Chapter 4
CMOS checksum error - Default
loaded
CMOS battery failed
Password is cleared!...Please set
switch #3 to off
CMOS is cleared... Please set switch
4 to off
Memory test fail
Primary master drive fails
Primary slave drive fails
Secondary master drive fails
Secondary slave drive fails
SMART failure predicted on primary
master: xxxxxxxxx
• If this message displays after you have intentionally
cleared the CMOS, it is simply a warning message to
inform you that the CMOS has been loaded to default
values. No action is required.
• If this message appears when the server is powered up
after being off for a period of time, it indicates the
CMOS battery needs to be checked. See
Chapter 7.
1. Make sure the CMOS battery is seated correctly.
2. If error persists, replace the CMOS battery. See
tery" in Chapter 7.
• Power down the server and reset configuration switch 3
to Off. See "Clearing the CMOS and Passwords"
in this chapter.
• Power down the server and reset configuration switch 4
to Off. See "Clearing the CMOS and Passwords"
in this chapter.
This message indicates that one or more of the DIMMs is
bad.
1. Load the BIOS default CMOS configuration by press-
ing F10, then F5 and F6 during POST.
2. Make sure that all DIMMs are HP qualified. Refer to
"Memory Modules" in
3. Remove all DIMMs and re-insert them one at a time to
determine which DIMM(s) failed. Replace the bad
DIMM(s).
BIOS detects the device installed in IDE primary master
failed its test.
• Replace the IDE device installed in the primary master
drive.
BIOS detects the device installed in IDE primary slave
failed its test.
• Replace the IDE device installed in the primary slave
drive.
BIOS detects the device installed in IDE secondary mas-
ter failed its test.
• Replace the IDE device installed in the secondary
master drive.
BIOS detects the device installed in IDE secondary slave
failed its test.
• Replace the IDE device installed in the secondary slave
drive.
BIOS predicts a future failure on xxxxxxxx (drive brand
name and ID).
1. Press F1 to continue booting up the server.
2. Store all the data on the failing hard drive to another
device.
3. Power off the server and replace the hard drive. Refer
to Chapter 7‚ Replacing
"Battery"
"Bat-
later
later
Chapter 3.
Parts.
Diagnostics
in
56
