- Page 1 FULLY AUTOMATIC TOP LOADING WASHING MACHINE USER MANUAL MODEL HWM80-1269S2 Please read this manual carefully before operating your washing machine and retain 0030519576 it for future reference.
-
Page 2: Table Of Contents
CONTENTS Product overview Safety precautions Description of symbols Warning Forbidden Safety warning Installation & adjustment Install the bottom plate Balance washing machine Usage of the drain hose Inlet pipe connection Before washing Check the following before washing Operation Loading your laundry Usage of the detergent Explanation of buttons Cleaning or Maintenance... -
Page 3: Product Overview
Product overview Control panel seat Top lid component Outer tub cover Lint filter Inner tub Pulsator Cabinet Adjustable foot (2 pieces) Water inlet valve Handle Back cover Drain hose Power cord Fixed foot (2 pieces) Base frame Please understand the shapes of the washing machine and accessories may be different from the sketch figures in this manual due to product improvement. -
Page 4: Safety Precautions
Safety precautions Description of symbols Warning sign Contents marked with this symbol are related to the safe use of the product and the personal safety of the user. Please operate in accordance to the contents of this manual,to avoid harm to the user or damage to the machine itself. Forbidden sign Contents marked with this symbol indicate operations or actions that should not be undertaken by the user. - Page 5 Safety precautions Forbidden Do not connect to hot Do not install this appliance in a water higher than damp or wet environment. Do not 50°C. leave wet laundry on the control panel or spray water directly onto this appliance as this may cause the washer to malfunction or cause an electrical fault.
- Page 6 Safety precautions Safety warning The washing machine's lid can be opened during spinning, which will take 15s or more to complete stop of spinning. The new hose-sets supplied with the appliance need to be used and that old hose-sets should not be reused. Please remove item such as coins, Check that water faucets are open button, sand and other solid materials...
-
Page 7: Installation & Adjustment
Installation & Adjustment Please install and adjust the machine according to the directions contained in this manual.It is very important to follow these directions for the safe operation of the machine,and to ensure your machine operates correctly. Install the bottom plate The purpose of the bottom plate is to su ppress noise from the washing machine during operation. -
Page 8: Usage Of The Drain Hose
Installation & Adjustment Usage of the drain hose The drainage shall be smooth with the drain hose. 1.The height of the drain hose shall be 4.If extra drain hose is needed, please less than 10cm, or the drainage will not be make separate purchase.The inner smooth，... - Page 9 Installation & Adjustment Connection between the water inlet hose jointer and the water faucet 1.Press the lower end of the lock lever and push down the slider. Take off the water inlet hose jointer from the water inlet hose component. See to Figure 1. 2.Take off the nameplate.
- Page 10 Installation & Adjustment Connection between the jointer 1.Push down the slider. Insert the water inlet hose into the jointer. the jointer of the 2.Hang the lock lever to the jointer. Release the water inlet hose slider till a click sound is heard. Slider Locking lever Check the connection...
-
Page 11: Before Washing
Before washing Preparation before washing 1.Connect the water inlet hose. Open the water faucet. 2.Confirm that the washing machine is earthed reliably. Then insert the power plug into the receptacle. The earth terminal shall not link to gas pipeline and faucet water pipeline. -
Page 12: Operation
Operation Loading your laundry The rated washing capacity refers to the largest dry weight of a load that can be washed. The thickness, size and type of clothes will influence the actual capacity. Do not select more than water level “4” for clothes less than 1.0kg, to avoid splashing of water. -
Page 13: Explanation Of Buttons
Operation Explanation of buttons Indicator display On: Indicates the program is about to run and indicates the seleced cycle and options Flashing: Indicates the program is running and indicates the selected cycle and options Child Lock function The function is intended for children’s safety and preventing children from accidental changes to washing programs. - Page 14 Operation "Start/Pause" button After the power is switched on, press it to start the machine. During working, press it to pause. During pause, press this button to restart and go on working. "Program" select Application Program Normal Recommended for mixed fabrics and general clothing items Jeans Suitable for washing large and thick clothes Quick...
- Page 15 Operation "Water Level " button The machine in standby or pause state, press water level button and hold more than 3s, the digital tube display P3, you can adjust the wash- ing intensity by press water level button again. The washing intensity is P1-P4 from weak to strong, P3 is the defaults level, you can chose the washing intensity by the material of the clothing and how dirty it is.
-
Page 16: Cleaning Or Maintenance
Cleaning or Maintenance Maintenance Remove the power plug before carrying out any cleaning or maintenance. Clean the lint filter(s) and detergent box after each wash. The lint filter must be used during washing. The filter at the water inlet valve may It must be cleaned in time after each use. -
Page 17: Trouble-Shooting
Trouble-shooting If there is a fault or the machine does not operate correctly,remove the power plug before checking the machine.Using diagnostic list below,please check if the machine requires repair.If a repair is required,please contact our customer care team,do not try to fix it by yourself. - Page 18 Trouble-shooting Problem Possible causes What to do The water tap leaks. Is the water inlet hose loose? Fasten the inlet hose. Please contact Customer The display shows F2. Overflow Error Care. Common occurrence Situation Cause The spinning is intermittent after it starts. Redistribute the load evenly.
-
Page 19: Packing List
Packing list Name Quantity Storage position Automatic washing machine Bottom plate User manual Inside the document bag Warranty card Inside the document bag Inside accessory bag Screw Inside accessory bag Components of the water inlet hose... -
Page 20: Specification
Specification Type Fully Automatic Washing Machine Model HWM80-1269S2 Rated voltage/frequency 220-240V~/50Hz Rated washing power 400W Rated spinning power 300W Net weight 26.0kg Gross weight 30.0kg Dimensions(mm) W 500 D 520 H 932 Water inlet pressure 0.03MPa-1.0MPa Rated Washing capacity 8.0kg...
