SERVICE MANUAL

Give complete "Chassis No." for parts
order or servicing, it is shown on the
rating sheet on the cabinet on the projector.
For your convenience, all service parts, identified in this manual are available through Eiki's normal distribution chan-
nels. In addition to service part number, the generic descriptions have been given, where possible, to allow your service
technicians to substitute equivalent components which might be available from other sources.
All orders for service parts will be honored. However, in instances where generic components are considered to be
available from several common sources, as would be the case with an industry standard fuse, resistor, or semiconduc-
tor, it may be more economical and expeditious to purchase the part locally.
PrOduCt COde
1 122 388 01
(KG3BC)
1 122 389 01
(LG3BC)
1 122 389 06
(LG3GC)
Multimedia Projector
FOreWOrd
FILE NO.
Model No. LC-XB42
U.S.A, Canada,
Europe, Hong Kong
Original Version
Chassis No. KG3-XB4200
SM
REFERENCE NO.
5110956-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-XB42 and is the answer not in the manual?

Questions and answers

Related Manuals for Eiki LC-XB42

Summary of Contents for Eiki LC-XB42

  • Page 1: Service Manual

    FOreWOrd For your convenience, all service parts, identified in this manual are available through Eiki’s normal distribution chan- nels. In addition to service part number, the generic descriptions have been given, where possible, to allow your service technicians to substitute equivalent components which might be available from other sources.

  • Page 2: Table Of Contents

    Contents SERVICE MANUAL ............1 Scaler I/O Port Functions (PW190) ......59 Contents ................  Waveform ..............60 Safety Instructions ............3 IC Block Diagrams ............61 Safety Precautions ............. 3 Electrical Parts List ............68 Product Safety Notice ..........3 Electrical Parts Location ...........

  • Page 3: Safety Instructions

    Safety Instructions Safety Precautions WARNING: The chassis of this projector is isolated (COLD) from AC line by using the converter transformer. Primary side of the converter and lamp power supply unit circuit is connected to the AC line and it is hot, which hot circuit is identified with the line ( ) in the schematic diagram.

  • Page 4: Specifications

    Specifications Mechanical Information Projector Type Multi-media Projector Dimensions (W x H x D) 334 mm x 78 mm x 257.5mm (Not including protrusion) Net Weight 3.7 kg Feet Adjustment 0˚ to 8.9˚ Panel resolution LCD Panel System 0.8” TFT Active Matrix type, 3 panels Panel Resolution 1,024 x 768 dots Number of Pixels...

  • Page 5: Circuit Protections

    Circuit Protections This projector provides the following circuit protections to operate in safety. If the abnormality occurs inside the pro- jector, it will automatically turn off by operating one of the following protection circuits. Thermal switch There is the thermal switch (SW902) inside of the projector to detect the internal temperature rising abnormally.

  • Page 6: Warning Temperature And Power Failure Protection

    Circuit Protections Warning temperature and power failure protection The projector will be automatically turned off when the internal temperature of the projector is abnormally high, or the cooling fans stop spinning, or the power supplies in the projector are failed. - If the WARNING indicator is flashing, it may detect the abnormal temperature inside the projector.

  • Page 7: Maintenance

    Maintenance Cleaning the Filter Filters prevents dust from accumulating on the optical elements inside the projector. Should the filters become clogged with dust particles, it will reduce cooling fans’ effectiveness and may result in internal heat buildup and adversely affect the life of the projector. If a “Filter warning” icon appears on the screen, clean the filters immediately.

  • Page 8: Lamp Replacement

    Maintenance Lamp Replacement When the projection lamp of the projector reaches its end of life, top Control the Lamp replacement icon appears on the screen and LAMP REPLACE indicator lights yellow. Replace the lamp with a new one promptly. The timing when the LAMP REPLACE indicator LAMP rePLACe should light is depending on the lamp mode.

  • Page 9: Resetting The Lamp Counter

    Maintenance Resetting the Lamp Counter Be sure to reset the Lamp counter after the lamp is replaced. When the Lamp counter is reset, the LAMP RE- PLACE indicator stops lighting and the Lamp replacement icon disappears. Lamp counter Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red framed pointer to the Setting Menu icon.

  • Page 10: Cleaning

    Maintenance Cleaning After long periods of use, dust and other particles will accumulate on the LCD panel, prism, mirror, polarized glass, lens, etc., causing the picture to darken or color to blur. If this occurs, clean the inside of optical unit. Remove dust and other particles using air spray.

