1.12.4 Thermal Monitoring
Figure 13 shows the location of the sensors and fan connectors.
E
A
C
D
Item
Description
A
Remote ambient temperature sensor
B
Thermal diode, located on processor die
C
Ambient temperature sensor, internal to hardware monitoring and fan control ASIC
D
Processor fan
E
Rear chassis fan
F
Front chassis fan
1
3
1
2
1
4
Figure 13. Thermal Sensors and Fan Connectors
1 3
B
F
