AT-8550SP AT-8550GB AT-8550SP (Ports 49R and 50R) Table 10. Twisted Pair Cabling and Distances Model Speed 10 Mbps Category 3 or better 100-ohm shielded or unshielded twisted pair cable... -
Page 53: Table 11. Fiber Optic Cabling And Distances
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Table 11 contains the cabling specifications for the fiber optic ports on an AT-8516F/SC switch. Table 11. Fiber Optic Cabling and Distances Model Speed AT-8516F/SC 100 Mbps Note For cabling specifications for an optional GBIC module, SFP module, expansion module, or stacking module, refer to the installation guide included with the option. -
Page 54: Unpacking The Switch
Allied Telesis. switch package. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. One AT-8500 Series Fast Ethernet Switch Two mounting brackets Eight flathead Phillips screws (All models except the AT-8524POE switch) Twelve flathead Phillips screws (AT-8524POE switch only) AC power cord (AC switches only;... -
Page 55: Installing The Switch In A Rack
If you are not installing the switch in a rack, proceed to “Installing an Optional GBIC” on page 60. 1. Place the unit upside down on a level, secure surface. AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Figure 12. Rack Mount Bracket Positions Note... -
Page 56: Figure 13. Removing The Feet
Chapter 2: Installation 2. Using a flat-head screwdriver, remove the snap-on plastic feet from 3. Turn the switch over. 4. Attach a rackmounting bracket to one side of the switch using four of 5. Install the second rackmounting bracket on the other side of the switch 6. - Page 57 AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Caution: Air vents must not be blocked and must have free access to the room ambient air for cooling. Warning: Operating Temperature. This product is designed for a maximum ambient temperature of 40° degrees C.
-
Page 58: Installing An Optional Expansion Or Stacking Module
Note You must use the original shipping material if you need to return the module to Allied Telesis. Warning An expansion or stacking module can be damaged by static electricity. Be sure to observe all standard electrostatic discharge (ESD) precautions, such as wearing an antistatic wrist strap, to avoid damaging the module. -
Page 59: Figure 16. Securing The Module In The Expansion Slot
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide 4. Pull the faceplate straight out of the slot. 5. Keep the faceplate in a safe area in case you need to reinstall it. The faceplate keeps any dust from getting into the switch and maintains proper airflow if the slot remains empty. -
Page 60: Installing An Optional Gbic
A GBIC can be damaged by static electricity. Be sure to observe all standard electrostatic discharge (ESD) precautions, such as wearing an antistatic wrist strap, to avoid damaging the module. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. One GBIC module... -
Page 61: Figure 17. Optical Bore And Ferrule Of Gbic Module
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide ferrules of the optical connector. Ferrule Bore Figure 17. Optical Bore and Ferrule of GBIC Module Note Unnecessary removal and insertion of a GBIC can lead to premature failure. 4. Slide the GBIC module, with the label side up, into an expansion slot on the switch, as shown in Figure 18. -
Page 62: Installing An Optional Sfp Transceiver
An SFP transceiver can be damaged by static electricity. Be sure to observe all standard electrostatic discharge (ESD) precautions, such as wearing an antistatic wrist strap, to avoid damaging the module. item is missing or damaged, contact your Allied Telesis sales representative for assistance. One SFP module Installation Guide... - Page 63 AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide debris picked up on the ferrules of the optical connectors. Use an alcohol swab or wipe to clean the ferrules of the optical connector. Note Unnecessary removal and insertion of an SFP transceiver can lead to premature failure.
