Use only for internal cluster communications
Choose this option if you are configuring an intra-cluster LAN adapter.
Use only for client access
Choose this option if you are configuring a client LAN adapter and System A and B reside on
different IP subnets.
NOTE
In this example, the intra-cluster LAN is shown first with the Adapter Name and IP
Address already filled in. However, your configuration may display the Client LAN
first.
Microsoft Cluster Server Setup, Assigning a Network Name to the intra-cluster LAN
10. Repeat the previous step for each LAN adapter. After you have configured all LAN adapters, click
Next.
11. Setup lists your LAN adapters and asks you to prioritize them for internal communications between
nodes. Move the Intra-cluster LAN to the top of the list so it has the highest priority. See the example
dialog below.
