HP P2000 3.5-inch Large Form Factor Drive Enclosure I/O Module Firmware S1 10B23 Release Notes HP Part Number: 579176-003 Published: June 201 1 Edition: Third...
Supersedes S100B56 Product models HP P2000 3.5-inch Large Form Factor Drive Enclosure I/O Module Enhancements and fixes A single faulty drive in an array caused both paths in the system to become unresponsive. Corrected the LED display on SATA 2.5-inch drives.
Page 4
Installation notes and best practices WARNING! Do not cycle power or restart devices during a firmware update. If the update is interrupted or there is a power failure, the module could become inoperative. If this occurs, contact technical support. The module may need to be returned to the factory for reprogramming. CAUTION: Before upgrading firmware, ensure that the system is stable and is not being reconfigured or changed in any way.
Page 5
Instead of command line parameters you can use the following DOS environment variables: oa_address: set this variable for the IP address of array controller oa_username : set this variable for the username of array controller oa_password : set this variable for the password of array controller NOTE: When prompted for logon information, enter credentials for an account with management access rights.
Page 6
Click Install Expansion-Module Firmware File. Wait for progress messages to specify that the update is complete. In the SMU display, verify that the proper firmware version appears for each module. Installing firmware using FTP Place the downloaded firmware package in a temporary directory. If using a Smart Component, extract the contents of the Smart Component.
