D945PAW
Technical Product Specification
®
The Intel
Desktop Board D945PAW may contain design defects or errors known as errata that may cause the product to deviate from published specifications. Current
characterized errata are documented in the Intel Desktop Board D945PAW Specification Update.
®
Desktop Board
May 2005
Order Number: D14067-001US
Advertisement
Table of Contents
Related Manuals for Intel BOXD945PAWLK - Desktop Board D945PAW
Summary of Contents for Intel BOXD945PAWLK - Desktop Board D945PAW
- Page 1 Order Number: D14067-001US ® The Intel Desktop Board D945PAW may contain design defects or errors known as errata that may cause the product to deviate from published specifications. Current characterized errata are documented in the Intel Desktop Board D945PAW Specification Update.
-
Page 2: Revision History
Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your product order. Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained from: Intel Corporation P.O. -
Page 3: Intended Audience
Preface This Technical Product Specification (TPS) specifies the board layout, components, connectors, ® power and environmental requirements, and the BIOS for the Intel Desktop Board D945PAW. It describes the standard product and available manufacturing options. Intended Audience The TPS is intended to provide detailed, technical information about the Desktop Board D945PAW and its components to the vendors, system integrators, and other engineers and technicians who need this level of information. - Page 4 Intel Desktop Board D945PAW Technical Product Specification Other Common Notation Used after a signal name to identify an active-low signal (such as USBP0#) (NxnX) When used in the description of a component, N indicates component type, xn are the relative coordinates of its location on the Desktop Board D945PAW, and X is the instance of the particular part at that general location.
-
Page 5: Table Of Contents
Block Diagram ....................14 Online Support ......................15 Processor ........................15 System Memory ......................16 1.5.1 Memory Configurations ................. 17 ® Intel 945P Chipset...................... 21 1.6.1 USB ....................... 21 1.6.2 IDE Support ....................22 1.6.3 Real-Time Clock, CMOS SRAM, and Battery..........23 PCI Express* Connectors .................... - Page 6 Intel Desktop Board D945PAW Technical Product Specification 2 Technical Reference Introduction ........................39 Memory Resources ...................... 39 2.2.1 Addressable Memory..................39 2.2.2 Memory Map....................41 DMA Channels ......................41 Fixed I/O Map....................... 42 PCI Configuration Space Map..................43 Interrupts ........................44 PCI Conventional Interrupt Routing Map ..............
- Page 7 Contents Adjusting Boot Speed....................74 3.8.1 Peripheral Selection and Configuration ............74 3.8.2 BIOS Boot Optimizations................74 BIOS Security Features ....................75 4 Error Messages and Beep Codes Speaker ........................77 BIOS Beep Codes......................77 BIOS Error Messages ....................77 Port 80h POST Codes ....................
- Page 8 Intel Desktop Board D945PAW Technical Product Specification System Memory Map ....................41 DMA Channels ......................41 I/O Map ........................42 PCI Configuration Space Map..................43 Interrupts ........................44 PCI Interrupt Routing Map ................... 46 Back Panel Connectors Shown in Figure 16..............47 Component-side Connectors Shown in Figure 17 ............