  • Page 11: Security Function Notice

    Security Function Notice Security Function Disable This projector provides security functions such as "Key lock", "PIN code lock" and "Logo PIN code lock". When the projector has set these security function on, you are required to enter correct PIN code to use the projector. If you do not know the correct PIN code to the projector, the projector can no longer be operated or started.

  • Page 12: Mechanical Disassembly

    Mechanical Disassembly Mechanical disassembly should be made following procedures in numerical or- Screws Expression der. (Type ) mm Diameter x Length Following steps show the basic procedures, therefore unnecessary step may T type M Type be ignored. Caution: The parts and screws should be placed exactly the same position as the original otherwise it may cause loss of performance and product safety.
  • Page 13 Mechanical Disassembly x Main Board, AV Board, Rear Panel and Fans removal 1. Remove the Main board. 2. Remove the Rear panel. 3. Remove AV board. 4. Remove fans (FN901, FN902). Main board Rear panel (T3x6)(Black)x2 (M2.5x6)x3 AV board (M2.5x6) (T3x6)x2 FN901 FN902...
  • Page 14 Mechanical Disassembly v Optical unit, Temp., Line Filter board,Fans removal 1. Remove the Optical unit. 2. Remove Screw (T3x8) and 4 hooks on the duct and then remove the Duct. 3. Remove the Duct top. 4. Remove the Line filter board and Temp. board. 5.
  • Page 15 Mechanical Disassembly b Power, Ballast, Lamp Cover Sw Board, Thermal Sw(SW902) removal 1. Remove the Power board. 2. Remove the Ballast board. 3. Remove the Lamp cover switch board and thermal switch (SW902). Isolation sheet (2 sheet) (T3x6) Power board (T3x6)x2 Ballast board (T3x8)x2...

  • Page 16: Optical Parts Disassembly

    Optical Parts Disassembly Before taking this procedure, remove Cabinet Top , Cabinet Front and Main Board following to the “Mechanical Dis- assembly”. Disassembly requires a 2.0mm hex wrench. z Projection lens disassembly Note: The optical unit should be removed from the cabinet bottom before removing the projection lens. Optical unit Projection lens (M2.5x8)x4...
  • Page 17 Optical Parts Disassembly c Relay lens disassembly (M2.5x5)x2 Relay lens Ass'y Spring Relay lens Fig.3 v Polarized glass-in disassembly (M2.5x5)x1 Polarized glass-in Ass'y Film sheet Polarized glass Hooks * Mount the polarized glass as the film at- tached side faces the Fig.4 prism side.
  • Page 18 Optical Parts Disassembly b LCD Panel/Prism Ass’y removal LCD Panel/ Prism Ass’y (M2.5x4)x2 (M3x10) (Bottom side) Fig.5-1 IMPOrtANt NOtICe on Lcd Panel/Prism ass'y replacement LCD panels used for this model can not be replaced separately. Do not disassemble the LCD Panel/Prism Ass’y. These LCD panels are installed with precision at the factory.
  • Page 19 Optical Parts Disassembly Panel Type Check There are 2 types of LCD Panel/Prism Ass'y for this model. Either L-Type or R-Type LCD Panel/Prism Ass'y is used on the projector. Check which type of LCD Panel/Prism Ass'y is used with the figure below. When replacing the LCD Panel/Prism Ass'y, you need to take "Panel Type Check and Setting"...

  • Page 20: Optical Unit Top Removal

    Optical Parts Disassembly n Polarized glass, Pre-polarized glass removal * Mount the polarized glasses as the film attached side faces the LCD panel side. (M2x2) (Green) Pre-Polarized Glass(G) Polarized Glass(G) (red) (M2x2) Pre-Polarized Glass(B) Film Polarized Glass(R) Polarized Glass(B) Fig.6 (Blue) m Optical unit top removal 1.

  • Page 21: Locations And Directions

    Optical Parts Disassembly , Locations and Directions Parts Name When mounting or assembling the optical parts in the opti- cal unit, the parts must be mounted in the specified loca- Integrator lens (OUT) tion and direction as shown in figure below. Prism beam splitter (PBS) Condenser lens (OUT) Dichroic mirror (B)

  • Page 22: Adjustments

    Adjustments Adjustments after Parts Replacement : Adjustment necessary : Check necessary ● ❍ Disassembly / Replaced Parts Polarized Glass LCD/ Integrator Relay Power Board Main Board Prism Ass’y Lens (OUT) Lens (OUT) Contrast Adjustment R-Contrast adjustment ● G-Contrast adjustment ● B-Contrast adjustment ●...

