CONVERTEON™ Family
Media Converter Chassis
AT-CV5000

Installation Guide

613-000586 Rev. B

Advertisement

Table of Contents
loading

Related Manuals for Allied Telesis Converteon AT-CV5000-

Summary of Contents for Allied Telesis Converteon AT-CV5000-

  • Page 1: Installation Guide

    CONVERTEON™ Family Media Converter Chassis AT-CV5000 Installation Guide 613-000586 Rev. B...
  • Page 2 Allied Telesis, Inc. reserves the right to make changes in specifications and other information contained in this document without prior written notice. The information provided herein is subject to change without notice. In no event shall Allied Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis, Inc.
  • Page 3 Electrical Safety and Emissions Standards This product meets the following standards. Radiated Energy Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 Translated Safety Statements Important: The indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” (613-000405) posted on the Allied Telesis website at www.alliedtelesis.com.

  • Page 5: Table Of Contents

    Preface ... 13 Safety Symbols Used in this Document... 14 Where to Find Web-based Guides ... 15 Contacting Allied Telesis ... 16 Online Support ... 16 Email and Telephone Support ... 16 Warranty ... 16 Returning Products... 16 Sales or Corporate Information ... 16 Management Software Updates ...
  • Page 6 Contents Unpacking the Chassis ... 45 Installing the Power Cord Retaining Clip (AC Powered Chassis Only)... 46 Installing the AT-CV5000 Chassis in a Rack ... 48 Grounding the AT-CV5000 Chassis... 50 Installing a Converteon™ Line Card ... 52 Cabling a Converteon™ Line Card in an AT-CV5000 Chassis... 55 Cabling a Fiber Optic Port ...
  • Page 7 AT-CV5000 Media Converter Chassis Installation Guide Using a Cartridge-Type Cleaner ... 110 Using a Swab ... 112...
  • Page 8 Contents...
  • Page 9 Figures Figure 1. AT-CV5000 Media Converter ... 18 Figure 2. Front Panel of the AT-CV5000 Chassis ... 20 Figure 3. Rear Panel of the AT-CV5000 Chassis (AC Version) ... 20 Figure 4. Rear Panel of the AT-CV5000 Chassis (DC Version) ... 20 Figure 5.
  • Page 10 Figures Figure 51. Tightening the Captive Screw... 77 Figure 52. Resetting the AT-CV5M01 Management Card ... 78 Figure 53. Inserting an AT-CM70S Line Card... 80 Figure 54. Tightening the Captive Screw on the AT-CM70S Line Card ... 80 Figure 55. Resetting Converteon™ Line Cards/Rear Expansion Module... 81 Figure 56.
  • Page 11 Tables Table 1. Safety Symbols ... 14 Table 2. Status LEDs on the LED Interface Card ... 22 Table 3. Status LEDs on the AT-CV5M01 Management Card ... 26 Table 4. MDI Pin Signals (10/100Base-TX) ... 103 Table 5. MDI-X Pin Signals (10/100Base-TX) ... 103 Table 6.
  • Page 12 Tables...

  • Page 13: Preface

    This guide contains instructions on how to install an AT-CV5000 Media Converter and the Converteon™ Series line cards. This preface contains the following sections: “Safety Symbols Used in this Document” on page 14 “Where to Find Web-based Guides” on page 15 “Contacting Allied Telesis” on page 16...

  • Page 14: Safety Symbols Used In This Document

    Preface Safety Symbols Used in this Document This document uses the safety symbols defined in Table 1. Symbol Table 1. Safety Symbols Meaning Caution Performing or omitting a specific action may result in equipment damage or loss of data. Warning Performing or omitting a specific action may result in electrical shock.

  • Page 15: Where To Find Web-Based Guides

    AT-CV5000 Media Converter Chassis Installation Guide Where to Find Web-based Guides The installation and user guides for all Allied Telesis products are available in portable document format (PDF) on our web site at www.alliedtelesis.com. You can view the documents online or download...

  • Page 16: Contacting Allied Telesis

    Internet sites: Software Updates If you prefer to download new software from the Allied Telesis FTP server from your workstation’s command prompt, you will need FTP client software and you must log in to the server. Enter “anonymous” for the user name and your email address for the password.

  • Page 17: Chapter 1: Overview

    Chapter 1 Overview This chapter contains the following sections: “AT-CV5000 Overview” on page 18 “System Description” on page 19 “Front and Rear Panel Components” on page 20 “LED Interface Card” on page 21 “AT-CV5M01 Management Card” on page 24 “Converteon™ Line Cards” on page 28 “Blank Slot Covers”...