-
Page 9: Product Description 1.1 Power Connector Terminology Change
Power Connector Terminology Change ................. 9 Overview ........................10 Online Support ......................15 Processor ........................15 System Memory ......................16 ® Intel 945P Chipset...................... 21 PCI Express* Connectors .................... 23 IEEE-1394a Connectors (Optional)................24 Legacy I/O Controller ....................24 1.10 Audio Subsystem ......................25 1.11 LAN Subsystem ...................... -
Page 10: Overview
Intel Desktop Board D945PAW Technical Product Specification 1.2 Overview 1.2.1 Feature Summary Table 1 summarizes the major features of the board. Table 1. Feature Summary Form Factor microBTX Form Factor (10.40 inches by 10.50 inches [264.16 millimeters by 266.70 millimeters]) ®... -
Page 11: Manufacturing Options
• Fan speed control 1.2.2 Manufacturing Options Table 2 describes the manufacturing options. Not every manufacturing option is available in all marketing channels. Please contact your Intel representative to determine which manufacturing options are available to you. Table 2. Manufacturing Options... -
Page 12: Board Layout
Intel Desktop Board D945PAW Technical Product Specification 1.2.3 Board Layout Figure 1 shows the location of the major components. OM17843 Figure 1. Board Components Table 3 lists the components identified in Figure 1. -
Page 13: Board Components Shown In Figure 1
Legacy I/O controller Diskette drive connector Front panel connector Front chassis fan connector Auxiliary front panel power LED connector Intel 82801G I/O Controller Hub (ICH7) LGA775 processor socket Intel 82945P MCH Remote thermal sensor Processor core power connector Processor fan connector... -
Page 14: Block Diagram
Intel Desktop Board D945PAW Technical Product Specification 1.2.4 Block Diagram Figure 2 is a block diagram of the major functional areas. Gigabit Ethernet PCI Express x1 Interface Controller (Optional) Connector PCI Express x1 Slot 1 Back Panel/Front Panel USB Ports... -
Page 15: Online Support
1.4 Processor The board is designed to support Intel Pentium 4 processors in an LGA775 processor socket with a 1066, 800, or 533 MHz system bus. See the Intel web site listed below for the most up-to-date list of supported processors. -
Page 16: System Memory
Intel Desktop Board D945PAW Technical Product Specification 1.5 System Memory The board has four DIMM sockets and support the following memory features: • 1.8 V (only) DDR2 SDRAM DIMMs with gold-plated contacts • Unbuffered, single-sided or double-sided DIMMs with the following restriction: Double-sided DIMMS with x16 organization are not supported. -
Page 17: Memory Configurations
Product Description 1.5.1 Memory Configurations The Intel 82945P MCH supports two types of memory organization: • Dual channel (Interleaved) mode. This mode offers the highest throughput for real world applications. Dual channel mode is enabled when the installed memory capacities of both DIMM channels are equal. -
Page 18: Dual Channel (Interleaved) Mode Configuration With Two Dimms
Intel Desktop Board D945PAW Technical Product Specification 1.5.1.1 Dual Channel (Interleaved) Mode Configurations Figure 4 shows a dual channel configuration using two DIMMs. In this example, the DIMM0 (blue) sockets of both channels are populated with identical DIMMs. Channel A, DIMM 0... -
Page 19: Dual Channel (Interleaved) Mode Configuration With Four Dimms
Product Description Figure 6 shows a dual channel configuration using four DIMMs. In this example, the combined capacity of the two DIMMs in Channel A equal the combined capacity of the two DIMMs in Channel B. Also, the DIMMs are matched between DIMM0 and DIMM1 of both channels. Channel A, DIMM 0 256 MB 512 MB... -
Page 20: Single Channel (Asymmetric) Mode Configuration With One Dimm
Intel Desktop Board D945PAW Technical Product Specification 1.5.1.2 Single Channel (Asymmetric) Mode Configurations NOTE Dual channel (Interleaved) mode configurations provide the highest memory throughput. Figure 7 shows a single channel configuration using one DIMM. In this example, only the DIMM0 (blue) socket of Channel A is populated. -
Page 21: Intel ® 945P Chipset
945P Chipset The Intel 945P chipset consists of the following devices: • Intel 82945P Memory Controller Hub (MCH) with Direct Media Interface (DMI) interconnect • Intel 82801G I/O Controller Hub (ICH7) with DMI interconnect The MCH component provides interfaces to the CPU, memory, PCI Express, and the DMI interconnect. -
Page 22: Ide Support
Intel Desktop Board D945PAW Technical Product Specification 1.6.2 IDE Support The board provides five IDE interface connectors: • One parallel ATA IDE connector that supports two devices • Four serial ATA IDE connectors that support one device per connector 1.6.2.1 Parallel ATE IDE Interface The ICH7’s Parallel ATA IDE controller has one bus-mastering Parallel ATA IDE interface. -
Page 23: Real-Time Clock, Cmos Sram, And Battery