  • Page 23: Optical Adjustments

    Optical Adjustments Before taking optical adjustments below, remove the Cabinet Top following to the “Mechanical Disassembly”. Adjustments require a 2.0mm hex wrench and a slot screwdriver. When you adjust Integrator lens or Relay lens adjustment, you need to disconnect FPC cables of LCD panels on the main board. Optical adjustment requires a 2.0mm hex wrench and a slot screwdriver.

  • Page 24: Integrator Lens Adjustment

    Optical Adjustments Integrator lens adjustment Turn the projector on by a state of without FPC cables. Project all of lights on the screen. Adjust the adjustment base of integrator lens assy to make color uniformity in white. 1) If the shading appears on the left or right of the screen as shown White Fig.2-1 , loosen 1 screw...

  • Page 25: Relay Lens-Out Adjustment

    Optical Adjustments Relay lens-Out adjustment Turn the projector on by a state of without FPC cables. Project all of lights on the screen. Adjust the adjustment base of relay lens assy to make color unifor- mity in white. If the shading appears on the left or right of the screen as shown in White Fig.3 , loosen 1 screw...

  • Page 26: Electrical Adjustments

    Electrical Adjustments Service Adjustment Menu Operation to enter the service mode MeNu SeLeCt button To enter the “Service Mode”, press and hold the for more than 3 seconds. The service menu appears on the screen as follows. to adjust service data MeNu button SeLeCt button Select the adjustment group no.

  • Page 27: Circuit Adjustments

    Electrical Adjustments Circuit Adjustments CAUTION: The each circuit has been made by the fine adjustment at factory. Do not attempt to adjust the following adjustments except requiring the readjustments in servicing otherwise it may cause loss of performance and product safety. Before adjustment, please turn on the projector more than ten minutes. WArNING : uSe uV rAdIAtION eYe ANd SKIN PrOteCtION durING SerVICING.
  • Page 28 Electrical Adjustments Gain adjustment [PC] x Panel Type Check and Setting 1. Enter the service mode. * Before setting, you need to check which type of LCD pan- 2. Receive the 16-step grey scale computer signal with Computer2 [RGB] el is placed on the projector according to the item "LCD mode.

  • Page 29: Common Center Adjustment

    Electrical Adjustments Gain adjustment [Component] n Common Center adjustment 1. Enter the service mode. 1. Enter the service mode. 2. Receive the 16-step grey scale computer signal with Computer2 [Component] 2. Receive the 50%-Whole Gray computer signal with mode. TP_G1 Computer2 [RGB] mode.
  • Page 30 Electrical Adjustments . 50% White adjustment [Video] ⁄1 Keystone Offset adjustment 1. Enter the service mode. After replacing the G-sensor circuit (IC3851, IC1802 and 2. Receive the 16-step grey scale composite video signal peripheral circuit), readjust the Keystone Offset adjustment Video[Video] with mode.

  • Page 31: Test Points And Locations

    Electrical Adjustments Test Points and Locations MAIN BOArd -31-...

