Multimedia Projector
MODEL
LC-XB33N
Owner's Manual
Network Supported
□
Wireless LAN
IEEE802.11b/g
□
Wired LAN
100-Base-TX/10-Base-T
Memory Viewer
□
SD Card Memory Viewer
* Refer to the owner's manuals below for details
about network and memory viewer function.
■
Network Set-up and Operation
■
Memory viewer
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Eiki LC-XB33N
Summary of Contents for Eiki LC-XB33N
- Page 1 Multimedia Projector MODEL LC-XB33N Owner's Manual Network Supported □ Wireless LAN IEEE802.11b/g □ Wired LAN 100-Base-TX/10-Base-T Memory Viewer □ SD Card Memory Viewer * Refer to the owner’s manuals below for details about network and memory viewer function. ■ Network Set-up and Operation ■...
-
Page 3: Features And Design
Features and Design This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. ◆ Compact Design This projector is designed compact in size and weight. -
Page 4: Table Of Contents
Table of Contents Features and Design . . . . . . . . . . . . . . . . . . .3 Table of Contents . -
Page 5: To The Owner
To the Owner Before installing and operating this projector, read this manual thoroughly. This projector provides many convenient features and functions. Operating the projector properly enables you to manage those features and maintains it in good condition for many years to come. Improper operation may result in not only shortening the product-life, but also malfunctions, fire hazard, or other accidents. -
Page 6: Safety Instructions
Safety Instructions All the safety and operating instructions should be read before the product is operated. Read all of the instructions given here and retain them for later use. Unplug this projector from AC power supply before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. -
Page 7: Installing The Projector In Proper Position
Air Circulation Openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked or covered. CAUTION Hot air is exhausted from the exhaust vent. When using or installing the projector, the following precautions should be taken. -
Page 8: Compliance
Do not make any changes or modifications to the equipment unless otherwise specified in the instructions. If such changes or modifications should be made, you could be required to stop operation of the equipment. Model Number : LC-XB33N Trade Name : EIKI Responsible party : EIKI International,Inc. -
Page 9: Part Names And Functions
Part Names and Functions Front ① ② ③ ④ ⑤ Back ⑦ ⑧ ⑨ ⑩ ⑥ Bottom ⑮ ⑯ ⑱ ① Infrared Remote Receiver ② Focus Ring ③ Zoom Lever ④ Projection Lens ⑤ Lens Cap (See page 59 for attaching.) CAUTION Do not turn on a projector with lens cap attached. -
Page 10: Rear Terminal
Rear Terminal ① ① USB In order to operate the computer with the remote control and use the PAGE remote control during a presentation, connect the USB port of the computer to the USB terminal with a USB cable (not supplied) (pp.12, 18). ②... -
Page 11: Top Control
Part Names and Functions Top Control ① SELECT button – Execute the selected item (p.23). – Expand or compress the image in the Digital zoom mode (p.38). ② POINT ▲▼◄► (VOLUME +/–) buttons – Select an item or adjust the value in the On-Screen Menu (p.23). -
Page 12: Remote Control
Remote Control ① ④ ③ ② ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ Note: To ensure safe operation, please observe the following precautions: – Do not bend, drop, or expose the remote control to moisture or heat. –... -
Page 13: Laser Pointer Function
Part Names and Functions Laser Pointer Function This remote control emits a laser beam from the laser light window. Press the LASER button to activate the laser pointer. The signal emission indicator lights red and the red laser beam is emitted. If the LASER button is pressed for more than one minute or if it is released, the laser light goes off. -
Page 14: Wireless Mouse Operation
wireless Mouse Operation The remote control can be used as a wireless mouse for your computer. Before operating the wireless mouse, connect your computer and the projector with a USB cable (not supplied). See “Connecting to a Computer” on page 18. When the Pointer function is used, the wireless mouse is not available. -
Page 15: Remote Control Battery Installation
Part Names and Functions Remote Control Battery Installation Open the battery compartment lid. Press the lid downward and slide it. To ensure safe operation, please observe the following precautions : ● Use two (2) AAA or LR03 type alkaline batteries. ●... -
Page 16: Installation
Installation Positioning the Projector For projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the screen. Notes: • The brightness in the room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain the best image. -
Page 17: Connecting The Ac Power Cord
Installation Connecting the AC Power Cord This projector uses nominal input voltages of 100-120 V or 200–240 V AC and it automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system. -
Page 18: Connecting To A Computer
Connecting to a Computer Cables used for connection • VGA Cable (Mini D-sub 15 pin) * • DVI-VGA Cable • DVI Cable • USB Cable • Audio Cables (*One cable is supplied; other cables are not supplied with the projector.) Audio Output USB cable cable... -
Page 19: Connecting To Video Equipment
