LPr (with NetRAID Local and Shared Storage)

A NetRAID adapter may only be used for either shared storage or local storage; one adapter may not be used for
both. To use NetRAID adapters for both shared and local storage, you must use two adapters.
Configure NetServer Hardware and BIOS
1. Make sure you power down System A and power up System B.
2. Insert the HP NetServer Navigator CD in the CD-ROM drive and restart the server.
3. If you have special NetServer local SCSI bus options enter the Symbios utility by pressing Ctrl+C at the
Symbios boot banner during boot and set the options you need; otherwise allow the server to boot. The
server boots from the CD and displays the Navigator Main Menu.
NOTE If prompted that the HP NetServer Navigator BIOS is a newer version, choose
Continue and go to step 4; otherwise go to step 6.
4. To update the BIOS, choose NetServer Utilities | More NetServer Utilities |
BIOS Update Utility. Select Execute and follow the screen prompts to update the BIOS.
5. After the server reboots, return to the Navigator main menu by clicking the Back button twice on the
displayed window.
6. From the Navigator main menu, install a utility partition on the local storage disk by choosing
Configuration Assistant and Installation Assistant, Custom, Microsoft,
then either:
MS Windows NT4.0 Enterprise Edition Cluster Server if using Navigator if
L.15.05 or later.
MS Windows NT 4.0 Enterprise Edition, and No for automated NOS installation if
using Navigator L.15.04 or earlier.
7. Define the local storage RAID arrays. Select Configure Disk Array and use HP NetRAID
Assistant to define the arrays. Be sure to define the arrays for the local storage adapter (Adapter_0), not
the shared storage adapter (Adapter_1).
NOTE
DO NOT define the shared storage arrays at this time. They will be defined later.
8. Exit HP NetRAID Assistant. The server will reboot.
During the reboot, at the NetRAID banner press <Ctrl><M> to enter the NetRAID Express utility.
From the Management Menu, check that the BIOS is enabled. If it is not, enable it.
9. Exit the NetRAID Express utility and reboot. Navigator will return to the Custom Configuration screen.
Install a utility partition on the local storage disk by choosing Install/Update Utility
Partition.
After installing the utility partition, Navigator returns to the Custom Configuration screen.
10. Make an NT 4.0 Drivers floppy disk by choosing Create Driver Diskette(s), Execute,
and following the prompts. Label the floppy disk NT 4.0 Drivers.
11. Press the Back button three times to return the Navigator Main Menu.
12. Create a set of installation floppy disks for NetRAID Assistant by choosing NetServer Utilities
| Diskette Library. Select NetRAID Assistant for WindowsNT and Windows95
from the list and then the Execute button. Follow the instructions to create the NetRAID Assistant
installation floppy disks. Label the floppy disks HP NetRAID Assistant 1 and HP NetRAID Assistant 2.
