2-4 Securely tighten the screws on the top of B that
were attached in Step
E
2-1, 2-4
2-2
2-3
Secure the anti-fall brackets using the screws.
3
Secure C.
3-1 Securely tighten the screws on C that were
1-3
attached in Step
3-2 Attach the caps ( ) to the head of the screws.
3-2
D
3-1
4
Mount A.
Be sure to place your hands at least 10 cm from
either end of
At least 10 cm
D
Align the dowels on D and E with the corresponding
holes on the bottom of
CAUTION
• Be careful not to pinch your fingers or drop the unit.
• Do not hold the keyboard in any position other than
the position shown in the illustration.
2-1
.
D
B
2-2
.
B
D
C
A
when positioning it.
At least 10 cm
A
B
E
A
.
5
Secure A.
5-1 Adjust the position of A so that the left and right
ends of A will project beyond D and E equally
when seen from the front.
5-2 Secure A by tightening the four short screws ( )
(6 x 16 mm) from the bottom.
Projection of A
6
Connect the pedal cord.
6-1 Insert the pedal cord plug to the [TO PEDAL] jack
from the rear.
6-2 Attach the cord holders to the rear panel as
shown, then clip the cord into the holders.
6-3 Use a vinyl tie to take up any slack in the pedal
cord.
6-1
6-2
Insert the pedal cord securely until the metal part of the
cord plug disappears from view.
Otherwise, the pedal may not function properly.
YDP-S51 Owner's Manual
Appendix
5-1
A
A
5-2
6-3
Insert the cord all the way
until the metal part of the plug
disappears from view.
29