Installation Connecting to Video Equipment Cables used for connection • Video and Audio Cable (RCA x 3) • S-VIDEO Cable • Audio Cable (Cables are not supplied with the projector. ) S-Video cable Notes: • When the AUDIO OUT is plugged-in, the projector's built- in speaker is not available. -
Page 20: Connecting To Component Video Equipment
Connecting to Component Video Equipment Cables used for connection • Audio Cables • Scart-VGA Cable • Component Cable • Component-VGA Cable (Cabels are not supplied with this projector.) RGB Scart 21- Component Video Output pin Output Component cable Scart-VGA Component- cable VGA cable COMPUTER IN 2/ COMPONENT... -
Page 21: Basic Operation
Basic Operation Turning On the Projector Complete peripheral connections (with a computer, VCR, etc.) before turning on the projector. Connect the projector’s AC power cord into an AC outlet. The POWER indicator lights red. Open the Lens cap (see pages 9,59). Press the POWER ON/SYAND-BY button on the top control or on the remote control. -
Page 22: Turning Off The Projector
Turning Off the Projector Press the POWER ON/STAND-BY button on the top control or on the remote control, and “Power off?” appears on the screen. Press the POWER ON/STAND-BY button again to turn off the projector. The POWER indicator starts to blink red, and the cooling fans keep running. -
Page 23: How To Operate The On-Screen Menu
Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Menu. For each adjustment and setting procedure, refer to the respective sections in this manual. Press the MENU button on the top control or the remote control to display the On-Screen Menu. -
Page 24: Menu Bar
Menu Bar For detailed functions of each menu, see “Menu Tree” on pages 66-67. For computer source Guide window PC System Menu Show the selected Used to select Menu of the On- computer system Screen Menu. (p.31). Input Menu PC Adjust Menu Used to select an Used to adjust input source either... -
Page 25: Zoom And Focus Adjustment
Basic Operation Zoom and Focus Adjustment Rotate the Zoom Lever to zoom in and out. Rotate the Focus Ring to adjust the focus of the image. Auto Setup Function Auto setup function is provided to automatically correct Keystone distortion according to the projector’s tilt and adjust the computer display parameters (Fine sync, Total dots, and Picture position) by just pressing the AUTO SETUP/CANCEL button on the top control or the AUTO SET/CANCEL button... -
Page 26: Sound Adjustment
Sound Adjustment Direct Operation Volume Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute Press the MUTE button on the remote control to temporarily turn off the sound. -
Page 27: Remote Control Operation
Basic Operation Remote Control Operation Using the remote control for some frequently used operations is advisable. Just pressing one of the buttons enables you to make the desired operation quickly without calling up the On-Screen Menu. COMPUTER/VIDEO/NETwORK button Press the COMPUTER, VIDEO, or NETWORK button on the remote control to select the input source. - Page 28 NO SHOw button Press the NO SHOW button on the remote control to black out the image. To restore to normal, press the NO SHOW button again or press any other button. When a projected image is captured and set as “User” in the Logo selection (see page 48), the screen changes each time you press the NO SHOW button as follows.
-
Page 29: Computer Input
Computer Input Input Source Selection (RGB: Computer 1 (Analog)/Computer ) Direct Operation Choose either Computer 1 (Analog) or Computer 2 by pressing the INPUT button on the top control or press the COMPUTER button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below. -
Page 30: Input Source Selection (Rgb(Pc Digital), Rgb(Av Hdcp))
Input Source Selection (RGB(PC digital), RGB(AV HDCP)) Direct Operation Choose Computer 1(Digital) by pressing the INPUT button on the top control or press the COMPUTER button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below. Menu Operation Press the MENU button to display the On-Screen ◄►... -
Page 31: Computer System Selection
Computer Input Computer System Selection This projector automatically tunes to various types of computers based on VGA, SVGA, XGA, SXGA, WXGA, or UXGA with its Multi-scan system and Auto PC Adjustment. If a computer is selected as a signal source, this projector automatically detects the signal format and tunes to project a proper image without any additional settings. -
Page 32: Auto Pc Adjustment
Auto PC Adjustment Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots, Horizontal and Vertical positions to conform to your computer. Direct Operation The Auto PC adjustment function can be operated directly by pressing the AUTO PC button on the remote control. Menu Operation Auto PC Adj . -
Page 33: Manual Pc Adjustment
Computer Input Manual PC Adjustment Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has five independent memory areas to store those parameters manually adjusted. It allows you to recall the setting for a specific computer. - Page 34 Display area H ◄► Use the Point buttons to adjust the horizontal area displayed by this projector. Display area V ◄► Use the Point buttons to adjust the vertical area displayed by this projector. Reset To reset the adjusted data, select Reset and press the SELECT button.
