Specifi cations
Monitor Specifi cations
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
DisplayPort:
DisplayPort Connector:
DVI:
DVI-D 24pin:
VGA:
15pin Mini D-sub:
Display Colours
Synchronization Range
Viewing Angle
Image Formation Time
Resolutions Supported
Active Display Area
Landscape: Horiz.:
Portrait: Horiz.:
Power Supply
Current Rating
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and
necessary for all current fl at panel technologies when displaying non-native resolutions full screen. In fl at panel technologies, each dot on the screen is actually one
pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE:
Technical specifi cations are subject to change without notice.
MultiSync E223W
Diagonal:
55.87 cm/22.0 inches
55.87 cm/22.0 inches
1680 x 1050
Digital RGB
Digital RGB
Analog RGB
Sync
16,777,216
Horizontal:
31.5 kHz to 82.3 kHz (Analog)
31.5 kHz to 82.3 kHz (Digital)
Vertical:
56 Hz to 75 Hz
Left/Right:
±85° (CR > 10)
Up/Down:
±80° (CR > 10)
5 ms (Typ.)
720 x 400*
1
: VGA text
1
640 x 480*
at 60 Hz to 75 Hz
800 x 600*
1
at 56 Hz to 75 Hz
832 x 624*
1
at 75 Hz
1
1152 x 864*
at 75 Hz
1024 x 768*
1
at 60 Hz to 75 Hz
1
1152 x 870*
at 75 Hz
1280 x 960*
1
at 60 Hz to 75 Hz
1
1280 x 1024*
at 60 Hz to 75 Hz
1400 x 1050*
1
at 60 Hz to 75 Hz
1440 x 900*
1
at 60 Hz
1680 x 1050 at 60 Hz........................................... resolution for optimal display performance.
473.8 mm/18.7 inches
Vert.:
296.1 mm/11.7 inches
296.1 mm/11.7 inches
Vert.:
473.8 mm/18.7 inches
AC 100-240 V ~ 50/60 Hz
0.45 - 0.25 A
Landscape:
503.5 mm (W) x 383.3 - 493.3 mm (H) x 213.9 mm (D)
19.8 inches (W) x 15.1 - 19.4 inches (H) x 8.4 inches (D)
Portrait:
329.7 mm (W) x 519.9 - 575.7 mm (H) x 213.9 mm (D)
13.0 inches (W) x 20.5 - 22.7 inches (H) x 8.4 inches (D)
110 mm / 4.3 inches
4.9 kg (10.8 lbs)/Without stand: 3.2 kg (7.1 lbs)
5°C to 35°C/41°F to 95°F
Humidity:
20% to 80%
Altitude:
0 to 6,562 Feet/0 to 2,000 m
-10°C to 60°C/14°F to 140°F
Humidity:
10% to 85%
Altitude:
0 to 40,000 Feet/0 to 12,192 m
Notes
Active matrix; thin fi lm transistor (TFT) liquid crystal
display (LCD); 0.282 mm dot pitch; 250 cd/m
luminance; 1000:1 contrast ratio (typical), (25000:1
Contrast ratio, Dynamic).
DisplayPort Complies with Standard V1.1a,
applicable to HDCP
DVI (HDCP)
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Composite sync.TTL level Positive/Negative
Sync on Green
(Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
Depends on display card used.
Automatically
Automatically
Automatically
Some systems may not support all modes listed.
NEC DISPLAY SOLUTIONS cites recommended
English-15
2
white
