Table 3.

Board Components Shown in Figure 1

Item/callout
from Figure 1 Description
A
Front panel audio connector
B
Back panel connectors
C
Main power connector
D
Front panel USB connectors [2]
E
Serial ATA connectors [4]
F
PCI Express x16 bus add-in card connector
G
PCI Conventional bus add-in card connectors [2]
H PCI Express x1 bus add-in card connector
I
Speaker
J IEEE-1394a controller (optional)
K
BIOS Setup configuration jumper block
L Front panel IEEE-1394a connectors (optional) [2]
M
Legacy I/O controller
N Diskette drive connector
O
Front panel connector
P Front chassis fan connector
Q
Auxiliary front panel power LED connector
R
Intel 82801G I/O Controller Hub (ICH7)
S
LGA775 processor socket
T
Intel 82945P MCH
U
Remote thermal sensor
V
Processor core power connector
W
Processor fan connector
X
DIMM Channel A sockets [2]
Y DIMM Channel B sockets [2]
Z
Rear chassis fan connector
AA SPI flash device
BB
Battery
CC Ethernet device
DD
Audio codec
EE Parallel ATE IDE connector
FF
Chassis intrusion connector
Product Description
13