  • Page 18: At-Cv5000 Overview

    Chapter 1: Overview AT-CV5000 Overview The AT-CV5000 media converter, as shown in Figure 1, is a modular unit that simplifies the task of building and maintaining a Fast Ethernet or Gigabit Ethernet network. When you connect workgroup hubs and other switches to the chassis, the AT-CV5000 media converter functions as the focal point of your network.

  • Page 19: System Description

    System Description Hardware The standard AT-CV5000 Media Converter chassis has the following features: Features 18 line card/expansion slots with preinstalled AT-CV5PNLx blank slot covers One preinstalled LED interface card which contains: – – – One rear expansion slot Two preinstalled AT-CVFAN fan modules Two slots in the back for power supplies.

  • Page 20: Front And Rear Panel Components

    Chapter 1: Overview Front and Rear Panel Components Figure 2 shows the front panel of the AT-CV5000 chassis. Figure 3 illustrates the rear panel of the AT-CV5000 AC powered chassis. Fan Tray Slot AC Power Socket WARNING This unit might have more than one power input. To 100-240VAC reduce the risk of electric shock, disconnect all power inputs before servicing unit.

  • Page 21: Led Interface Card

    LED Interface Card The LED interface card, as shown in Figure 5, is preinstalled in the AT-CV5000 chassis and is not field-replaceable. The LED interface card features the following components: One RS-232 terminal port with a DB-9 connector One recessed RESET LINE/EXP button Seven system status LEDs Recessed RESET LINE/EXP Button RS-232 Terminal...

  • Page 22: Interface Card Leds

    Chapter 1: Overview These default settings are for a DEC VT100 or ANSI terminal, or an equivalent terminal emulation program. Interface Card Table 1 lists the system status LEDs located on the LED interface card. LEDs (For future use) MSTR (For future use) (For future use) PS-A...

  • Page 23: Reset Line/Exp Button

    Table 1. Status LEDs on the LED Interface Card (Continued) FAN-A FAN-B RESET LINE/ You can use the recessed RESET LINE/EXP button to reset the line cards and/or the module currently present in the expansion slot in the rear of the EXP Button chassis.

  • Page 24: At-Cv5M01 Management Card

    Chapter 1: Overview AT-CV5M01 Management Card The AT-CV5M01 Management Card provides a CPU subsystem for the AT-CV5000 chassis as well as the AT-S70 management software preinstalled that allows you to configure and monitor the status of the converter line cards. For more information about the AT-S70 management software, refer to the AT-S70 Management Software User’s Guide.

  • Page 25: 10/100Base-Tx Twisted Pair Port

    Parity: None Stop bits: 1 Flow control: None These default settings are for a DEC VT100 or ANSI terminal, or an equivalent terminal emulation program. 10/100Base-TX The 10/100Base-TX twisted pair port on the management card allows you to establish a remote management session and has a maximum operating Twisted Pair Port distance of 100 meters (328 feet).

  • Page 26: Cpu Reset Button

    Chapter 1: Overview For 10 Mbps operation, Category 3 or better, 100 Ohm shielded or unshielded, twisted pair cabling is required. For 100 Mbps operation, Category 5 or Enhanced Category 5 (5E), 100 Ohm shielded or unshielded, twisted pair cabling is required. CPU RESET The recessed CPU RESET button allows you to reset only the management card.
  • Page 27 Table 2. Status LEDs on the AT-CV5M01 Management Card State Green The twisted pair port is operating in full- duplex mode. The twisted pair port is operating in half- duplex mode. AT-CV5000 Media Converter Chassis Installation Guide Description...

  • Page 28: Converteon™ Line Cards

    Note For a current list of line cards for the Converteon™ Series Chassis, refer to the Allied Telesis web site or consult your authorized sales representative. For detailed descriptions of these line cards, refer to the documentation shipped with the line cards and/or the Converteon™...

  • Page 29: Smart Missinglink

    AT-CV5000 Media Converter Chassis Installation Guide port has been lost. If the failure occurs on the fiber optic cabling, the line card drops the link to the twisted pair port. Some devices can be configured to take a specific action in the event of the loss of connection on a port, to seek a redundant path to a disconnected end node, or to send out a trap to a network management station, and so alert the network administrator of the problem.

