Allied Telesis Converteon AT-CV1000 Datasheet

Datasheet | Media Converters
AT -CV1000
Converteon Chassis
TM
AT -CV1000
1 slot Converteon chassis
Overview
The AT-CV1000 is one of a family of metal
chassis designed to house 1, 2 or 18
Converteon media blades.The AT-CV1000 is
the single-blade chassis, AT-CV1203 is the 2 slot
chassis and AT-CV5000 is the 18 slot chassis.
Flexible Deployment
The AT-CV1000 chassis can be installed on a
desktop, by the addition of four rubber feet.
Alternatively, it can be wall-mounted, or under
desk-mounted by the addition of two small
brackets being secured to the sides of the
chassis. As the unit operates silently, it can be
installed in any office or home environment.
Hassle Free Support
All Allied Telesis AT-CV1000 chassis offer free
technical support, ensuring trouble-free
installation.
Technical Specifications
Physical Specifications
Dimensions 10.48cm x 17.77cm x 2.54cm
(W x D x H) (4.125" x 7" x 1")
Weight 0.47kg (1.05lbs)
Power adapter style In line (IEC power inlet)
Input voltage 10-240V AC 50/60Hz, auto-sensing
Output voltage 12vDC @ 2A
Chassis
Nominal input: 12vDC
Input current: 1.06A @ 12vDC
USA Headquarters | 19800 North Creek Parkway
European Headquarters | Via Motta 24
Asia-Pacific Headquarters | 11 Tai Seng Link
www.alliedtelesis.com
© 2007 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners.

Environmental Specifications

Operating temperature:
Storage temperature:
Operating humidity:
Storage humidity:
Maximum operating altitude: 3,000 m
Maximum storage altitude: 4,000 m
Predicted MTBF (Telcordia SR332): 1,220,000 hrs
Standards
EMI part 15:
FCC class A, EN55022 class A, VCCI class A, C-Tick, CE
Immunity:
EN55024
Safety:
UL60950-1 (cULUS), EN60950-1 (TUV)

Package Contents

1 x AT-CV1000 chassis
4 x Rubber feet for desktop mounting
2 x Wall-mount brackets
2 x Screws (for wall-mounting)
2 x Plastic anchor clips (for wall-mounting)
1 x Power adapter
1 x IEC power cord (country specific)
1 x Installation guide (on CD)
1 x Warranty registration card
| Suite 200 | Bothell |
| 6830 Chiasso | Switzerland | T: +41 91 69769.00
| Singapore | 534182 | T: +65 6383 3832
0°C to 40°C
(32°F to 104°F)
-25°C to 70°C
(-13°F to 158°F)
5% to 90% non-condensing
5% to 95% non-condensing
(10,000 ft.)
(13,100 ft.)
WA 98011 | USA | T: +1 800 424 4284
| F: +41 91 69769.11
| F: +65 6383 3830
Key Features
• Single-slot chassis for Converteon line card
• Stand-alone or wall-mountable
• Silent operation
• External power supply

Ordering Information

AT-CV1000-xx
Single-slot Converteon chassis
Where xx = 10 US power adapter
20 European power adapter
30 UK power adapter
40 Australian power adapter
Associated Products
AT-CVMCR
Bracket allowing AT-CV1000 to be installed in AT-MCR12
chassis
AT-CV1203-xx
2 slot Converteon chassis
AT-CV5000-xx
18 slot, Converteon chassis
| F: +1 425 481 3895
617-000141 Rev. F