Product Description NOTE Many Serial ATA drives use new low-voltage power connectors and require adaptors or power supplies equipped with low-voltage power connectors. For more information, see: http://www.serialata.org/ For information about Refer to The location of the Serial ATA IDE connectors Figure 17, page 48 1.6.3 Real-Time Clock, CMOS SRAM, and Battery A coin-cell battery (CR2032) powers the real-time clock and CMOS memory. -
Page 24: Ieee-1394A Connectors (Optional)
Intel Desktop Board D945PAW Technical Product Specification 1.8 IEEE-1394a Connectors (Optional) The optional IEEE-1394a interface addresses interconnection of both computer peripherals and consumer electronics. The IEEE-1394a interface provides a throughput ranging from 100 Mbits/sec to 400 Mbits/sec. As a manufacturing option, the board includes three IEEE-1394a connectors as follows: •... -
Page 25: Diskette Drive Controller
The location of the keyboard and mouse connectors Figure 16, page 47 1.10 Audio Subsystem The board supports the Intel High Definition audio subsystem based on the Sigmatel* 9220 audio codec. The audio subsystem supports the following features: • Advanced jack sense for the back panel audio jacks that enables the audio codec to recognize the device that is connected to an audio port. -
Page 26: 6-Channel (5.1) Audio Subsystem
Intel Desktop Board D945PAW Technical Product Specification 1.10.3 6-Channel (5.1) Audio Subsystem The 6-channel (5.1) audio subsystem includes the following: • Intel 82801G I/O Controller Hub (ICH7) • Sigmatel 9220 audio codec • Microphone input that supports a single dynamic, condenser, or electret microphone The back panel audio connectors are configurable through the audio device drivers. -
Page 27: Lan Subsystem
PCI Conventional bus power management ⎯ Supports ACPI technology ⎯ Supports LAN wake capabilities 1.11.1 LAN Subsystem Software LAN software and drivers are available from Intel’s World Wide Web site. For information about Refer to Obtaining LAN software and drivers Section 1.3, page 15... -
Page 28: Lan Connector Led Locations
Intel Desktop Board D945PAW Technical Product Specification ® 1.11.2.1 Intel 82562GX Physical Layer Interface Device The Intel 82562GX provides the following functions: • 10/100 Ethernet LAN connectivity • Full device driver compatibility • Programmable transit threshold • Configuration EEPROM that contains the MAC address 1.11.2.2... -
Page 29: Gigabit Lan Subsystem
Product Description 1.11.3 Gigabit LAN Subsystem The Gigabit (10/100/1000 Mbits/sec) LAN subsystem includes the Intel 82573/82574 controller and an RJ-45 LAN connector with integrated status LEDs. ® 1.11.3.1 Intel 82573V/82574V Gigabit Ethernet Controller The Intel 82573V/82574V Gigabit Ethernet Controller supports the following features: •... -
Page 30: Hardware Management Subsystem
Intel Desktop Board D945PAW Technical Product Specification 1.12 Hardware Management Subsystem The hardware management features enable the board to be compatible with the Wired for Management (WfM) specification. The board has several hardware management features, including the following: • Chassis intrusion detection •... -
Page 31: Thermal Monitoring
Product Description 1.12.4 Thermal Monitoring Figure 13 shows the location of the sensors and fan connectors. OM17844 Item Description Remote ambient temperature sensor Thermal diode, located on processor die Ambient temperature sensor, internal to hardware monitoring and fan control ASIC Processor fan Rear chassis fan Front chassis fan... -
Page 32: Power Management
Intel Desktop Board D945PAW Technical Product Specification 1.13 Power Management Power management is implemented at several levels, including: • Software support through Advanced Configuration and Power Interface (ACPI) • Hardware support: ⎯ Power connector ⎯ Fan connectors ⎯ LAN wake capabilities ⎯... -
Page 33: Power States And Targeted System Power
Product Description 1.13.1.1 System States and Power States Under ACPI, the operating system directs all system and device power state transitions. The operating system puts devices in and out of low-power states based on user preferences and knowledge of how devices are being used by applications. Devices that are not being used can be turned off. -
Page 34: Hardware Support
Intel Desktop Board D945PAW Technical Product Specification 1.13.1.3 Wake-up Devices and Events Table 9 lists the devices or specific events that can wake the computer from specific states. Table 9. Wake-up Devices and Events These devices/events can wake up the computer…... -
Page 35: Power Connector
Product Description Resume on Ring enables telephony devices to access the computer when it is in a power-managed state. The method used depends on the type of telephony device (external or internal). NOTE The use of Resume on Ring and Wake from USB technologies from an ACPI state requires an operating system that provides full ACPI support. - Page 36 Intel Desktop Board D945PAW Technical Product Specification Depending on the LAN implementation, the board supports LAN wake capabilities with ACPI in the following ways: • The PCI Express WAKE# signal • The PCI Conventional bus PME# signal for PCI 2.3 compliant LAN designs •...
