Washing Sequence - Haier HWM-802P User Manual

Washing sequence

Wash timer
(To set to below 2 minute,
first set to 5 minute then
turn it back. it can increase
the service life of the timer).
3
15
12 6
WASH TIMER WASH TIMER
9
Wash
1 Inlet selector
(1) Set inlet selector to
(2 )Adjust water level rod to a position as needed.
2. Fill the water and add the dissolved washing
powder to make the water level reach the preset
position. (Figure 2)
Run washing program for some time to stir and
dissolve the powder completely.
3.Put in the laundries. If the water quantity is
insufficient, please add water.
4.Select the current.
Select the strength of the current according to
the laundries. (Figure 3)
5.Select the washing time
Select the washing time according to the
laundries. (Figure 4)
6.After washing,the buzzer will ring .Set
the "WASH SELECTOR" at "DRAIN".
(Figure 5).
Wash selector
(Strong current,
standard current)
STRONG STRONG
STANDARD STANDARD
DRAIN DRAIN
WASH SELECTOR WASH SELECTOR
Wash side. Figure 1
8
Spin timer
(to set to below 1 minute,
first set to 2 minute then
turn it back. it can increase
the service life of the timer).
5 1
4 2
SPIN TIMER SPIN TIMER
3
Figure 1
INLET SELECTOR SPIN
WASH
Figure 2
STRONG STRONG
STANDARD STANDARD
DRAIN DRAIN
Figure 3
3
15
12 6
Figure 4
9
STRONG
STANDARD STANDARD
DRAIN DRAIN
Figure 5