  • Page 30: Blank Slot Covers

    AT-CV5PNL3 – For the rear expansion slot AT-CV5PNL1 AT-CV5PNL3 Figure 7. AT-CV5PNLx Series Blank Slot Covers Note Allied Telesis strongly recommends that a blank slot cover be inserted in any slot that does not contain a functioning line card or module. AT-CV5PNL2...

  • Page 31: Power Supplies

    Power Supplies The AT-CV5000 chassis is shipped with two rear slots designated for the power supplies. Two power supply options are available: AT-PWR14 AC module AT-PWR15 DC module An AC powered chassis is shown in Figure 8 and a DC-powered chassis is shown in Figure 9.

  • Page 32: Fan Modules

    Chapter 1: Overview Fan Modules The AT-CVFAN module, as shown in Figure 10, is designed for use with the AT-CV5000 chassis. You can install the same fan module in either fan slot labeled A or B, located at the rear of the AT-CV5000 chassis. For proper operation, two AT-CVFAN modules are preinstalled in the AT-CV5000 chassis.

  • Page 33: Management Connections

    Management Connections The AT-CV5000 chassis provides two ports to connect to the AT-S70 management software: For local management, connect to the RS-232 terminal port on the AT-CV5M01 Management Card or to the RS-232 console port on the AT-CM70S line card only. For more information, refer to “Starting a Local Management Session”...

  • Page 34: A Few Basics About Media Converters

    Chapter 1: Overview A Few Basics about Media Converters An Ethernet media converter can interconnect network devices over large distances by transferring Ethernet traffic between twisted pair ports and fiber optic cabling. MAC Address A Converteon™ media converter line card has a MAC address table that can store up to 2K to 32 K MAC addresses, depending on the line card Table model.

  • Page 35: Store-And-Forward

    AT-CV5000 Media Converter Chassis Installation Guide with an end node, the end node should also be using Auto-Negotiation. Otherwise, a duplex mode mismatch can occur. A line card port, using Auto-Negotiation, defaults to half-duplex if it detects that the end node is not using Auto-Negotiation.

  • Page 36: Network Topologies

    Chapter 1: Overview Network Topologies This section discusses the network topologies you can create with the Converteon™ Fast and Gigabit Media Converter Line Cards. Standalone Figure 12 illustrates a standalone topology using one AT-CV5000 media converter with an AT-CM202 line card to interconnect two small networks. Topology AT-FS709FC 10BASE-T / 100BASE-TX 8 PORT FAST ETHERNET SWITCH WITH 100FX UPLINK...

  • Page 37: Figure 13. Back-To-Back Network Topology

    Network 1 has an AT-8350GB switch connected to the 10/100Base-TX port on the AT-CM202 line card in the first AT-C5000 media converter. Network 2 has an AT-8524M switch connected to the 10/100Base-TX port on the AT-CM202 line card in the second AT-CV5000 media converter.
  • Page 38 Chapter 1: Overview...

  • Page 39: Chapter 2: Installation

    Chapter 2 Installation This chapter contains the following installation procedures for the AT-CV5000 chassis: “Reviewing Safety Precautions” on page 40 “Selecting a Site for the Chassis” on page 44 “Unpacking the Chassis” on page 45 “Installing the Power Cord Retaining Clip (AC Powered Chassis Only)” on page 46 “Installing the AT-CV5000 Chassis in a Rack”...

  • Page 40: Reviewing Safety Precautions

    Note indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” (613-000405) on the Allied Telesis website at www.alliedtelesis.com Warning: Class 1 Laser product. Warning: Do not stare into the laser beam.
  • Page 41 AT-CV5000 Media Converter Chassis Installation Guide Warning: As a safety precaution, install a circuit breaker with a minimum value of 15 Amps between the equipment and the DC power source. Always connect the wires to the LAN equipment first before you connect the wires to the circuit breaker.
  • Page 42 Chapter 2: Installation Caution: Risk of explosion if battery is replaced by an incorrect type. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. Attention: Le remplacement de la batterie par une batterie de type incorrect peut provoquer un danger d’explosion.
  • Page 43 AT-CV5000 Media Converter Chassis Installation Guide Warning: Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuits (e.g., use of power strips). Warning: Circuit breaker is used as a disconnection device. To de-energize equipment, shut down the circuit breaker and then disconnect the input wire.