-
Page 35: Image Mode Selection
Computer Input Image Mode Selection Direct Operation Select the desired image mode from among Dynamic, Standard, Real, Blackboard (Green), Image 1, Image 2, Image 3, and Image 4 by pressing the IMAGE button on the remote control. Dynamic For viewing pictures in a bright room. Standard Normal picture mode preset on the projector. -
Page 36: Image Adjustment
Image Adjustment Press the MENU button to display the On-Screen ◄► Menu. Use the Point buttons to move the red frame pointer to the Image Adjust Menu icon. ▲▼ Use the Point buttons to move the red frame pointer to the desired item and then press the SELECT button to display the adjustment dialog box. -
Page 37: Screen Size Adjustment
Computer Input Store To store the adjusted data, select Store and press the SELECT button. Use the Point from Image 1 to 4 and press the SELECT button. A confirmation box appears and then select [Yes]. Stored data can be called up by selecting an “Image (1–4)” in the Image Mode Selection on page 35. -
Page 38: For Zooming In And Out The Images
Custom Adjust the screen scale and position manually with this function. Press the SELECT button at Custom and the “Custom” is displayed on the screen for a few seconds and then the Aspect dialog box appears. Scale H/V ... Adjust the Horizontal/Vertical screen scale. H&V ... -
Page 39: Video Input
Video Input Input Source Selection (Video, S-video) Direct Operation Choose Video by pressing the INPUT button on the top control or the VIDEO button on the remote control. Before using these buttons, correct input source should be selected through menu operation as described below. Menu Operation Press the MENU button to display the On-Screen ◄►... -
Page 40: Input Source Selection (Component, Rgb Scart 21-Pin)
Input Source Selection (Component, RGB Scart 1-pin) Direct Operation Choose Computer 2 by pressing the INPUT button on the top control or press the COMPUTER button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below. Menu Operation Press the MENU button to display the On-Screen ◄►... -
Page 41: Video System Selection
Video Input Video System Selection Press the MENU button to display the On-Screen ◄► Menu. Use the Point frame pointer to the AV System Menu icon. ▲▼ Use the Point buttons to move the red arrow pointer to the desired system and then press the SELECT button. -
Page 42: Image Mode Selection
Image Mode Selection Direct Operation Select the desired image mode from among Dynamic, Standard, Cinema, Blackboard (Green), Image 1, Image 2, Image 3, and Image 4 by pressing the IMAGE button on the remote control. Dynamic For viewing pictures in a bright room. Standard Normal picture mode preset on the projector. -
Page 43: Image Adjustment
Video Input Image Adjustment Press the MENU button to display the On-Screen ◄► Menu. Use the Point buttons to move the red frame pointer to the Image Adjust Menu icon. ▲▼ Use the Point buttons to move the red frame pointer to the desired item and then press the SELECT button to display the adjustment dialog box. - Page 44 Sharpness ◄ Press the Point button to decrease the sharpness of the ► image; press the Point button to increase the sharpness of the image (from 0 to 15). Gamma ◄► Use the Point buttons to adjust the gamma value to obtain a better balance of contrast (from 0 to 15).
-
Page 45: Screen Size Adjustment
Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. Press the MENU button to display the On-Screen ◄► Menu. Use the Point buttons to move the red frame pointer to the Screen Menu icon. ▲▼... -
Page 46: Setting
Setting Setting This projector has a Setting menu that allows you to set up the other various functions described below. Press the MENU button to display the On-Screen ◄► Menu. Use the Point buttons to move the red frame pointer to the Setting Menu icon. ▲▼... - Page 47 Setting Keystone This function is used to store or reset the keystone correction when the AC power cord is unplugged. Use the ▲▼ Point buttons to switch between each option. Store ... Keep the keystone correction even when the AC power cord is unplugged. Reset ...