-
Page 37: Trusted Platform Module (Optional)
TPM protects encryption and signature keys at their most vulnerable stages—operations when the keys are being used unencrypted in plain-text form. The TPM is specifically designed to shield unencrypted keys and platform authentication information from software-based attacks. For information about Refer to http://www.intel.com/design/motherbd/aw/... - Page 38 Intel Desktop Board D945PAW Technical Product Specification...
-
Page 39: Technical Reference
2 Technical Reference What This Chapter Contains Introduction ........................39 Memory Resources ...................... 39 DMA Channels ......................41 Fixed I/O Map....................... 42 PCI Configuration Space Map..................43 Interrupts ........................44 PCI Conventional Interrupt Routing Map ..............45 Connectors........................46 Jumper Block ....................... 56 2.10 Mechanical Considerations .................. -
Page 40: Detailed System Memory Address Map
Intel Desktop Board D945PAW Technical Product Specification • MCH base address registers, internal graphics ranges, PCI Express ports (up to 512 MB) • Memory-mapped I/O that is dynamically allocated for PCI Conventional and PCI Express add-in cards The amount of installed memory that can be used will vary based on add-in cards and BIOS settings. -
Page 41: Memory Map
Technical Reference 2.2.2 Memory Map Table 10 lists the system memory map. Table 10. System Memory Map Address Range (decimal) Address Range (hex) Size Description 1024 K - 4194304 K 100000 - FFFFFFFF 4095 MB Extended memory 960 K - 1024 K F0000 - FFFFF 64 KB Runtime BIOS... -
Page 42: Fixed I/O Map
Intel Desktop Board D945PAW Technical Product Specification 2.4 Fixed I/O Map Table 12. I/O Map Address (hex) Size Description 0000 - 00FF 256 bytes Used by the Desktop Board D945PAW. Refer to the ICH7 data sheet for dynamic addressing information. -
Page 43: Pci Configuration Space Map
PCI Conventional bus connector 1 (Note 2) PCI Conventional bus connector 2 (Note 2) Intel 82562 10/100 Mbits/sec LAN PLC (if present) (Note 1) PCI Express video controller Notes: Present only when a PCI Express x16 graphics card is installed. -
Page 44: Interrupts
Intel Desktop Board D945PAW Technical Product Specification 2.6 Interrupts The interrupts can be routed through either the Programmable Interrupt Controller (PIC) or the Advanced Programmable Interrupt Controller (APIC) portion of the ICH7 component. The PIC is supported in Windows 98 SE and Windows ME and uses the first 16 interrupts. The APIC is supported in Windows 2000 and Windows XP and supports a total of 24 interrupts. -
Page 45: Pci Conventional Interrupt Routing Map
Technical Reference 2.7 PCI Conventional Interrupt Routing Map This section describes interrupt sharing and how the interrupt signals are connected between the PCI Conventional bus connectors and onboard PCI Conventional devices. The PCI Conventional specification describes how interrupts can be shared between devices attached to the PCI Conventional bus. -
Page 46: Connectors
Intel Desktop Board D945PAW Technical Product Specification Table 15. PCI Interrupt Routing Map ICH7 PIRQ Signal Name PCI Interrupt Source PIRQA PIRQB PIRQC PIRQD PIRQE PIRQF PIRQG PIRQH ICH7 LAN INTA PCI bus connector 1 INTD INTA INTB INTC PCI bus connector 2... -
Page 47: Back Panel Connectors
Technical Reference 2.8.1 Back Panel Connectors Figure 16 shows the location of the back panel connectors. The back panel connectors are color-coded. The figure legend (Table 16) lists the colors used (when applicable). OM17951 Figure 16. Back Panel Connectors Table 16 lists the back panel connectors identified in Figure 16. NOTE The back panel audio line out connector is designed to power headphones or amplified speakers only. -
Page 48: Component-Side Connectors