  • Page 44: Selecting A Site For The Chassis

    Chapter 2: Installation Selecting a Site for the Chassis Observe the following requirements when choosing a site for the chassis: If you plan to install the chassis in an equipment rack, check to be sure that the rack is safely secured and that it will not tip over. Devices in a rack should be installed starting at the bottom, with the heavier devices near the bottom of the rack.

  • Page 45: Unpacking The Chassis

    1. Remove all components from the shipping package. 2. Make sure that the following components are included in the package. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. 3. Place the AT-CV5000 chassis on a level, secure surface.

  • Page 46: Installing The Power Cord Retaining Clip (Ac Powered Chassis Only)

    Chapter 2: Installation Installing the Power Cord Retaining Clip (AC Powered Chassis Only) To install the power cord retaining clip on an AT-CV5000 chassis with an AT-PWR14 AC power supply, perform the following procedure: 1. Locate the power cord retaining clip which is shown in Figure 14. 2.

  • Page 47: Figure 17. Retaining Clip Properly Installed In The Bracket

    4. Verify that the retaining clip is in the correct position, as shown in Figure 17. 1 0 0 -2 4 0 V Figure 17. Retaining Clip Properly Installed in the Bracket AT-CV5000 Media Converter Chassis Installation Guide W A R N IN Th is un it...

  • Page 48: Installing The At-Cv5000 Chassis In A Rack

    Chapter 2: Installation Installing the AT-CV5000 Chassis in a Rack The chassis is shipped with two rack-mounting brackets. To mount the chassis in a rack, perform the following procedure: 1. Place the chassis on a level, secure surface. 2. Attach the brackets to the sides of the chassis using four screws 3.
  • Page 49 AT-CV5000 Media Converter Chassis Installation Guide Warning: Operating Temperature. This product is designed for a maximum ambient temperature of 40° degrees C. All Countries: Install product in accordance with local and National Electrical Codes. Circuit Overloading: Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of circuits might have on overcurrent protection and supply wiring.

  • Page 50: Grounding The At-Cv5000 Chassis

    Chapter 2: Installation Grounding the AT-CV5000 Chassis To ensure the safe and proper operation of your AT-CV5000 chassis, you must ground the unit to a ground point using either of the frame ground connectors on the rear panel, as shown in Figure 20. Grounding the chassis requires the following items: To attach the frame ground, perform the following procedure: 1.

  • Page 51: Figure 22. Placing The Ground Lug On The Frame Ground Stud

    The frame ground stud for power supply A is shown in Figure 22. 1 0 0 1 0 0 -2 -2 4 0 4 0 V V A C Figure 22. Placing the Ground Lug on the Frame Ground Stud 4.

  • Page 52: Installing A Converteon™ Line Card

    Note You must use the original package if you need to return the unit to Allied Telesis. install the line card. Keep the blank slot cover in a safe area in case you remove the line card.

  • Page 53: Figure 24. Location Of The Alignment Guides

    5. Locate the top and bottom alignment guides inside the line card slots, as shown in Figure 24. Alignment Guides Alignment Guides Figure 24. Location of the Alignment Guides 6. Align the line card with the top and bottom alignment guides located inside the slot.

  • Page 54: Figure 26. Tightening The Captive Screw

    Chapter 2: Installation 8. Use a Phillips screwdriver to tighten the captive screw on the line card, as shown in Figure 26. A T - C M 2 0 LK AT R DY SM L O A M Figure 26. Tightening the Captive Screw Note Always tighten the captive screw to secure the line card to the chassis.

  • Page 55: Cabling A Converteon™ Line Card In An At-Cv5000 Chassis

    Note For a current list of line cards for the Converteon™ Series Chassis, refer to the Allied Telesis web site or consult your authorized sales representative. For detailed descriptions of these line cards, refer to the documentation shipped with the line cards and/or the Converteon™...

  • Page 56: Figure 27. Dual Sc Port

    Chapter 2: Installation connector is connected to the receiver connector on the remote node. To connect a fiber optic cable to a dual SC connector, perform the following procedure: 1. Remove the dust cover from the fiber optic port, as shown in Figure 28.

  • Page 57: Figure 30. Removing The Dust Cover From A Simplex Sc Fiber Optic Port

    5. When the connection is established, the LK LED for the fiber optic port should show green. If the LED is OFF, refer to “Troubleshooting” on page 95 for instructions. Cabling a Simplex SC Connector To connect a fiber optic cable to a simplex SC connectors, perform the following procedure: Warning: Class 1 Laser product.

