Eiki LC-XB31 Specification Sheet


Projectors... and more!
KEY FEATURES: Model LC-XB31
Weighs only 6.8 lbs (3.1 kg)! Footprint slightly larger than a sheet of paper!
2500 ANSI Lumens, 85% uniformity, and 450:1 contrast ratio.
3 panel LCD imaging delivers a rich, color saturated picture.
True XGA resolution. WXGA and UXGA~VGA and MAC compatible.
Quiet operation: fan noise as low as 28 dBA.
Smart data compression / expansion, and video scaling.
Convenient mid-range (1.2:1) manual zoom and focus lens.
Preset image offset. Vertical digital keystone correction.
Accepts Composite, Component and S-Video in all major standards.
Displays both 4:3 and 16:9 formats. Supports most HDTV resolutions.
Converts Interlace to Progressive scan. 3-2 / 2-2 Pulldown support.
Variable Power Management option. Optional local or remote keylock.
VGA-type computer input. Auto input search.
Custom warm-up screen option. Green chalkboard projection mode.
Wireless remote control. 16X digital zoom. Turn OFF and GO!
3 Year* Projector Warranty!
Included Accessories:
Owner's Manual on CD-ROM. Quick Start Guide. AC Power Cord. Lens Cover. VGA type Computer Input Cable (HD15 ~ HD15).
Wireless Remote Control & Batteries (AA x 2).
Optional Accessories:
Soft Carry Bag. Replacement Lamp. Component Video Input Cable (HD15~3-RCA). DB9~Mini Din-8 cable for RS-232
control. Luggage-Style ("wheelie") Carrying Case with Wheels, Telescoping Handle, and Detachable Computer Compartment. Ceiling Mount.
Ceiling Post and Plate. 33' (10m) Extension Cable for Serial Cable.
Screen Brightness ................................................... up to 2500 ANSI Lumens
Illumination Uniformity ............................................................................. 85%
Size of Color Palette ..................................................................... 16.7 Million
Contrast Ratio ............................................................... 450:1 (Full ON/OFF)
Projection Lamp ....................................................................... 220 Watt UHP
Estimated Lamp Life .................................................. up to 3000 Hours of Use
Imaging System ...................... 0.63" PolySilicon active matrix TFT Panels x 3
Screen Pixels .............................................. 1024 x 768 in stripe configuration
Total Pixels ......................................................... 2,359,296 ((1024 x 768 ) x 3)
Lens Type ................................................................ Manual Zoom and Focus
Lens Specs................ Speed: f:1.65~1.81; FL: 0.886~1.063 in. (22.5~27 mm)
Lens Ratios.......................... Zoom Max:Min: 1.2:1; Throw:Width: 1.72~2.07:1
Image Diagonal ........................................................ 40~300 in. (102~762 cm)
Image Width ............................................................. 2.67~20 ft. (0.84~6.1 m.)
Throw Distance (Wide / Tele) .................................. 4.6~41.3 ft. (1.4~12.6 m.)
Front Elevation / Maximum Pitch ............... up to 10
Anti Keystone ............................... Fixed Image Offset, Ratio (Top:Bottom) 9:1
Vertical Keystone Correction ............................... Digital: up to 20° up or down
Scanning Frequency ................. Auto: H Sync. 15-100kHz; V Sync. 50-100Hz
Dot Clock ...........................................................................................140 MHz
Image Orientation ............................................... Normal, Reversed, Inverted
Local Control / Power Management ................. Full Function / Auto Shutdown
Remote Projector Ctrl ............................................... Wireless (Infra Red) x 1
Service Port (for RS-232 control)........................................ Mini DIN 8 Pin x 1
Computer Native Resolution ............................................... 1024 x 768 (XGA)
Computer: Compatibility ...........UXGA, SXGA+, SXGA, WXGA, XGA, SVGA,
Computer: Formats............................................1600 x 1200 through 640x480
Computer: Higher Resolutions ........ Displayed panned or Smart Compressed
Computer: Lower Resolution .................Displayed normal or Smart Expanded
Outstanding Features:
1. Low cost / High Brightness = affordable & low cost per lumen.
2. Compact and lightweight: easy to carry or install.
Lamp contains Mercury. Do not put in trash. Dispose of as Hazardous Waste, according to Laws in your jurisdiction.
Specifications subject to change without notice. ©2008 Eiki International, Inc. Issued January 1, 2008.
Eiki International, Inc., 30251 Esperanza, Rancho Santa Margarita, CA 92688-2132. Tel: 800-242-3454; Fax: 800-457-3454, E-mail: usa@eiki.com
In Canada: 310 First St., Unit 2, P.O. Box 156, Midland, ON L4R 4K8. Tel: 800-563-3454, Fax: 800-567-4069, E-mail: canada@eiki.com
LC-XB31
SPECIFICATIONS: Model LC-XB31
Video: Compatibility........NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
Video: HD Compatibility...................... 480i/p, 575i/p, 720p, 1035i, 1080i
Video: Formats Supported ................ Normal 4:3 and Wide Screen 16:9
Video: Image Sizing ...................................... Video Scaling Technology
Image Signal Inputs
Video In :................................... RCA x 1 (Composite) S-Video x 1 (Y/C)
Audio Signal Inputs
Audio: Amplifier ......................................................... Mono: 1 Watt RMS
Audio: Output...................................... Stereo: Ministereo x 1 (Variable)
Audio: Built In Speakers ............................................ 1.1 in. (2.8 cm) x 1
Fan Noise ..................................................................... as low as 28 dBA
° °
up / up to 10 up or down Cabinet Size** (HxWxD) ..... 3.1 x 13.2 x 9.4in. (79.6 x 335 x 238.4mm.)
Weight ............................................................................6.8 lbs. (3.1 kg)
Packaged Size (H x W x D)
Packaged Weight .............................................................11.0 lb (5.0 kg)
Power Consumption ....................................................... up to 245 Watts
Heat ............................................................................ 836 BTU (211 KC)
Power Requirements ......................................... 100-240V AC, 50/60Hz
Power Cord ................................................ 10' (3M) Type 3, Detachable
Electrical Safety Compliance ............................................. UL, cUL, IEC
Electromagnetic Compatibility ............................. FCC Class B, CE Mark
VGA & MAC Security Facilities............................................Kensington® Security Slot
Operating Temperature............................................... 41~95
User Maintenance .................................. Clean Air Filter, Replace Lamp
Warranty: (to the original end-use customer)
3. UXGA & WXGA compatible. Interlace to Progressive conversion.
4. Turn ON and Show! (Countdown can be optionally skipped).
5. Turn Off and Go! (AC power cord can be removed immediately
after OFF).
Visit our World Wide Web site: http://www.eiki.com
XGA "Brilliant" Series
Computer In 1 / Component In (with optional adapter) ........ HD15 x 1
Computer In 2 / Monitor out (switchable) ............................ HD15 x 1
Computer 1 & 2 / Component ............................Stereo: Ministereo x 1
Composite/S-Video .................................................... RCA x 2 (L & R)
8.4 x 16.9 x 16.2in. (213 x 429 x 411mm.)
Projector: ............... 3 Yr. / 6000 Hr. *(Parts & Labor to Correct Defects)
Lamp: ................................. 90 Days (Failed Lamp Replaced Pro-Rata)
LC-XB31
** excluding legs and lens
0
F (5~35
* Whichever occurs first
0
C)