  • Page 32: Service Adjustment Data Table

    Electrical Adjustments These initial values are the reference data written from the Service Adjustment Data Table CPU ROM to memory IC when replaced new memory IC. The adjustment items indicated with “✻” are required to readjust following to the “Electrical adjustments”. Other items should be used with the initial data value.
  • Page 33 Electrical Adjustments Group/ Item Name Function Initial range Note Item 150 PreCoast YCbCr 480i 0 - 63 151 PostCoast YCbCr 480i 0 - 63 152 PreCoast YCbCr 575i 0 - 63 153 PostCoast YCbCr 575i 0 - 63 154 PreCoast YCbCr 480p 0 - 63 155 PostCoast YCbCr 480p 0 - 63...
  • Page 34 Electrical Adjustments Group/ Item Name Function Initial range Note Item Motion Adaptive Weight <KDEINT> 0 - 255 Value 0 : Conservative <====> 4 : 1 Angle Interpolation Level 0 - 4 Aggressive 2 CUE Low Pass Filter Enable <CUELPFEN> 0 - 1 Group deinterlacer setting Effective only for Progressive ON-L2 mode.
  • Page 35 Electrical Adjustments Group/ Item Name Function Initial range Note Item Film Detection Sensitivity 1 Video Motion Sensitivity 1 - 5 <VOFSTVT> 2 Video Motion Threshold Low <VOFTHRDA> 0 - 32767 Video Motion Threshold <VOFTHRDB> 0 - 32767 High 4 Global Motion Threshold <GMDTHRD>...
  • Page 36 Electrical Adjustments Group/ Item Name Function Initial range Note Item 33 LineR1 0-1023 (MIN<-->MAX Cyclic Operation) 34 LineR2 0-1023 (MIN<-->MAX Cyclic Operation) 35 LineR3 0-1023 (MIN<-->MAX Cyclic Operation) 36 LineR4 0-1023 (MIN<-->MAX Cyclic Operation) 37 LineG0 0-1023 (MIN<-->MAX Cyclic Operation) 38 LineG1 0-1023 (MIN<-->MAX Cyclic Operation)
  • Page 37 Electrical Adjustments Group/ Item Name Function Initial range Note Item 102 FrontCTalkB-End 0-255 103 R-DCOffset-NGain 0-1023 Scan Direction (Front/Rear) 104 R-DCOffset-N1 0-2047 Scan Direction (Front/Rear) 105 R-DCOffset-N2 0-2047 Scan Direction (Front/Rear) 106 R-DCOffset-N3 0-2047 Scan Direction (Front/Rear) 107 R-DCOffset-N4 0-2047 Scan Direction (Front/Rear) 108 R-DCOffset-N5 0-2047...
  • Page 38 Electrical Adjustments Group/ Item Name Function Initial Range Note Item 171 B-DCOffset-P3 0-2047 Scan Direction (Front/Rear) 172 B-DCOffset-P4 0-2047 Scan Direction (Front/Rear) 173 B-DCOffset-P5 0-2047 Scan Direction (Front/Rear) 174 B-DCOffset-P6 0-2047 Scan Direction (Front/Rear) 175 B-DCOffset-P7 0-2047 Scan Direction (Front/Rear) 176 B-DCOffset-P8 0-2047 Scan Direction (Front/Rear)
  • Page 39 Electrical Adjustments Group/ Item Name Function Initial range Note Item 2 B-LCCOM 0-511 3 R-LCCOM-Gain 0-255 4 G-LCCOM-Gain 0-255 5 B-LCCOM-Gain 0-255 6 R-LCCOM-Bright 0-255 7 G-LCCOM-Bright 0-255 8 B-LCCOM-Bright 0-255 9 R-LCCOM-Cent 0-63 10 G-LCCOM-Cent 0-63 11 B-LCCOM-Cent 0-63 12 R-ENBX-PW 0-127 13 G-ENBX-PW...
  • Page 40 Electrical Adjustments Group/ Item Name Function Initial Range Note Item 55 Motor Disable Motors Disable 0 - 1 0: On, 1: Off 56 Menu Position Move menu (X asis) 0 - 1024 57 Menu Position Move menu (Y asis) 0 - 1024 58 Lamp Go Out 0 - 1 59 Souce Search Enable...
  • Page 41 Electrical Adjustments Group/ Item Name Function Initial range Note Item Luminance Level 14 Data for 13 DIMMER_CTRL_LEVEL14 Dimmer: Dim Level 14 at the less 0 - 255 than the Value Luminance Level 15 Data for 14 DIMMER_CTRL_LEVEL15 Dimmer: Dim Level 15 at the less 0 - 255 than the Value Luminance Data Avarage Point for...
  • Page 42 Electrical Adjustments Group/ Item Name Function Initial Range Note Item Temp. A to judge the Temp Error at 10 Temp A Warning (Eco) 30-100 Eco (Room) Temp. B to judge the Temp Error at 11 Temp B Warning (Eco) 30-100 Eco (Panel) Temp.
  • Page 43 Electrical Adjustments Group/ Item Name Function Initial range Note Item 7 Not used 9999 Cooling Time stting at Fan Mode L1 (x 8 Cooling Time L1 30 sec) 1-15 1: 30, 3: 90, 15: 450 sec. Cooling Time stting at Fan Mode L2 (x 9 Cooling Time L2 30 sec) 1-15...
  • Page 44 Electrical Adjustments Group/ Item Name Function Initial range Note Item 7 Image Area V Hight Image Level Acquiring Area Height 0 - 4095 8 Y Target Level Target Value of Y Level Adj. 0 - 255 11 Gain Tolerance Torelance of Level Adj. 0 - 255 12 Delta Gain Deviation Width of Gain Value...
  • Page 45 Electrical Adjustments Group/ Item Name Function Initial range Note Item 1 Disp Dots 0 ~ 4095 2 H Back Porch 0 ~ 4095 3 V Back Porch 0 ~ 4095 4 Disp Line 0 ~ 4095 Group SCArt(480i) 1 Disp Dots 0 ~ 4095 2 H Back Porch 0 ~ 4095...
  • Page 46 Electrical Adjustments Group/ Item Name Function Initial range Note Item 2 H Back Porch 0 ~ 4095 3 V Back Porch 0 ~ 4095 4 Disp Line 1052 0 ~ 4095 Group YCbCr (1035i) 0 Total Dots 2200 0 ~ 4095 * Read only 1 Disp Dots 1872 0 ~ 4095...
  • Page 47 Electrical Adjustments Group/ Item Name Function Initial range Note Item 3 V Back Porch 0 ~ 4095 4 Disp Line 1052 0 ~ 4095 5 Clamp 0 ~ 255 6 Clamp Width 0 ~ 255 Group rGB Video (1080i - 50) 0 Total Dots 2640 0 ~ 4095...