  • Page 58: Cabling A Twisted Pair Port

    Chapter 2: Installation Cabling a When you connect a twisted pair cable to a port, observe the following guidelines: Twisted Pair Port To connect to the 10/100Base-TX port, perform the following procedure: 1. Connect the twisted pair cable to the twisted pair port, as shown in 2.

  • Page 59: Figure 33. Inserting An Sfp Transceiver Into The Sfp Slot

    in Figure 33. Figure 33. Inserting an SFP Transceiver into the SFP Slot Note For information about the proper cable type, refer to the SFP transceiver installation instructions. Note Before you install the cable in the SFP transceiver, verify that the optical power input to the transceiver is within its dynamic range.

  • Page 60: Powering On An Ac Powered Chassis

    Chapter 2: Installation Powering On an AC Powered Chassis This section describes how to power on an AC powered AT-CV5000 chassis. If your chassis is DC powered, see “Powering On a DC Powered Chassis” on page 64. To power on an AC powered chassis, perform the following procedure: 1.

  • Page 61: Figure 37. Power Cord Retaining Clip In The Up Position

    2. Position the power cord retaining clip in the up position, as shown in Figure 37. 10 0- 24 0V WA RN IN G Th is red uce un it mig ht inp uts the ris hav e k of mo re bef ore ele ctr...

  • Page 62: Figure 40. On/Off Power Switch In On Position

    Chapter 2: Installation 6. Turn the ON/OFF power switch of the installed power supply module 7. Plug the other end of the power adapter to a power outlet. 8. Check that the POWER LED on the AT-PWR14 AC power module is No further installation steps are required if you do not need to change the to the ON position, as shown in Figure 40.
  • Page 63 AT-CV5000 Media Converter Chassis Installation Guide default parameter settings of the chassis, which are listed in the AT-S70 Management Software User’s Guide. However, if you want to manage the chassis or review the settings, refer to “Starting a Local Management Session”...

  • Page 64: Powering On A Dc Powered Chassis

    Chapter 2: Installation Powering On a DC Powered Chassis This section describes how to power on a DC powered AT-CV5000 chassis. If your chassis is AC powered, see “Powering On an AC Powered Chassis” on page 60. For information about how to install the power supply, refer to “Installing an AT-PWR15 DC Power Supply”...

  • Page 65: Figure 42. Stripped Wire

    4. With a 14-gauge wire-stripping tool, strip the three wires in the tray cable coming from the DC input power source to 8mm ± 1mm (0.31 in., ± 0.039 in.), as shown in Figure 42 on page 65. Warning Do not strip more than the recommended amount of wire. Stripping more than the recommended amount can create a safety hazard by leaving exposed wire on the terminal block after installation.

  • Page 66: Figure 43. Inserting Wires Into A Dc Terminal Block

    Chapter 2: Installation 6. Connect the +48 VDC (RTN) feed wire to the terminal block marked 7. Connect the -48 VDC feed wire to the terminal block marked - (minus). 8. Secure the tray cable near the rack framework using multiple cable 9.

  • Page 67: Starting A Local Management Session

    Starting a Local Management Session The procedure in this section explains how to start a local management session using the RS-232 terminal port on an AT-CV5M01 Management Card or the 8-pin Mini-DIN port on an AT-CM70S line card installed in the chassis.

  • Page 68: Figure 46. At-S70 Main Menu

    2. Connect the other end of the cable to an RS-232 port on a terminal or 3. Set the terminal or terminal emulation program to the following 4. When prompted, enter a username and password. Allied Telesis AT-CV5M01 Management Module Software Module Status and Configuration Remote Module Status and Configuration...
  • Page 69 AT-CV5000 Media Converter Chassis Installation Guide Refer to the AT-S70 Management Software User’s Guide for information about how to move through the menus and make menu selections.

  • Page 70: Starting A Remote Management Session

    Chapter 2: Installation Starting a Remote Management Session The procedure in this section explains how to start a remote management session using the 10/100Base-TX port on the AT-CV5M01 Management Card on the chassis. You can use a remote management session to configure the chassis operating parameters and view performance and error statistics using the AT-S70 management software.
  • Page 71 AT-CV5000 Media Converter Chassis Installation Guide Usernames and passwords are case-sensitive. Refer to the AT-S70 Management Software User’s Guide for information about how to move through the menus and make menu selections.
  • Page 72 Chapter 2: Installation...

