2. Select the following options when prompted:
Choose the unpartitioned space and install Windows NT.
Choose NTFS file system
When prompted to search for a Network Adapter, load NIC drivers for both the intra-cluster and the
client LAN. Be sure to load the correct intra-cluster LAN driver version as specified in the
Configuration Guide for your cluster. If you are using two HP D5013A NICs, load the driver twice,
once for the intra-cluster NIC and once for the client NIC.
Make sure TCP/IP Protocol is selected.
Other protocols may be selected in addition, but TCP/IP is required.
Set TCP/IP Properties for DNS, WINS Address, etc. at this time.
NOTE
The Client LAN IP addresses and Intra-cluster LAN IP addresses must be on different
subnets.

LH3

These procedures provide instructions for servers using NetRAID, SureStore E 12H, and Model 30/FC
shared storage solutions.
NOTE If you are use NetRAID adapters for both shared and local storage go to the next
procedure, LH3 (with NetRAID Local and Shared Storage) on page 18.
Configure NetServer Hardware and BIOS
1. Make sure you power down System A and power up System B.
2. Insert the HP NetServer Navigator CD in the CD-ROM drive and restart the server.
3. During reboot enter the Setup Utility by pressing F2.
4. Select User Preferences and then the LH3 Integrated NetRAID setting you want to use.
If you are using NetRAID for shared storage, disable the LH3 Integrated HP NetRAID.
It must be disabled otherwise it will conflict with the HP NetRAID adapter used for shared storage.
5. Exit the Setup Utility.
The server reboots. If you have special NetServer local SCSI bus options enter the Symbios utility, by
pressing Ctrl+C at the Symbios boot banner during reboot and set the options you need; otherwise allow
the server to reboot. The server boots from the CD and displays the Navigator Main menu.
NOTE If prompted that the HP NetServer Navigator BIOS is a newer version, choose
Continue and go to step 6; otherwise go to step 9.
6. To update the BIOS, choose Configuration Assistant and Installation Assistant,
then Custom, Microsoft, MS Windows NT 4.0 Enterprise Edition, and No for
automated NOS installation.
7. Select Update, then Execute. Follow screen prompts to update the BIOS.
8. After the server reboots, return to the Navigator main menu by clicking the Back button twice on the
displayed window.
