    HP NetServer Performance and Sizing Guidelines Microsoft Windows NT 4.0 Server, Terminal Server Edition January 1999...

  • Page 2

    The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Table Of Contents

    Introduction........................4 Processors .........................5 Memory ..........................7 Network ..........................7 Client Solutions ........................8 SIZING ACTIVITY................10 Methodology ........................10 Test Configuration .......................10 Visual Test Scripts .......................14 Test Procedures ......................16 Test Results ........................16 Elapsed Time .......................17 Process Utilization......................18 Network Utilization......................24 Memory Utilization ......................26 Hewlett-Packard Company...

  • Page 4: Test Summary, Introduction

    (Microsoft Window NT Server, Terminal Server Administrator's Guide). Configuration Task-based users Typical users Advanced users ® Single processor Intel ® Pentium Pro 200MHz 128MB RAM Dual-processor Pentium Pro 200MHz 256MB RAM Quad-processor Pentium Pro 200MHz 512MB RAM Table 1 Hewlett-Packard Company...

  • Page 5: Processors

    LXr 8000: Quad Processor ™ Pentium II Xeon MHz 1GB RAM Table 2 Resource requirements can vary significantly depending on the application mix and client usage pattern. Therefore, whenever possible, HP recommends sizing the server using the targeted application environment. Hewlett-Packard Company...

  • Page 6: Figure

    P r oce s s or 2 (Max) 1. 09 0. 52 5. 93 7.54 28. 12 63. 34 P r oce s s or 3 (Max) N umb e r o f C lie nt S e s s io ns Figure 1 Hewlett-Packard Company...

  • Page 7: Memory, Network

    As with processor and memory utilization, network utilization will vary depending on user activity. As a general rule of thumb, Microsoft recommends 2 - 6Kbps per user (Microsoft Terminal Server Capacity Planning, White Paper). Network activity during our benchmark test averaged between 2 and 5Kbps per user. Hewlett-Packard Company...

  • Page 8: Client Solutions

    2700 2600 2500 2400 2300 2200 2100 2000 2440 2435 2431 PC Client s 2444 2438 2434 WBTClient s N u m b e r of C l i e nt S e ssi on s Figure 2 Hewlett-Packard Company...

  • Page 9

    The following chart shows the % Network Utilization recorded during 1, 2 and 3 client runs using HP Vectra and HP Windows-based Terminals. Network Segment - Average % Network 0.26 0.37 0.26 0.37 Number of Client Figure 4 Hewlett-Packard Company...

  • Page 10: Sizing Activity, Methodology, Test Configuration

    To create the network, two sets of six clients were each connected to cascaded HP J3128A AdvanceStack 10Base-T hubs. Microsoft Terminal Server HP NetServer NetS er ver LHx 10 Mbits HP J31218A HP J3128A Windows NT Windows 95 (6 workstations) (6 workstations) Microsoft Terminal Server Clients HP Vectra Figure 5 Hewlett-Packard Company...

  • Page 11

    Four Intel Pentium II Xeon 400 MHz processor with 100 MHz bus • 512KB cache per processor • 1GB RAM • Integrated dual Ultra2 SCSI controllers - 4.2GB disk drive • HP DeskDirect 10/100 TX PCI LAN Adapter Hewlett-Packard Company...

  • Page 12

    Intel Pentium/133 processor • 32MB RAM • HP DeskDirect 10/100 TX PCI LAN Adapter • Windows NT 4.0 HP Vectra VL5 • Intel Pentium/200 processor • 32MB RAM • HP DeskDirect 10/100 TX PCI LAN Adapter • Windows 95 Hewlett-Packard Company...

  • Page 13

    Microsoft Terminal Server Terminal Server Client Ne tSe rve r LHx Screen Output Keyboard/Mouse Application Screen Display Presentation RDP Data Stream Presentation Services Layer Services Layer Protocol Protocol Protocol Packets Drivers Drivers Transport Transport Data Transport Driver Driver Figure 6 Hewlett-Packard Company...

  • Page 14: Visual Test Scripts

    (i.e., 2.0 seconds), CPU utilization of the Microsoft Word portion of the test is consistently higher. The Microsoft Word and Microsoft Excel applications were started at the beginning of the test script and exited at the end of the script. Hewlett-Packard Company...