- Page 48 Logo (Logo and Logo PIN code lock settings) This function allows you to customize the screen logo with Logo select, capture, and Logo PIN code lock functions. Note: • When “On” is selected in the Logo PIN code lock function, Logo select and Capture functions cannot be selected.
- Page 49 Setting Logo PIN code lock This function prevents an unauthorized person from changing the screen logo. Off ... The screen logo can be changed freely from the Logo Menu (p.48). On ... The screen logo cannot be changed without a Logo PIN code. If you want to change the Logo PIN code lock setting, press the SELECT button and the Logo PIN code dialog box appears.
- Page 50 Ceiling When this function is set to “On,” the picture will be top/ bottom and left/right reversed. This function is used to project the image from a ceiling-mounted projector. Rear When this function is set to “On,” the picture will be left/right reversed.
- Page 51 Setting Standby mode This function is available when operating the projector via network. Normal ... Supply the power to the network function even after turning off the projector. You can turn on/ off the projector via network, modify network environment, and receive an e-mail about projector status while the projector is powered off.
- Page 52 On start When this function is set to “On,” the projector will be automatically turned on just by connecting the AC power cord to a wall outlet. Note: • Be sure to turn off the projector properly (see “Turning Off the Projector” on page 22). If the projector is turned off in the incorrect sequence, the On start function does not work properly.
- Page 53 Setting Security (Key lock and PIN code lock) This function allows you to use the Key lock and PIN code lock function to set the security for the projector operation. Key lock This function locks the top control and remote control buttons to prevent operation by unauthorized persons.
-
Page 54: Change The Pin Code
Enter a PIN code ▲▼ Use the Point buttons to enter a number. Press the ► Point button to fix the number and move the red frame pointer to the next box. The number changes to “.” If you fixed an incorrect number, use the Point the pointer to the number you want to correct, and then enter the correct number. - Page 55 Setting This function provides the following options in the cooling fans’ operation when the projector is turned off (p.22). L1 ... Normal operation L2 ... Slower and lower-sound than the normal operation (L1), but it takes more time to cool the projector down.
- Page 56 Filter counter This function is used to set a frequency for the filter cleaning. When the projector reached a specified time between cleanings, a Filter warning icon appears on the screen, notifying the cleaning is necessary. After cleaning the filter, be sure to select RESET and set the timer.
-
Page 57: Maintenance And Cleaning
Maintenance and Cleaning wARNING TEMP . indicator The Warning Temp. indicator shows the state of the function which protects the projector. Check the state of the Warning Temp. indicator and the POWER indicator to take proper maintenance. The projector is shut down and the warning Temp . indicator is blinking red . -
Page 58: Cleaning The Air Filters
Cleaning the Air Filters Filter prevents dust from accumulating on the optical elements inside the projector. Should the air filters become clogged with dust particles, it will reduce cooling fans’ effectiveness and may result in internal heat buildup and adversely affect the life of the projector. If a “Filter warning” icon appears on the screen, clean the air filters immediately. -
Page 59: Attaching The Lens Cap
Maintenance and Cleaning Attaching the Lens Cap When moving this projector or while not using it over an extended period of time, replace the lens cap. Attach the lens cap according to the following procedures. Pass the string through a hole of the lens cap. Turn over the projector . -
Page 60: Lamp Replacement
Do not drop a lamp or touch a glass bulb! The glass can shatter and may cause injury. Lamp Cover Lamp Handle Screw : LC-XB33N : POA-LMP115 (Service Parts No. 610 334 9565) LAMP REPLACE indicator Screw Screw... -
Page 61: Resetting The Lamp Counter
Maintenance and Cleaning Resetting the Lamp Counter Be sure to reset the Lamp counter after the lamp is replaced. When the Lamp counter is reset, the LAMP REPLACE indicator stops lighting and the Lamp replacement icon disappears. Press the MENU button to display the On-Screen ◄►... -
Page 62: Appendix
Appendix Troubleshooting Before calling your dealer or service center for assistance, check the items below once again. – Make sure you have properly connected the projector to peripheral equipment as described on pages 18-20. – Make sure all equipment is connected to AC outlet and the power is turned on. –... - Page 63 Appendix No image No sound The color is strange . Some displays are not seen during the operation . Auto PC adjustment function does not work . The setting does not remain after turning off power . Power management does work .
- Page 64 The image is distorted or runs off . PIN code dialog box appears at start-up . Page Up/Down function does not work . The Remote Control does not work . Indicator blinks or lights . wireless Mouse function does not work . The exclamation mark appears on the screen .