Intel Desktop Board D945PAW Technical Product Specification 2.8.2 Component-side Connectors Figure 17 shows the locations of the component-side connectors. G I J 1 13 OM17845 Figure 17. Component-side Connectors... -
Page 49: Component-Side Connectors Shown In Figure 17
Technical Reference Table 17 lists the component-side connectors identified in Figure 17. Table 17. Component-side Connectors Shown in Figure 17 Item/callout from Figure 17 Description Rear chassis fan connector Front panel audio connector Parallel ATA IDE connector Chassis intrusion connector Serial ATA connector 0 Serial ATA connector 1 Serial ATA connector 2... -
Page 50: Front Panel Audio Connector
Intel Desktop Board D945PAW Technical Product Specification Table 18. Front Panel Audio Connector Signal Name Signal Name Port E [Port 1] Left Channel Ground Port E [Port 1] Right Channel Presence# (dongle present) Port F [Port 2] Right Channel Port E [Port 1] Sense return... -
Page 51: Main Power Connector
Main power – a 2 x 12 connector. This connector is compatible with 2 x 10 connectors previously used on Intel Desktop boards. The board supports the use of ATX12V power supplies with either 2 x 10 or 2 x 12 main power cables. When using a power supply with a 2 x 10 main power cable, attach that cable on the rightmost pins of the main power connector, leaving pins 11, 12, 23, and 24 unconnected. -
Page 52: Auxiliary Front Panel Power/Sleep Led Connector
Intel Desktop Board D945PAW Technical Product Specification 2.8.2.2 Add-in Card Connectors The board has the following add-in card connectors: • PCI Express x16: one connector supporting simultaneous transfer speeds up to 8 GBytes/sec. • PCI Express x1: one PCI Express x1 connector. The x1 interface supports simultaneous transfer speeds up to 500 MBytes/sec. -
Page 53: Connection Diagram For Front Panel Connector
Technical Reference 2.8.2.4 Front Panel Connector This section describes the functions of the front panel connector. Table 26 lists the signal names of the front panel connector. Figure 18 is a connection diagram for the front panel connector. Table 26. Front Panel Connector Signal In/Out... -
Page 54: States For A One-Color Power Led
Intel Desktop Board D945PAW Technical Product Specification 2.8.2.4.2 Reset Switch Connector [Purple] Pins 5 and 7 [Purple] can be connected to a momentary single pole, single throw (SPST) type switch that is normally open. When the switch is closed, the board resets and runs the POST. -
Page 55: Connection Diagram For Front Panel Usb Connectors
Technical Reference 2.8.2.5 Front Panel USB Connectors Figure 19 is a connection diagram for the front panel USB connectors. INTEGRATOR’S NOTES • The +5 V DC power on the USB connector is fused. • Pins 1, 3, 5, and 7 comprise one USB port. •... -
Page 56: Jumper Block
Intel Desktop Board D945PAW Technical Product Specification 2.9 Jumper Block CAUTION Do not move the jumper with the power on. Always turn off the power and unplug the power cord from the computer before changing a jumper setting. Otherwise, the board could be damaged. -
Page 57: Mechanical Considerations
Technical Reference 2.10 Mechanical Considerations 2.10.1 Form Factor The board is designed to fit into a BTX-form-factor chassis. Figure 22 illustrates the mechanical form factor of the board. Dimensions are given in inches [millimeters]. The outer dimensions are 10.40 inches by 10.50 inches [264.16 millimeters by 266.70 millimeters]. 7.550 9.150 [191.77]... -
Page 58: I/O Shield
Additional design considerations for I/O shields relative to chassis requirements are described in the ATX specification. NOTE The I/O shield drawings in this document are for reference only. I/O shields compliant with the ATX chassis specification 2.03 are available from Intel. 172.93 REF [6.808] 13.00 TYP [0.512]... -
Page 59: Electrical Considerations
Technical Reference 2.11 Electrical Considerations 2.11.1 DC Loading Table 30 lists the DC loading characteristics of the boards. This data is based on a DC analysis of all active components within the board that impact its power delivery subsystems. The analysis does not include PCI add-in cards. -