  • Page 15

    The following two screenshots were captured during a run of the Visual Test script. Figure 7 Hewlett-Packard Company...

  • Page 16: Test Procedures, Test Results

    In order to establish an application baseline (0) value, the script was run at the server and the Performance Monitor was used to monitor server activity. The application baseline value is included on some of the charts under the "0" column. Hewlett-Packard Company...

  • Page 17: Elapsed Time

    2436 2440 241 2 241 6 2439 2553 2751 2953 2433 2436 241 8 2421 2445 2540 2750 301 1 2433 2437 2421 241 1 241 1 2421 2507 2640 LXr 8000 Number of Client Sessions Figure 9 Hewlett-Packard Company...

  • Page 18: Process Utilization

    All processors use a single queue in which threads wait for processor cycles. This length does not include the threads that are currently executing. This is an instantaneous count, not an average over the time interval. Hewlett-Packard Company...

  • Page 19

    Figure 11 - 12 Client Sessions (LH 3) The following Performance Monitor charts show % Processor Time while performing the 36 client session tests on the HP NetServer LH 3. Figure 12 - 36 Client Sessions (LH 3) Hewlett-Packard Company...

  • Page 20

    36 client run and 1650 seconds for the 72 client run. As discussed previously, this is because the Microsoft Word portion of the script actually places a heavier load on the system and saturates the processors before the Microsoft Excel portion of the script. Hewlett-Packard Company...

  • Page 21

    Maximum Processor Utilization 22.98 88.77 LXPr o 4.12 13.84 37.09 93.46 2.11 15.39 28.69 92.88 LH 3 0.44 7.23 27.91 62.88 LXr 8000\ N u mbe r of C l i e nt S e ssi o ns Figure 15 Hewlett-Packard Company...

  • Page 22

    1, 12, 24, 36, 48, 60 and 72 client sessions for each of the tested server configurations. Maximum Processor Queue Length LX Pr o LXr 8000 N umber of C l i ent Ses si ons Figure 17 Hewlett-Packard Company...

  • Page 23

    0.05 seconds between text keystrokes and 2.0 seconds between keystrokes that initiate menu operations. Average %Processor Time 0.05 Text/0.5 Menu Delay 0.05 Text/2.00 Menu Delay 0.5 Text/4.00 Menu Delay 35.23 6.65 1.45 LH 3 Delay Lengths Figure 18 Hewlett-Packard Company...

  • Page 24: Network Utilization

    The % Network Utilization counter records the percent of network bandwidth in use for the local network segment. The following Performance Monitor chart characterizes the network traffic (i.e., % Network Utilization) while performing the 24 client session test for each of the LH 3. Figure 19 (24 Clients) Hewlett-Packard Company...

  • Page 25

    However, it is important to remember that, for purposes of our test, we used an isolated network with no additional traffic. In additional, our test script was not graphics intensive. As expected, as processor utilization increases network activity begins to level off. Hewlett-Packard Company...

  • Page 26: Memory Utilization

    The Committed Bytes counter records the amount of virtual memory that has been committed to either physical RAM or the pagefile. If the amount of committed bytes is larger than the amount of physical memory, it may indicate that more RAM is required. Hewlett-Packard Company...

  • Page 27

    The HP NetServer LH 3 was configured with 1GB of RAM. Figure 22 Memory – Pages/Second The following Performance Monitor characterizes the value of the Memory - Pages/Second counter while performing the 24 client session test on the LH 3. Figure 23 Hewlett-Packard Company...

  • Page 28

    290.1 9 251 .7 284.28 397.87 46.23 1 23.72 227.1 2 347.45 301 .94 365.1 9 249.95 24.7 84.1 6 1 08.85 1 63.99 1 82.71 301 .5 291 .83 LX r8000 Number of Client Sessions Figure 25 Hewlett-Packard Company...

  • Page 29

    7 ,1 4 4 , 4 2 5 6 ,2 7 5 , 8 4 9 L X r 8 0 0 0 N u m b e r o f C lie n t S e s s io n s Figure 27 Hewlett-Packard Company...

  • Page 30

    About HP Hewlett-Packard Company is a leading global provider of computing, Internet and intranet solutions, services, communications products and measurement solutions, all of which are recognized for excellence in quality and support. HP has 124,600 employees and had revenue of $47.1 billion in its 1998 fiscal year.