-
Page 64: Cabling The Switch
To connect the data cables to the switch ports and to apply power to the switch, perform the following procedure: Cabling Twisted If your AT-8500 Series switch has twisted pair ports, perform the following procedure: Pair Ports 1. Connect the twisted pair data cables to the RJ-45 ports on the switch, as shown in Figure 19. -
Page 65: Cabling Fiber Optic Ports
Note Do not remove the dust covers if you do not intend to connect the fiber optic cables at this time. Dust contamination can adversely impact the operation of the ports. AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide... -
Page 66: Figure 21. Attaching A Fiber Optic Cable
Chapter 2: Installation 2. Attach the fiber optic data cables to the fiber optic ports, as shown in Figure 21. Figure 21. Attaching a Fiber Optic Cable When you attach a fiber optic cable, be sure to observe the following guidelines: Be sure that the cable connector is firmly locked into place in the port. -
Page 67: Cabling Expansion Modules
Cabling If you installed a fiber optic or twisted pair expansion module, stacking module, GBIC module, or SFP module, connect the data cable to the port Expansion on the module. Modules AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide... -
Page 68: Powering On An Ac Powered Switch
Chapter 2: Installation Powering on an AC Powered Switch To power on an AC powered switch, perform the following procedure: 1. Select the correct power cord for your country. 2. Plug the power cord into the AC power connector on the back panel of 3. -
Page 69: Figure 24. Connecting The Rps Dc Cable
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide 4. If you installed an optional redundant power supply unit, connect one end of the DC power cord included with the RPS unit to the back panel of the redundant power supply and the other end to the RPS connector on the back panel of the switch, as shown in Figure 24. -
Page 70: Wiring And Powering On An Dc Powered Unit
Chapter 2: Installation Wiring and Powering on an DC Powered Unit To provide power for a DC powered switch, perform the following steps: 1. Before you attach wires to the DC terminal block at the rear of the 2. On the rear side of the chassis is a DC terminal block. Starting from 3. -
Page 71: Figure 27. Connecting The Stripped Wire
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Warning Do not strip more than the recommended amount of wire. (See Figure 26.) Stripping more than the recommended amount can create a safety hazard by leaving exposed wire on the terminal block after installation. - Page 72 Chapter 2: Installation 7. Secure the tray supply cable near the rack framework using multiple 8. Ensure that the circuit breaker is in the Off position. 9. Connect the DC wires to the circuit breaker. (Refer “Power 10. Power on the circuit breaker. 11.
-
Page 73: Starting A Local Management Session
To start a local management session, perform the following procedure: 1. Connect one end of the RS-232, straight-through management cable included with the AT-8500 Series switch to the RS-232 terminal port on the switch. (See Figure 28.) This port is located on the front panel on the AT-8516F/SC, AT-8524M, and AT-8524POE switches and on the back panel of the AT-8550GB and AT-8550SP switches. - Page 74 For instructions, refer to the AT-S62 Management Software User’s Guides. The guides are available from the Allied Telesis web site at www.alliedtelesis.com and on the CD included with the switch. . This message is intended for...
-
Page 75: Warranty Registration
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Warranty Registration When you have finished installing the switch, fill out the enclosed warranty card and mail it to Allied Telesis. - Page 76 Chapter 2: Installation...
-
Page 77: Chapter 3: Troubleshooting
If after following the instructions in this chapter you are unable to resolve the problem, contact Allied Telesis Technical Support for assistance. Refer to “Contacting Allied Telesis” on page 14 for contact information. Make sure that the power cord is securely connected to the power source and to the AC connector on the back panel of the switch. -
Page 78: Fiber Optic Port Link Led Is Off