  • Page 48: Chassis Block Diagrams

    Chassis Block Diagrams Chassis over view 127,216 PW_TXD/PW_RXD 124,368 IRRCVR0 331,164 IC5302 BUFFER IC5031 AUDIO OUTPIT IC5201 <LM4889> PC1/PC2-SW <AN5870> IC5001 AUDIO CONTROL <NJW1156> IC4001 BUFFER AUDIO -48-...

  • Page 49: System Control

    Chassis Block Diagrams System control IC891 INVERTER <MH74LVC> IC301 SCALER <PW190> -49-...

  • Page 50: Lamp Control

    Chassis Block Diagrams Lamp control -50-...

  • Page 51: Audio Circuit

    Chassis Block Diagrams Audio circuit -51-...

  • Page 52: Power Supply & Protection Circuit

    Chassis Block Diagrams Power supply & protection circuit IC651 POWER OSC. <STR-Z2156> IC601 P.F.CONTROL <FA5502> BLAST_AC FAN_ERR IC301 SCALER <PW190> -52-...

  • Page 53: Fan Control Circuit

    Chassis Block Diagrams Fan control circuit TPFANA Q7812 FN903 S15.5V FAN_A D3621 D3613 Q7811 FN904 IC7811 D3622 Q7813 FN905 D3623 TPFANB Q7862 FN901 FAN_B D3626 FN902 D3614 Q7861 IC7861 D3627 Q7864 Q3601 P_FAIL P_FAIL P_Fail: H Power Error: On FAN_ERR TPFANC Q7842 FN907...

  • Page 54: Iic Bus Control Circuit

    Chassis Block Diagrams IIC bus control circuit DSub1 DSub2 -54-...

  • Page 55: Troubleshooting

    Troubleshooting Indicators and Projector Condition Check the indicators for projector condition. Indicators Projector Condition LAMP WARNING POWER REPLACE red/green yellow The projector is off. (The AC power cord is unplugged.) The projector is in stand-by mode. Press the POWER ON/STAND- BY button to turn on the projector.

  • Page 56: No Power

    Troubleshooting No Power This projector provides a function which can be specified a defective area simply by indicating the LEDs. Connect the AC cord and press the Power button once and then check the LED indication. - When all of Led indicators are not lighting, the symptom indicates that the primary power supply circuit does not operate properly.

  • Page 57: No Picture

    Troubleshooting No Picture Check following steps. No picture with all of input sources Check signal processing stage and LCD driving stage; Check RGB S&H signals at test points TP_B1, TP_G1, TP_R1. Check power supply circuit 15.5V and peripheral circuit. Check ICs IC501, IC531, IC561, IC2501, IC2531, IC2561, IC401, IC301 and peripheral circuits.

  • Page 58: No Sound

    Troubleshooting No Sound Check following steps. Check if the audio sig- Check IC5001 and peripheral circuit. nal is observed at pins 7 Check 5V_AUDIO, 12V power supply. and 15 of IC5001. Check if the audio sig- Check IC5031, 5V_AUDIO and peripheral circuit. nal is observed at pins 5 Check the Mute signal at pin 1 of IC5031.

  • Page 59: Control Port Functions

    Control Port Functions Scaler I/O Port Functions (PW190) POrt SIGNAL POrt NAMe FuNCtION deSCrIPtION NAMe PORTD7 DDC_SW3 DDC_SW3 DDC_SW3 PORTC5 ON_3.3V 3.3V Power Drive, Power On: H PORTD6 DDC_SW1 DDC_SW1 DDC_SW1 PORTC6 ON_5VA 5VA Drive On/Off, On: H PORTC1 3-Wired Serial Control TXD_PW TXD_PW Serial Control TXD...

