- Page 1 POWERglide ™ U S E R ’ S G U I D E MODEL 3545 SERIES Safety Instructions Product view Assembly Operations / Special Tools Routine Maintenance 9-13 Troubleshooting Replacement Parts Consumer Services Warranty...
- Page 2 My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your BISSELL PowerGlide. Thanks again, from all of us at BISSELL.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Keep hair, loose clothing, fingers, and all When using an electrical appliance, parts of body away from openings and basic precautions should be observed, moving parts. including the following: Turn off all controls before plugging or READ ALL INSTRUCTIONS unplugging vacuum cleaner. - Page 4 Hose Handle Carrying Crevice Handle Tool Quick Reach Handle Extension Wand Quick Release Cord Wrap Power Switch Combination Upholstery/Dusting Brush Tool Extra Belt Storage Power Cord (extra belt not included) Post-Motor Filter Handle Floor Surface Release Selector Pedal Powerfoot Furniture Protection C A U T I O N : Guard...
-
Page 5: How To Put It Together
How to use this guide This User’s Guide has been designed to help you get the utmost satisfaction from your BISSELL PowerGlide. You’ll find assembly and operating instructions, safety precautions, as well as maintenance and troubleshooting instructions. Please read this Guide thoroughly before assembling your vacuum cleaner. -
Page 6: Handle Positions
Snap the Combination Upholstery/Dusting Brush Tool into the storage clip. How to use your BISSELL PowerGlide Handle Positions Press the Handle Release Pedal with your foot to place your PowerGlide into one of three cleaning positions. -
Page 7: Powerfoot Height Adjustment
Powerfoot Height Adjustment The Powerfoot/Rotating Floor Brush on your BISSELL PowerGlide can be adjusted to clean several floor surfaces. NOTE: For optimal cleaning performance, adjust to the lowest practical setting. If your cleaner is difficult to push, adjust to the next higher setting. -
Page 8: Special Tools
Special Tools Your BISSELL PowerGlide is not only a powerful carpet and rug vacuum cleaner, it’s also a versatile above floor vacuum cleaner when you select one of the special tools. Raise Handle to Upright Position. Grasp the Quick Reach Handle and lift up to separate from suction intake opening. -
Page 9: Replacement Parts
Or visit our Website - www.bissell.com Replace Dust Bag Use only BISSELL Style 7 Dust Bags in your BISSELL PowerGlide. To maintain peak vacuum efficiency, you should check the Dust Bag weekly, and replace it when it is no more than half full. - Page 10 Hand wash filter in cold water with mild detergent, then air dry. Reposition dry filter and grill. Replacing Post-Motor Filter Use only BISSELL Style 7 Replacement Post-Motor Filters in your BISSELL PowerGlide. Style 7 Post Motor Filter (#203-1009) Style 7 Micro-Lock ®...
-
Page 11: Check Rotating Floor Brush And Drive Belt
Check Air Passageway for obstructions. Remove debris from this area. Replace Drive Belt Use only BISSELL Style 7 Replacement Belts (#32074) in your BISSELL PowerGlide. Unplug cleaner from electrical outlet. With Rotating Floor Brush removed from vacuum cleaner ( Steps 1-4 above), stretch old Drive Belt to clear Motor Pulley and remove. -
Page 12: Replace Lightbulb
Belt will center itself on Rotating Brush crown. Reposition Brush Cover and four screws. Tighten screws securely. Replace Lightbulb Use only BISSELL Replacement Bulb (#203-1007) in your BISSELL PowerGlide. Unplug cleaner from electrical outlet Using a screwdriver, remove the two screws as shown and lift off the lens. -
Page 13: Clearing Clogs
When cleaner is unplugged and motor cools for 30 minutes, the thermal protector automatically resets and cleaning may continue. If the thermal protector continues to activate after following the above steps, your cleaner may need servicing. Call BISSELL Consumer Services, or visit the website. -
Page 14: Troubleshooting
*If suggested solutions for this or any function of your PowerGlide do not correct the problem, call: BISSELL Consumer Services 1-800-237-7691 Monday - Friday 8 a.m. — 7 p.m. EST Saturday 9 a.m. — 2 p.m. EST or visit the BISSELL website - www.bissell.com... - Page 15 PO Box 3606 Grand Rapids MI 49501 ATTN: Consumer Services Or visit the BISSELL website - www.bissell.com When contacting BISSELL, have model number of unit available. ©2001 BISSELL Inc Grand Rapids, Michigan Please record your Model Number: ___________________ All rights reserved. Printed in USA.
-
Page 16: About Your Warranty
Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, upon receipt of the product BISSELL Inc. will repair or replace (with new or remanufactured components or products), at BISSELL’s option, free of charge from the date of purchase by the original purchaser, for two years any defective or malfunctioning part.