  • Page 73: Chapter 3: Working With Line Cards And Other Modules

    Chapter 3 Working with Line Cards and other Modules This chapter contains the following installation procedures for line cards and other modules in the AT-CV5000 chassis: “Removing a Converteon™ Line Card” on page 74 “Working with the AT-CV5M01 Management Card” on page 76 “Installing an AT-CM70S Line Card”...

  • Page 74: Removing A Converteon™ Line Card

    Chapter 3: Working with Line Cards and other Modules Removing a Converteon™ Line Card To remove a Converteon™ line card, perform the following procedure: 1. Select the line card in the AT-CV5000 chassis you want to remove. 2. Using a Phillips screwdriver, loosen the captive screws at the top of 3.
  • Page 75 AT-CV5000 Media Converter Chassis Installation Guide Note The blank slot cover prevents dust from getting into the chassis and maintains proper airflow, cooling, and ventilation throughout the chassis.

  • Page 76: Working With The At-Cv5M01 Management Card

    Note You must use the original package if you need to return the unit to Allied Telesis. install the management card and remove the slot cover, if installed. alignment guides located inside the slot.

  • Page 77: Resetting An At-Cv5M01 Management Card

    4. Slide the management card into the slot, as shown in Figure 50, until the front of the card is flush with the front of the chassis. Figure 50. Inserting the AT-CV5M01 Management Card 5. Secure the AT-CV5M01 Management Card to the chassis by using a Phillips screwdriver to tighten the captive screw on the management card faceplate, as shown in Figure 51.

  • Page 78: Replacing An At-Cv5M01 Management Card

    Chapter 3: Working with Line Cards and other Modules 2. Press the reset button with the tip of a pen or a non-conductive pointed Replacing an When an AT-CV5M01 Management Card is replaced, all the parameter settings saved on the management card are lost. To keep the current AT-CV5M01 parameter settings, upload the configuration file onto a TFTP server Management...

  • Page 79: Installing An At-Cm70S Line Card

    (ESD) precautions, such as wearing an antistatic wrist strap, to avoid damaging the device. A line card can be damaged by static electricity. Note You must use the original package if you need to return the unit to Allied Telesis. AT-CV5000 Media Converter Chassis Installation Guide...

  • Page 80: Figure 53. Inserting An At-Cm70S Line Card

    Chapter 3: Working with Line Cards and other Modules 6. Slide the AT-CM70S line card into the two slots, as shown in 7. Use a Phillips screwdriver to tighten the captive screw on the line card, Figure 54. Tightening the Captive Screw on the AT-CM70S Line Card Figure 53, until the line card is flush with the front of the chassis.

  • Page 81: Resetting The Line Cards And The Module In The Rear Expansion Slot

    Resetting the Line Cards and the Module in the Rear Expansion Slot To reset the line cards and the module in the rear expansion slot, perform the following procedure: 1. Locate the RESET LINE/EXP button, which is recessed on the front panel of the LED interface card.

  • Page 82: Installing An At-Pwr14 Ac Power Supply

    Note You must use the original package if you need to return the unit to Allied Telesis. want to install the AT-PWR14 AC power supply.

  • Page 83: Figure 56. Inserting The At-Pwr14 Ac Power Supply

    5. Slide the AT-PWR14 power supply into the selected slot, as shown in Figure 56, until the module is flush with the front of the chassis. 10 0- 24 0V WA RN Th is IN G un it red uce mig ht the ris hav e...

  • Page 84: Installing An At-Pwr15 Dc Power Supply

    You can install an additional AT-PWR15 DC power supply while the existing power supply is powered ON. and store the package in a safe place. Note You must use the original package if you need to return the unit to Allied Telesis. want to install the AT-PWR15 DC power supply.

  • Page 85: Figure 58. Inserting The At-Pwr15 Dc Power Supply

    5. Slide the AT-PWR15 DC power supply into the selected slot, as shown in Figure 58, until the module is flush with the front of the chassis. 40 -60 VD C WA RN Th is IN G un it red uce mig ht the ris hav e...

  • Page 86: Replacing An At-Cvfan Module

    Chapter 3: Working with Line Cards and other Modules Replacing an AT-CVFAN Module This section provides instructions for replacing an AT-CVFAN fan module if one fails. To replace an AT-CVFAN module, perform the following procedure: 1. Power OFF the chassis. 2.

  • Page 87: Figure 60. Removing An At-Cvfan Module From Fan Slot A

    Note You must use the original shipping material if you need to return the fan module to Allied Telesis. 5. Carefully remove the fan module from the chassis. 6. To install a new fan, do one of the following: Caution Avoid touching the fan blades.