  • Page 60: Waveform

    Waveform VIdeO signal <VIdeO> HSYNC signal VSYNC signal HSYNC signal <tPdHS> VSYNC signal <tPdVS> r-S&H signal <tP_r1> G-S&H signal <tP_G1> B-S&H signal <tP_B1> -60-...

  • Page 61: Ic Block Diagrams

    IC Block Diagrams ● AN5870 <Signal Switch, IC5201> ● FA7701<ddC Control, IC5751> -61-...
  • Page 62 IC Block Diagrams ● FA5502 <P.F. Control, IC601> ● FA7711 <DC-DC Converter, IC5801> -62-...
  • Page 63 IC Block Diagrams ● HIN202EIB <RS-232C Driver, IC3801> ● L3E06150 <D/A, S/H-LCD Driver, IC501, IC531, IC561> -63-...
  • Page 64 IC Block Diagrams ● L3E07111 <LCD Driver & Gamma Correction, IC401> ● L3E01060 <Level Shift, IC2501, IC2531, IC2561> -64-...
  • Page 65 IC Block Diagrams ● LM4889 <Audio Output, IC5031> ● NJW1156 <Audio Control, IC5001> -65-...
  • Page 66 IC Block Diagrams ● PW190 <Scaler, IC301> ● Str-Z2156<Power OSC, IC651> -66-...
  • Page 67 IC Block Diagrams ● TE7783 <Parallel I/O Expander, IC1802> -67-...

  • Page 68: Electrical Parts List

    KG3-XB4200 Electrical Parts List Product safety should be considered when a component replacement is made in any area of a projector. Components indicated by a mark in this parts list and the circuit diagram show components whose value have special significance to product safety.

  • Page 69: Electrical Parts Location

    KG3-XB4200 Electrical Parts List Electrical Parts Location ● Assemblied Boards A2900 Temp Board A2000 AV Board A4800 A630 R/C Board Line Filter Board A690 Lamp Cover SW Board A1000 Main Board A901 Ballast Board A600 Power Board ● Out Of Circuit Board LF901 FN903 Noise Filter...