Page 60: Fan Connector Current Capability
Intel Desktop Board D945PAW Technical Product Specification 2.11.3 Fan Connector Current Capability CAUTION The processor fan must be connected to the processor fan connector, not to a chassis fan connector. Connecting the processor fan to a chassis fan connector may result in onboard component damage that will halt fan operation. -
Page 61: Thermal Considerations
All responsibility for determining the adequacy of any thermal or system design remains solely with the reader. Intel makes no warranties or representations that merely following the instructions presented in this document will result in a system with adequate thermal performance. -
Page 62: Localized High Temperature Zones
Intel Desktop Board D945PAW Technical Product Specification CAUTION Ensure that proper airflow is maintained in the processor voltage regulator circuit. Failure to do so may result in damage to the voltage regulator circuit. The processor voltage regulator area (item A in Figure 25) can reach a temperature of up to 85 C in an open chassis. -
Page 63: Reliability
C (under bias, without heatsink) C (under bias, with heatsink) For information about Refer to Intel Pentium 4 processor datasheets and specification updates Section 1.3, page 15 2.13 Reliability The Mean Time Between Failures (MTBF) prediction is calculated using component and subassembly random failure rates. -
Page 64: Environmental
Intel Desktop Board D945PAW Technical Product Specification 2.14 Environmental Table 33 lists the environmental specifications for the board. Table 33. Environmental Specifications Parameter Specification Temperature -40 °C to +70 °C Non-Operating 0 °C to +55 °C Operating Shock Unpackaged 50 g trapezoidal waveform... -
Page 65: Regulatory Compliance
Technical Reference 2.15 Regulatory Compliance This section describes the Desktop Boards’ compliance with U.S. and international safety and electromagnetic compatibility (EMC) regulations. 2.15.1 Safety Regulations Table 34 lists the safety regulations that the Desktop Board D945PAW complies with when correctly installed in a compatible host system. Table 34. -
Page 66: European Union Declaration Of Conformity Statement
• Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to the equipment not expressly approved by Intel Corporation could void the user’s authority to operate the equipment. Tested to comply with FCC standards for home or office use. -
Page 67: Recycling Considerations
Svenska Denna produkt har tillverkats i enlighet med EG-direktiv 89/336/EEC & 73/23/EEC. 2.15.4 Recycling Considerations Intel encourages its customers to recycle its products and their components (e.g., batteries, circuit boards, plastic enclosures, etc.) whenever possible. In the U.S., a list of recyclers in your area can be found at: http://www.eiae.org/... -
Page 68: Product Certification Markings (Board Level)
Product Certification Markings Description Marking UL joint US/Canada Recognized Component mark. Includes adjacent UL file number for Intel Desktop Boards: E210882 (component side). FCC Declaration of Conformity logo mark for Class B equipment; includes Intel name and D945PAW model designation (component side). -
Page 69: Overview Of Bios Features
BIOS Security Features ....................75 3.1 Introduction The boards use an Intel BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated using a disk-based program. The SPI Flash contains the BIOS Setup program, POST, the PCI auto-configuration utility, and Plug and Play support. -
Page 70: Bios Flash Memory Organization
Intel Desktop Board D945PAW Technical Product Specification Table 37 lists the BIOS Setup program menu features. Table 37. BIOS Setup Program Menu Bar Maintenance Main Advanced Security Power Boot Exit Clears Displays Configures Sets Configures Selects boot Saves or passwords and... -