  • Page 88: Figure 62. Inserting An At-Cvfan Module Into Fan Slot A

    Chapter 3: Working with Line Cards and other Modules 7. Tighten the two captive screws on the fan module, as shown in Figure 64. Tightening the Screws on the AT-CVFAN Module in Slot A. a. To install a new fan in slot A, turn the fan so that the handle is on the left and slide the new fan module into the fan slot, as shown in Figure 62.

  • Page 89: Figure 65. Tightening The Screws On The At-Cvfan Module In Slot B

    V 5 P 24 0V 10 0- A T - C Figure 65. Tightening the Screws on the AT-CVFAN Module in Slot B To power on the chassis, proceed to the procedure described in “Powering On an AC Powered Chassis” on page 60 or “Powering On a DC Powered Chassis”...

  • Page 90: Installing A Blank Slot Cover

    6. Align the back edge of the blank slot cover with the left and right Note Allied Telesis strongly recommends that a blank slot cover be inserted in any slot that does not contain a functioning line card or module.

  • Page 91: Figure 66. Inserting An At-Cv5Pnl1 Blank Slot Cover

    7. Slide the blank slot cover into the slot, as shown in Figure 66, until the slot cover is flush with the front of the chassis. A T -C M 2 0 A T -C M 2 0 A T -C M 2 0 LK AT LK AT...

  • Page 92: Installing An At-Cv5Pnl2 Blank Slot Cover

    Note You must use the original package if you need to return the unit to Allied Telesis. want to install the blank slot cover. located inside the slot. slot cover is flush with the front of the chassis.

  • Page 93: Installing An At-Cv5Pnl3 Blank Slot Cover

    Note Always tighten the captive screws to secure the blank slot cover to the chassis. Note You must use the original package if you need to return the unit to Allied Telesis. 10 0- 24 0V WA RN Thi s...

  • Page 94: Figure 71. Tightening The Captive Screws On An At-Cv5Pnl3

    Chapter 3: Working with Line Cards and other Modules 4. Use a Phillips screwdriver to tighten the captive screws, as shown in Figure 71. 40 V W A R N IN Th is un it re du m ig ht ce th in pu ha ve...

  • Page 95: Chapter 4: Troubleshooting

    If after following the instructions in this chapter you are unable to resolve the problem, contact Allied Telesis Technical Support for assistance. Refer to “Contacting Allied Telesis” on page 16 for contact information. Verify that the power supply in question is completely installed in its slot.
  • Page 96 Chapter 4: Troubleshooting Caution For normal operation, both fans must be installed in the chassis.

  • Page 97: At-Cv5M01 Management Card

    AT-CV5M01 Management Card PWR LED is If the PWR LED on an AT-CV5M01 card is OFF, perform the following: If the chassis is installed on a desktop, check to be sure that the power adapter is securely connected to a power outlet and that the power adapter cable is securely connected to the rear of the converter.

  • Page 98: Flt Led Is Steadily On

    LED interface card with the tip of a pen or a non-conductive pointy object. Note If the FLT LED remains steadily on, contact Allied Telesis Technical Support for assistance. Check that the end node connected to the port is powered ON and is operating properly.
  • Page 99 If you are still experiencing problems after testing and troubleshooting the installation, contact Allied Telesis Technical Support for assistance. Refer to “Contacting Allied Telesis” on page 16 or visit our web site at www.alliedtelesis.com for support information. AT-CV5000 Media Converter Chassis Installation Guide...
  • Page 100 Chapter 4: Troubleshooting...

  • Page 101: Appendix A: Technical Specifications

    Appendix A Technical Specifications Physical Specifications Dimensions (W x D x H) Weight: Recommended Minimum Ventilation on All Sides Environmental Specifications Operating Temperature: Storage Temperature: Operating Humidity: Storage Humidity: Maximum Operating Altitude: Maximum Storage Altitude: Power Specifications AC Input Current: DC Input Current: Nominal Input Frequency: 34.25 cm x 44.05 cm x 8.68 cm...

  • Page 102: Safety And Electromagnetic Emissions Certifications

    Appendix A: Technical Specifications Safety and Electromagnetic Emissions Certifications EMI: Immunity: Safety: Laser: Quality and Reliability: Standards IEEE 802.3 (10Base-T) IEEE 802.3u (100Base-TX) FCC Class A, EN55022 Class A, VCCI Class A, C-TICK, CE EN55024 UL60950-1 ( ), EN60950-1 (TUV), CAN/CSA C22.2 No.