  • Page 70: Electrical Parts List

    KG3-XB4200 Electrical Parts List Electrical Parts List Note: Parts order must contain Chassis No., Part No., and Descriptions. Key No. Part No. description Key No. Part No. description 305 014 4611 TR 2SC2412K T146 S ASSEMBLED BOARD 305 015 8727 TR 2SC2812-L6-TB 305 015 8925 TR 2SC2812-L7-TB...
  • Page 71 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description C661 303 208 1415 TA-SOLID 1U M R681 301 150 5918 MT-GLAZE 10K JA 1/10W 303 411 5712 TA-SOLID 1U M R682 301 256 6215 MT-GLAZE 270 JA 1/10W C662 303 411 1823...
  • Page 72 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description 308 045 4909 DIODE RBV-1506 LF-B 303 276 3113 CERAMIC 33P J DS601 307 219 0808 THYRISTOR TF861S C4833 303 453 8917 CERAMIC 0.1U K 303 453 8610 CERAMIC 0.1U K MISCELLANEOUS...
  • Page 73 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description 305 173 9915 TR 2SC3928A1S 305 015 8727 TR 2SC2812-L6-TB Q3601 305 014 4512 TR 2SC2412K T146 R 305 015 8925 TR 2SC2812-L7-TB 305 014 4611 TR 2SC2412K T146 S 305 163 1615 TR 2SC2812N-L6-TB0...
  • Page 74 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description 305 002 0311 TR 2SA1037K T146 R 305 002 6729 TR 2SA1179-M6-TB 305 002 0410 TR 2SA1037K T146 S 305 002 6927 TR 2SA1179-M7-TB 305 002 6729 TR 2SA1179-M6-TB 305 163 1516 TR 2SA1179N-M6-TB...
  • Page 75 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description IC4011 310 348 7501 IC TC7WT241FU(TE12L) 303 409 3426 CERAMIC 0.1U K IC4891 309 404 7213 IC TC7SET00FU-(TE85L) C2013 403 457 2512 CERAMIC 0.47U K IC5001 409 683 5716 IC NJW1156AV 303 376 6311...
  • Page 76 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description C2571 303 453 8917 CERAMIC 0.1U K C322 303 453 8917 CERAMIC 0.1U K 303 453 8610 CERAMIC 0.1U K 303 453 8610 CERAMIC 0.1U K 303 409 3426 CERAMIC 0.1U K...
  • Page 77 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description 303 409 3426 CERAMIC 0.1U K 303 453 8610 CERAMIC 0.1U K C353 303 453 8917 CERAMIC 0.1U K 303 409 3426 CERAMIC 0.1U K 303 453 8610 CERAMIC 0.1U K C373...
  • Page 78 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description C402 303 453 8917 CERAMIC 0.1U K 303 433 1112 CERAMIC 1U K 303 453 8610 CERAMIC 0.1U K C441 303 391 5511 ELECT 10U M 303 409 3426 CERAMIC 0.1U K...
  • Page 79 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description C508 303 396 9613 CERAMIC 1U K 303 409 3426 CERAMIC 0.1U K 303 397 7618 CERAMIC 1U K C5221 303 454 0613 CERAMIC 0.01U K C5081 303 453 8917 CERAMIC...
  • Page 80 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description 303 397 7618 CERAMIC 1U K C5662 303 453 8917 CERAMIC 0.1U K C540 303 396 9613 CERAMIC 1U K 303 453 8610 CERAMIC 0.1U K 303 397 7618 CERAMIC 1U K...
  • Page 81 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description C5844 303 454 1016 CERAMIC 8200P K C891 303 453 8917 CERAMIC 0.1U K 303 306 6510 CERAMIC 8200P K 303 453 8610 CERAMIC 0.1U K C5861 403 455 1012 CERAMIC...
  • Page 82 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description R2000 301 150 6014 MT-GLAZE 0.000 ZA 1/10W R304 301 224 9316 MT-GLAZE 1K JA 1/16W R2002 301 225 1418 MT-GLAZE 47K JA 1/16W R306 301 224 9712 MT-GLAZE 22 JA 1/16W R2003...
  • Page 83 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description R4031 301 225 8110 MT-GLAZE 10 JA 1/16W R5207 301 225 8110 MT-GLAZE 10 JA 1/16W R4032 301 225 8110 MT-GLAZE 10 JA 1/16W R5208 301 224 8814 MT-GLAZE 100 JA 1/16W R406...
  • Page 84 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description R570 301 294 3115 MT-GLAZE 1K FA 1/16W R6857 301 225 1616 MT-GLAZE 390 JA 1/16W R5701 301 294 3016 MT-GLAZE 10K FA 1/16W R6858 301 225 1616 MT-GLAZE 390 JA 1/16W R5702...
  • Page 85 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description R8812 301 225 8110 MT-GLAZE 10 JA 1/16W L2501 945 041 1978 INDUCTOR,330 OHM R8821 301 225 8110 MT-GLAZE 10 JA 1/16W L2502 945 041 1978 INDUCTOR,330 OHM R8822 301 225 8110...
  • Page 86 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description D5201 307 210 5416 DIODE RB551V-30-TE-17 L8079 945 041 1978 INDUCTOR,330 OHM D5202 307 210 5416 DIODE RB551V-30-TE-17 L8801 945 086 5368 IMPEDANCE,220 OHM P D5203 307 210 5416 DIODE RB551V-30-TE-17 L8802...
  • Page 87 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description SC1023 945 076 3503 SURGE-ABSORBER R2061 301 255 6513 MT-GLAZE 100 JA 1/10W SC1031 945 076 3503 SURGE-ABSORBER R2062 301 255 6513 MT-GLAZE 100 JA 1/10W SC1032 945 076 3503 SURGE-ABSORBER...
  • Page 88 KG3-XB4200 Electrical Parts List Key No. Part No. description Key No. Part No. description 945 054 1156 CORD,POWER-3.0MK 945 054 1149 CORD,POWER-3.138MK MISCELLANEOUS 610 336 8405 CARRY BAG-KB3AC 945 039 7210 CABLE,MOUSE SRAL 945 073 4855 CABLE,INTERFACE VGA 645 093 1642 CABLE,INTERFACE VGA 655 002 1205 POLYE BAG-KB3AC...

  • Page 89: Mechanical Parts List

    KG3-XB4200 Mechanical Parts List Cabinet Parts Location -89-...

  • Page 90: Optical Parts Location

    KG3-XB4200 Mechanical Parts List Optical Parts Location Integrator Lens-In (Integrator-In) Relay Lens-Out (Relay-out) -90-...
  • Page 91 KG3-XB4200 Mechanical Parts List Polarized Glass-In (Polarized-in-R) (Polarized-in-G) (Polarized-in-B) Projection Lens (Projection) -91-...
  • Page 92 KG3-XB4200 Mechanical Parts List Prism/LCD Panel Assy (Green) L02-4 L02-2 (Red) L02-5 L02-1 L02-3 (Blue) (Prism/LCD panel Ass'y) -92-...
  • Page 93 KG3-XB4200 Mechanical Parts List In the Optical Unit -93-...

