Page 1: Installation Guide
Installation Guide Wyse R Class Conversion to WES2009 ® Wyse USB Firmware Tool Release 1.13 ® Products: R10L, R50L, R50LE, R90L, R90LE, R90L7 Issue: 090711 PN: 883887-29L Rev. A... -
Page 2: Ordering Information
End User License Agreement (“License”) A copy of the Wyse Technology End User License Agreement is included in the software and provided for your reference only. The License at http://www.wyse.com/license as of the purchase date is the controlling licensing agreement. -
Page 3: Table Of Contents
Contents Introduction Kit Contents 1 Overview 2 Wyse Technical Support 2 Related Documentation and Services 2 Wyse Online Community 2 Installing Rx0L Flash and RAM Requirements 3 Procedures 4 What’s Next 6 Installing Rx0LE Flash and RAM Requirements 7 Procedures 8 What’s Next 11... - Page 4 Contents This page intentionally blank.
-
Page 5: Introduction
• RAM module • Wyse Conversion Labels (you must attach a Wyse label to each converted thin client) • Microsoft License Labels (you must attach a COA label to each converted thin client) Figure 1 Kit contents (items may look different or not be included in your kit) -
Page 6: Overview
To access international support, visit http://www.wyse.com/global. Related Documentation and Services Fact Sheets containing the features of hardware products are available on the Wyse Web site. Go to http://www.wyse.com/products/hardware, click the link for your hardware product, and then click the link for the Fact Sheet. -
Page 7: Installing Rx0L Flash And Ram
Installing Rx0L Flash and RAM This chapter contains information for users of Wyse Rx0L thin clients who must install new flash and/or RAM. If you are installing firmware only, you can skip this chapter and proceed to"Installing WES2009 Firmware." IMPORTANT: •... -
Page 8: Procedures
Chapter 2 Procedures Step 1: Remove the Rx0L Thin Client Left Side Cover Caution Follow all precautions listed in the Quick-Start Guide that came with your thin client for disconnecting and reconnecting the thin client. 1. Perform a proper shutdown of the thin client by closing all files and ending your session, and then press the power button to turn off the thin client. - Page 9 Installing Rx0L Flash and RAM Step 2: Install the Rx0L Flash Module Warning Flash modules may be susceptible to damage by Electro-Static Discharge (ESD). All industry-standard cautions should be followed to avoid ESD. Before you remove or install a module, touch any metal part of the chassis and keep that contact with the chassis during the installation process.
-
Page 10: What's Next
Chapter 2 Step 3: Install the Rx0L RAM Module Warning RAM modules may be susceptible to damage by Electro-Static Discharge (ESD). All industry-standard cautions should be followed to avoid ESD. Before you remove or install a module, touch any metal part of the chassis and keep that contact with the chassis during the installation process. -
Page 11: Installing Rx0Le Flash And Ram
Installing Rx0LE Flash and RAM This chapter contains information for users of Wyse Rx0LE thin clients who must install new flash and/or RAM. If you are installing firmware only, you can skip this chapter and proceed to"Installing WES2009 Firmware." IMPORTANT: •... -
Page 12: Procedures
Chapter 3 Procedures Step 1: Remove the Rx0LE Thin Client Left Side Cover Caution Follow all precautions listed in the Quick-Start Guide that came with your thin client for disconnecting and reconnecting the thin client. 1. Perform a proper shutdown of the thin client by closing all files and ending your session, and then press the power button to turn off the thin client. - Page 13 Installing Rx0LE Flash and RAM Step 2: Install the Rx0LE Flash Module Warning Flash modules may be susceptible to damage by Electro-Static Discharge (ESD). All industry-standard cautions should be followed to avoid ESD. Before you remove or install a module, touch any metal part of the chassis and keep that contact with the chassis during the installation process.
- Page 14 Chapter 3 Figure 9 Removing the existing flash module 3. Install the new flash module in the reverse order of removing the original flash module. Carefully press the flash module onto the standoff lock and connector, making sure to lock it into place. 4.
-
Page 15: What's Next
Installing Rx0LE Flash and RAM Step 3: Install the Rx0LE RAM Module Warning RAM modules may be susceptible to damage by Electro-Static Discharge (ESD). All industry-standard cautions should be followed to avoid ESD. Before you remove or install a module, touch any metal part of the chassis and keep that contact with the chassis during the installation process. - Page 16 Chapter 3 This page intentionally blank.
-
Page 17: Installing Wes2009 Firmware
Installing WES2009 Firmware This chapter includes the requirements and procedures you need to install and use Wyse USB Firmware Tool to update your thin client to WES2009 firmware. The purpose of the Wyse USB Firmware Tool is to configure a bootable USB key for device firmware. -
Page 18: Procedures
It is not recommended to use your desktop for the destination directory as there are several files that will be extracted from the .exe file. 3. Create a shortcut on the desktop for the Wyse USB Firmware Tool.exe file (see your operating system documentation). - Page 19 Installing WES2009 Firmware Figure 12 Wyse USB Firmware Tool wizard 2. Click Next to open the Select an Option dialog box. Figure 13 Configuration options 3. Select the Configure a single USB key to Copy or Update firmware option, and then click Next to open the Select the Configuration dialog box.
- Page 20 Chapter 4 6. (Optional) Leave the default-selected Preserve data partition check box (recommended in most cases) unless you do not want to preserve any existing custom data partition you have on the thin client (outside of the partition used by the firmware). This option is only available for use with thin clients using multiple data partitions totalling 4 GB or larger, allowing you to remove the partition used for custom data that is not write filter protected (this is the custom data...
- Page 21 At this time you can also replicate/duplicate the configured USB key (containing the firmware you want to push) for simultaneous usage on target devices (by users in several locations at the same time). For full Wyse USB ® Firmware Tool details, see Users Guide: Wyse USB Firmware Tool 1.13.
- Page 22 After the thin client displays the WES2009 desktop, you can verify the Version and that your general client information is correct. 1. On the General tab of the Client Information window (Start > All Programs > Wyse Client Information), verify the following: •...
- Page 23 Warning Use of the Software on more than one device requires that you first purchase from Wyse additional copies of, or licenses to, the Software. Contact your local Wyse distributor or Wyse Inside Sales at 1-800-800-9973 option 1 or 1-408-473-1200 option 1.
-
Page 24: Troubleshooting
Wyse USB Firmware Tool. If you experience problems booting from a configured USB key, it is recommended that you try a different brand of USB key. The following list of USB keys have been successfully tested with the Wyse USB Firmware Tool: •... - Page 25 Installing WES2009 Firmware This page intentionally blank.
- Page 26 Installation Guide ® Wyse R Class Conversion to WES2009 Issue: 090711 Written and published by: Wyse Technology Inc., September 2011 ® ® Created using FrameMaker and Acrobat...
