Owner's Manual

Memory Viewer function

This is the manual for the Memory Viewer function.
Read this manual thoroughly to operate the Memory Viewer function.
First, read the owner's manual of the projector to understand the basic operation of the
projector and the safety instructions.
The safety instructions in the owner's manuals should be followed strictly.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-WB40N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eiki LC-WB40N

Summary of Contents for Eiki LC-WB40N

  • Page 1: Memory Viewer Function

    This is the manual for the Memory Viewer function. Read this manual thoroughly to operate the Memory Viewer function. First, read the owner's manual of the projector to understand the basic operation of the projector and the safety instructions. The safety instructions in the owner's manuals should be followed strictly.
  • Page 2 Store images on a dedicated SD memory card and insert it into the SD memory card slot of the projector, then you can project those images. This projector is also equipped with dedicated Network Viewer 4 software to edit the presentation images to project with the Memory Viewer function. With this function, you can edit images, photo data, or Power Point data into a more effective presentation data.

  • Page 3: Sd Memory Card Slot

    The memory card is not provided with this projector. The types of memory card which can be used with the Memory Viewer function of this projector is "SD Memory Card". It may not be used with this projector depending on the type of the SD memory card. A new SD memory card or a card formatted by computer or camera must be formatted by this projector.

  • Page 4: Inserting The Sd Memory Card

    Memory viewer function Inserting the SD memory card Insert the SD memory card into the card slot on the back side of the projector as shown in the figure below. Removing the SD memory card Push the SD memory card in the arrow direction gently to remove. The card comes out and you can remove it.

  • Page 5: Entering The Memory Viewer Mode

    After short time, the network connection standby display screen "Ready for use" will appear. 2. Insert the SD memory card into the card slot on the back side of the projector. The card indicator lights up.

  • Page 6: Displaying The Memory Viewer Browser Window

    * When you set up the custom screen size with the screen setting of the projector, a part of the browser window of the memory viewer may get cut off from the custom screen size. In that case, readjust the custom screen size.

  • Page 7: Menu Tree

    AUTO SETUP/CANCEL button. Note: * The memory viewer does not support the resolution of image more than the panel resolution of the projector. * Text file can be displayed up to 15,000 rows with 110 characters per row. description Mode to select a playing file respectively Available file types are JPEG(.jpg), Bitmap(.bmp), Text(.txt).

  • Page 8: Image Viewer In The Manual Mode

    Memory viewer function Image viewer in the manual mode 1. Select "Manual mode" from "Menu" on the browser window of the memory viewer and press SELECT button. 2. Select a file to display with point buttons and press SELECT button. The selected file image is displayed on the screen.

  • Page 9: Termination Of Memory Viewer

    To terminate the memory viewer function, take one of methods described below. - Terminate with projector's on-screen menu. 1. Select “Wired” or "Wireless" from the input menu of the projector. Press SELECT button. 2. Select "Memory Viewer" with the point ed buttons and press SELECT button. The "Enter/Exit" pallet of the memory viewer appears.
  • Page 10 2. Move the projection data from the computer into the SD memory card. Note: If the network PIN code is set for the projector, the authentication window appears as below. In that case, enter "user" into the User Name column and the network PIN code of the projector into the...

  • Page 11: Formatting The Sd Memory Card

    * The data converted by the Network Viewer 4 [File Converter1] can be stored into the SD memory card mounted on the projector directly. For further information, refer to chapter Network Viewer function, "Setting of output destination and conversion mode" (p.113) described on the separated booklet of Network Owner's manual.
  • Page 12 Fax : 86-21-5396-0318 E-Mail : info@eiki-china.com WorldWide Website http://www.eiki.com MEMORY VIEWER OWNER'S MANUAL Canada EIKI CANADA - Eiki International, Inc. P.O. Box 156, 310 First St. - Unit 2, Midland, ON, L4R 4K8, Canada Tel : 800-563-3454 (705)-527-4084 Fax : 800-567-4069 (705)-527-4087 E-Mail : canada@eiki.com...