Page 71: System Management Bios (Smbios)
Overview of BIOS Features automatically configured for Logical Block Addressing (LBA) and to PIO Mode 3 or 4, depending on the capability of the drive. You can override the auto-configuration options by specifying manual configuration in the BIOS Setup program. To use ATA-66/100 features the following items are required: •... -
Page 72: Bios Updates
To install an operating system that supports USB, follow the operating system’s installation instructions. 3.6 BIOS Updates The BIOS can be updated using either of the following utilities, which are available on the Intel World Wide Web site: • ®... -
Page 73: Boot Options
Overview of BIOS Features 3.7 Boot Options In the BIOS Setup program, the user can choose to boot from a diskette drive, hard drives, CD-ROM, or the network. The default setting is for the diskette drive to be the first boot device, the hard drive second, and the ATAPI CD-ROM third. -
Page 74: Adjusting Boot Speed
It is possible to optimize the boot process to the point where the system boots so quickly that the Intel logo screen (or a custom logo splash screen) will not be seen. Monitors and hard disk drives with minimum initialization times can also contribute to a boot time that might be so fast that necessary logo screens and POST messages cannot be seen. -
Page 75: Bios Security Features
Overview of BIOS Features 3.9 BIOS Security Features The BIOS includes security features that restrict access to the BIOS Setup program and who can boot the computer. A supervisor password and a user password can be set for the BIOS Setup program and for booting the computer, with the following restrictions: •... - Page 76 Intel Desktop Board D945PAW Technical Product Specification...
-
Page 77: Error Messages And Beep Codes
4 Error Messages and Beep Codes What This Chapter Contains Speaker ........................77 BIOS Beep Codes......................77 BIOS Error Messages ....................77 Port 80h POST Codes ....................78 4.1 Speaker The board-mounted speaker provides audible error code (beep code) information during POST. For information about Refer to The location of the onboard speaker... -
Page 78: Port 80H Post Codes
Intel Desktop Board D945PAW Technical Product Specification 4.4 Port 80h POST Codes During the POST, the BIOS generates diagnostic progress codes (POST-codes) to I/O port 80h. If the POST fails, execution stops and the last POST code generated is left at port 80h. This code is useful for determining the point where an error occurred. -
Page 79: Port 80H Post Codes
Error Messages and Beep Codes Table 44. Port 80h POST Codes POST Code Description of POST Operation Host Processor Power-on initialization of the host processor (Boot Strap Processor) Host processor Cache initialization (including APs) Starting Application processor initialization SMM initialization Chipset Initializing a chipset component Memory... - Page 80 Intel Desktop Board D945PAW Technical Product Specification Table 44. Port 80h POST Codes (continued) POST Code Description of POST Operation Keyboard (PS2 or USB) Resetting keyboard Disabling keyboard Detecting presence of keyboard Enabling the keyboard Clearing keyboard input buffer Instructing keyboard controller to run Self Test (PS2 only)
- Page 81 Error Messages and Beep Codes Table 44. Port 80h POST Codes (continued) POST Code Description of POST Operation DXE Drivers Waiting for user input Checking password Entering BIOS setup TBD – Flash Update Calling Legacy Option ROMs TBD – Calling INT 19. One beep unless silent boot is enabled. TBD –...
-
Page 82: Typical Port 80H Post Sequence
Intel Desktop Board D945PAW Technical Product Specification Table 45. Typical Port 80h POST Sequence POST Code Description Initializing a chipset component Reading SPD from memory DIMMs Detecting presence of memory DIMMs Configuring memory Testing memory Loading recovery capsule Entered DXE phase...