Chapter 3: Troubleshooting Fiber Optic Port Link LED is Off For fiber optic ports, verify that the LINK LED for each port is ON. If a LINK LED is OFF, do the following: Verify that you are using the appropriate category of twisted pair cable: Category 3 or better for 10 Mbps operation and Category 5 and Category 5E for 100 Mbps and 1000 Mbps operations. -
Page 79: Poe Device Is Not Receiving Power
24, even when all devices require the maximum of 15.4 W. Fault LED is On Continuously AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide A 1000Base connection can take from five to ten seconds to establish a link. -
Page 80: Cannot Establish A Local Management Session
If the LED remains on even after you have tried the above suggestions, the switch may be having a hardware problem. Contact your Allied Telesis representative for assistance. Check to be sure that the RS-232 cable is securely connected to the RS-232 terminal port on the switch and to the RS-232 port on the terminal or personal computer. -
Page 81: Appendix A: Technical Specifications
Appendix A Technical Specifications Physical Specifications AT-8516F/SC and AT-8524M Dimensions AT-8550GB and AT-8550SP Dimensions AT-8524POE Dimensions: Weight: AT-8516F/SC AT-8524M AT-8524POE AT-8550GB AT-8550SP Recommended Minimum Ventilation on All Sides: Environmental Specifications Operating Temperature: Storage Temperature: Operating Humidity: Storage Humidity: Maximum Operating Altitude: Maximum Non-operating Altitude:4,000 m (13,000 ft) 4.4 cm x 44.0 cm x 22.2 cm (1.75 in. -
Page 82: Power Specifications
Appendix A: Technical Specifications Power Specifications Input Voltage: All models except for the AT-8524POE: AC Input Power Consumption: Available Power over Ethernet: Safety and Electromagnetic Emissions Certifications EMI: Immunity: Safety: Quality and Reliability: AT-8524POE: All models except AT-8524POE: Only the AT-8524POE: IEEE 802.3af Class 3 (15.4 W): IEEE 802.3af Class 2 (7.3 W): IEEE 802.3af Mode:... -
Page 83: Rj-45 Twisted Pair Port Pinouts
AT-8524M, AT-8550GB, and AT-8550SP switches. Table 13 lists the RJ-45 port pin signals on the 10/100Base-TX ports on an AT-8524POE switch. AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Pin 1 Figure 29. RJ-45 Connector and Port Pin Layout Table 12. -
Page 84: Table 14. Mdi And Mdi-X Pin Signals (1000Base-T)
Appendix A: Technical Specifications Table 14 lists the RJ-45 pin signals for the two 10/100/1000-Base-T ports on the AT-8550GB switch when the ports are operating at 1000 Mbps. Table 13. 10/100Base-T Port MDI/MDI-X Pin Signals with PoE MDI Signal Unused Unused RX- and Vport-2 Unused... -
Page 85: At-8516F/Sc Fiber Optic Port Specifications
Minimum: Maximum: 62.5/125 micron cabling Minimum: Maximum: Receiver Sensitivity: Minimum: Maximum: AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide 100Base-FX 100 Mbps 2 km (1.24 mi) Dual SC Connector 50/125 micron or 62.5/125 micron (core/cladding) multimode fiber optic cabling 1310 nm -22.5 dBm average... -
Page 86: Rs-232 Terminal Port Pinouts
Appendix A: Technical Specifications RS-232 Terminal Port Pinouts Table 15 lists the pin signals on the RS-232 terminal port. Table 15. RS-232 Terminal Port Pin Signals Signal Data Carrier Detect Transmit Data Receive Data Data Set Ready Ground Data Terminal Ready Clear to Send Request to Send Ring Indicator... -
Page 87: Rps Connector Port Pinouts
AT-8516F/SC, AT-8524M, AT-8550GB, and AT-8550SP switches. Table 16 lists the 16-pin RPS connector pins and definitions. AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Figure 30. RPS 16-pin Molex Connector Pin Layout Table 16. Pin Definitions of the 16-pin RPS Connector... -
Page 88: Figure 31. At-8524Poe Rps Connector Pin Layout
Appendix A: Technical Specifications Table 16. Pin Definitions of the 16-pin RPS Connector (Continued) Figure 31 illustrates the pin layout to the RPS connector on the AT-8524POE switch. Table 17 lists the RPS connector pins and definitions. Table 17. Pin Definitions for the RPS Connector on the AT-8524POE Definition +3.3V DC Return Figure 31. -
Page 89: Pin Definition
AT-8500 Series Layer 2+ Fast Ethernet Switches Installation Guide Table 17. Pin Definitions for the RPS Connector on the AT-8524POE Switch (Continued) Definition 3.3V RS+ 3.3V 3.3V... -
Page 90: Dual Sc Type Connector
Appendix A: Technical Specifications Dual SC Type Connector A dual SC type connector, as shown in Figure 32, is used with the AT-8516F/SC switch. Figure 32. Dual SC Connector...
