1.3 Online Support

To find information about...
Intel Desktop Board D945PAW under
"Desktop Board Products" or "Desktop
Board Support"
Available configurations for the Desktop
Board D945PAW
Processor data sheets
ICH7 addressing
Custom splash screens
Audio software and utilities
LAN software and drivers
Supported video modes

1.4 Processor

The board is designed to support Intel Pentium 4 processors in an LGA775 processor socket with a
1066, 800, or 533 MHz system bus. See the Intel web site listed below for the most up-to-date list
of supported processors.
For information about...
Supported processors
CAUTION
Use only the processors listed on web site above. Use of unsupported processors can damage the
board, the processor, and the power supply.
INTEGRATOR'S NOTE
Use only ATX12V-compliant power supplies.
For information about
Power supply connectors
Visit this World Wide Web site:
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
http://developer.intel.com/design/motherbd/aw/aw_available.htm
http://www.intel.com/design/litcentr
http://developer.intel.com/products/chipsets
http://intel.com/design/motherbd/gen_indx.htm
http://www.intel.com/design/motherbd
http://www.intel.com/design/motherbd
http://www.intel.com/design/motherbd/aw/aw_documentation.htm
Refer to:
http://www.intel.com/design/motherbd/aw/aw_proc.htm
Product Description
Refer to
Section 2.8.2.1, page 51
15