  • Page 103: Rj-45 Twisted Pair Port Pinouts

    RJ-45 Twisted Pair Port Pinouts Figure 72 illustrates the pin layout for an RJ-45 connector and port. Table 3 lists the RJ-45 pin signals when a twisted pair port is operating in the MDI configuration at 10 or 100 Mbps. Table 4 lists the RJ-45 port pin signals when a twisted pair port is operating in the MDI-X configuration at 10 or 100 Mbps.

  • Page 104: Rs-232 Terminal Port Pinouts

    Appendix A: Technical Specifications RS-232 Terminal Port Pinouts Figure 72 illustrates the pin layout to an RS-232 terminal port. Table 5 lists the pin signals on the RS-232 Terminal Port. Figure 73. RS-232 Terminal Port Pinouts Table 5. RS-232 Terminal Port Pin Signals Data Carrier Detect Transmit Data Receive Data...

  • Page 105: 8-Pin Mini-Din Console Port Pinouts

    8-Pin Mini-DIN Console Port Pinouts Figure 74 illustrates the pin layout of the 8-Pin Mini-DIN console port and connector. Figure 74. 8-Pin Mini-DIN Console Port and Connector Pin Layouts Table 6 lists the definitions for the 8-Pin Mini-DIN console port pinouts. AT-CV5000 Media Converter Chassis Installation Guide Table 6.

  • Page 106: Sc Type Connectors

    Appendix A: Technical Specifications SC Type Connectors Dual SC The fiber optic cable, as shown in Figure 75, is used to connect to the dual SC connectors in various Converteon™ line cards. Connector Simplex SC The fiber optic cable, as shown in Figure 76, is used to connect to the simplex SC connectors in various Converteon™...

  • Page 107: Dual St Type Connector Cable

    AT-CV5000 Media Converter Chassis Installation Guide Dual ST Type Connector Cable The fiber optic cable, shown in Figure 77, is used to connect to the dual ST connectors in various Converteon™ line cards. Figure 77. Dual ST Connector Cable...

  • Page 108: Sfp Transceiver Cable

    Appendix A: Technical Specifications SFP Transceiver Cable The SFP transceiver, as shown in Figure 78, is used in various Converteon™ line cards. Figure 78. SFP Transceiver The fiber optic cable, shown in Figure 79, is one of the cable types that can be used to connect to the SFP transceiver.

  • Page 109: Appendix B: Cleaning Fiber Optic Connectors

    Appendix B Cleaning Fiber Optic Connectors The fiber optic connector consists of a fiber optic plug and its adapter. The end of the fiber optic cable is held in the core of the ferrule in the plug. Light signals are transmitted through the core of the fiber. Even minor smudges or dirt on the end face of the fiber, completely invisible to the naked eye, can disrupt light transmission and lead to failure of the component or of the entire system.

  • Page 110: Figure 82. Cartridge Cleaner

    Appendix B: Cleaning Fiber Optic Connectors Using a Cartridge-Type Cleaner Fiber optic cartridge cleaners are available from many vendors and are typically called “cartridge cleaners,” as shown in Figure 82. To clean a fiber optic connector using a cartridge cleaner, perform the following procedure.
  • Page 111 3. When you reach the end of the cleaning surface, pick up the ferrule tip, rotate and place it at the top and rub downwards at least 2 times. Caution Failing to pick up the ferrule tip when you reach the bottom of the cleaning surface can result in static electricity that can damage the fiber optic cable.

  • Page 112: Figure 84. Lint-Free And Alcohol-Free Swabs

    Appendix B: Cleaning Fiber Optic Connectors Using a Swab Specially treated swabs (stick cleaners) are available for cleaning inside connector adapters or hard-to-reach ferrule tips. These swabs, often referred to as “lint free” or “alcohol free” swabs, are available from many vendors, as shown in Figure 84.
  • Page 113 3. If a fiber inspection scope is available, use the scope to inspect the connector to make sure that it is clean and to check for scratches, pits, or other problems that may affect performance. Note Always keep a dust cap on a fiber optic cable when it is not in use. Warning Do not look directly at the cable ends or inspect the cable ends with an optical lens when the cable is connected at the other end.
  • Page 114 Appendix B: Cleaning Fiber Optic Connectors...

Table of Contents

Save Article as PDF