- Page 65 Appendix wARNING : High voltages are used to operate this projector . Do not attempt to open the cabinet . If problems still persist after following all operating instructions, contact the dealer where you purchased the projector or the service center. Specify the model number and explain about the problem. We will advise you how to obtain service.
-
Page 66: Menu Tree
Menu Tree Computer Input/Video Input Input Computer 1 (Analog) Computer 1 (Digital) Computer 2 Video Wired Wireless Sound Sound Volume Mute Quit Computer Input System SVGA 1 Mode 1 Mode 2 - - - - * Systems displayed in the System Menu vary depending on an input signal. - Page 67 Appendix Video Input System System Image Select Dynamic Standard Cinema Blackboard (Green) Image 1 Image 2 Image 3 Image 4 Image Adjust Contrast Brightness Color Tint Color temp. Green Blue Sharpness Gamma Noise reduction Progressive Reset Store Quit Screen Normal Wide Custom Setting...
-
Page 68: Indicators And Projector Condition
Indicators and Projector Condition Check the indicators for projector condition. Indicators WARNING LAMP POWER TEMP. REPLACE red/green yellow • • • green. • • • blinks green. When the projection lamp reaches its end of life, the LAMP REPLACE indicator lights yellow. When this indicator lights yellow, replace the projection lamp with a new one promptly. -
Page 69: Compatible Computer Specifications
Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V-, H-Frequency mentioned below and less than 140 MHz of Dot Clock for analog signal and 110 MHz of Dot Clock for digital signal. When selecting these modes, PC adjustment can be limited. - Page 70 When the input signal is digital from DVI terminal, refer to the chart below. ON-SCREEN H-Freq . RESOLUTION DISPLAy (KHz) D-VGA 640 x 480 31.47 D-480p 640 x 480 31.47 D-575p 768 x 575 31.25 D-SVGA 800 x 600 37.879 D-XGA 1024 x 768 43.363...
-
Page 71: Technical Specifications
Appendix Technical Specifications Mechanical Information Projector Type Dimensions (W x H x D) Net Weight Feet Adjustment Panel Resolution LCD Panel System Panel Resolution Number of Pixels Signal Compatibility Color System High Definition TV Signal Scanning Frequency Optical Information Projection Image Size (Diagonal) Throw Distance Projection Lens Projection Lamp... -
Page 72: Optional Parts
Accessories Owner’s Manual (CD-ROM) Quick Reference Guide AC Power Cord Remote Control and Batteries VGA Cable Control cable Lens Cap with String PIN Code Label Network Application (CD-ROM) ● The specifications are subject to change without notice. ● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels. -
Page 73: Pj Link Notice
Appendix Pj Link Notice This projector is compliant with PJLink Standard Class 1 of JBMIA (Japan Business Machine and Information System Industries Association). This projector supports all commands defined by PJLink Class 1 and is verified conformance with PJLink Standard Class 1. For PJ Link password, see page 49 on the owner’s manual “Network Set-up and Operation.”... -
Page 74: Configurations Of Terminals
Configurations of Terminals COMPUTER IN /COMPONENT IN /MONITOR OUT (ANALOG) Terminal: Analog RGB (Mini D-sub 15 pin) DVI-I TERMINAL (DIGITAL/ANALOG) C1 C2 USB CONNECTOR (Series B) - Data + Data Ground LAN TERMINAL TX + TX – RX + 8 7 6 5 4 3 2 1 SERVICE PORT CONNECTOR Terminal : Mini DIN 8-PIN... -
Page 75: Pin Code Number Memo
Appendix PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No . Logo PIN Code Lock No . -
Page 76: Dimensions
Appendix Dimensions Unit: inch(mm) Screw Holes for Ceiling Mount Screw: M4 Depth: 0.472(12.0) 88.7(3.49) 246.3(9.70) 53.5(2.11) 228(9.0) 90(3.54) 70(2.76) 10°MAX... - Page 77 Tel : 86-21-5396-0088 Fax : 86-21-5396-0318 E-Mail : info@eiki-china.com KD3BC Canada EIKI CANADA - Eiki International, Inc. P.O. Box 156, 310 First St. - Unit 2, Midland, ON, L4R 4K8, Canada Tel : 800-563-3454 (705)-527-4084 Fax : 800-567-4069 (705)-527-4087 E-Mail : canada@eiki.com Eastern Europe EIKI CZECH spol.