  • Page 94: Mechanical Parts List

    910 302 5613 DEC SHEET-M4JA 610 333 9290 FILTER BASE-KM6AC 610 333 8699 GRILLE-KM6BC 610 336 2243 BADGE EIKI-KB3BC 610 336 2465 DEC INLAY LED FR-KB3AC CHASSIS PARTS 610 339 4480 DEC AV SHEET KG3BC 610 334 4348 HOLDER POWER PWB BTM-KM6AC...
  • Page 96 A-key to better communications © 2008 Eiki Internatinal Inc, (KG3BC) April. 2008 Japan...

  • Page 97: Diagrams & Drawings

    LC-XB42 KG3-XB4200 these schematic diagrams and printed wiring board drawings are part of the service manual original for chassis No. KG3-XB4200, model LC-XB42. File with the service manual No. SM5110956-00 Note: All the information of part numbers and values indicated on these diagrams are at the beginning of production.

  • Page 98: Parts Description And Reading In Schematic Diagram

    KG3-XB4200 Parts description and reading in schematic diagram 1. The parts specification of resistors, capacitors and resistor reading coils are expressed in designated code. Please check Example 1/2 D J 10K B the parts description by the following code table. 2.
  • Page 99 KG3-XB4200 Pin description of diode, transistor and IC ● diode ● transistor/Fet ● IC...

  • Page 100: Note On Soldering

    Note on Soldering do not use solder containing lead. Solder This product has been manufactured using lead-free Use solder with the metal content and composition ratio solder in order to help preserve the environment. by weight given in the table below. Do not use solders Because of this, be sure to use lead-free solder which do not meet these conditions.
  • Page 101 PROJECTION LENS Schematic Diagrams POWER LAMP LP900 BALLAST SW902 PTH651 PTH652 POWER FACTOR CORRECTION S10B5540N DHXAVB026G C650 R650 K6AC (TERMOSTAT_SW) 1/10GJ (T601,Q601,Q602,D604,IC601) 25KK J10EM024N 9.1KC 0.1GQ Q652 K6AC_1A K6AC_1B METAL Q651 D654 FB601 R647 HALIDE LAMP Z20051--- 1/10GJ T651 K6AC_2A K6AC_2B R648 68KC...
  • Page 102 R8101 1/16GJ4.7KA R8102 1/16GJ4.7KA EDID for R8103 1/16GZ0A DVI-HDCP Signal R8104 1/16GZ0A C8101 16KK0.1MN ;16KK0.1AYH IC8101 ;16KK0.1AXH 24LCSS22A/SNP R8134 1/16GZ0A SCL2_5V R8133 1/16GZ0A SDA2_5V R8131 1/16GZ0A DVI_SDA R8132 1/16GZ0A C8106 16KK0.1MN DVI_SCL ;16KK0.1AYH ;16KK0.1AXH D8161 R8106 1/16GZ0A RB521S-30G 1/16GJ10KA R8130 D8163 02DZ6.2YG 5VDVI...
  • Page 103 IC9883 TC7SZ125FUK R410 1/16GZ0A R426 1/16GJ10KA TO IC561 (S&H) R427 1/16GZ0A RESET R G B COMMON C428 16KK0.1MN :16KK0.1AYH :16KK0.1AXH R424 1/16GJ4.7KA R430 R411 SRCS RB437 SHCLKR1 R1JA4704G SRDATA R409 R404 R472 IRM_RST C425 R406 1/16GZ0A SDATA SDATA_PW R407 1/16GZ0A SCLK FROM IC301 P3 SCLK_PW...
  • Page 104 FRPR FROM IC401 SHCLKR XFRR IC501 3.3V R591 PQ20WZ11P FROM IC301 DIRXR C585 R593 R592 C586 1/16GZ0A P_FAIL D5704 D5703 L561 C5705 1SS355 1SS355 L3530 L26B3470G L26B3470G 25EM471X :1SS352G :1SS352G 15V_PNL 3.3V S15.5V NT15.5V 15V_PNL TP-R1 C5704 R5701 C579 25KK11D 1/16GF10KA C584 16KK0.1MN...
  • Page 105 FAN_B Q6846 FAN_C FAN_A S5V_LED R6863 D6831 LAMP REPLACE(Y) 1/16GJ D6832 TEMP WARNING(R) 1.5KA EXHAUST INTAKE D6833 STAND-BY (RED ON) EXHAUST R6864 LAMP ON (GREEN ON) B_PANEL G_PANEL R_PANEL 1/16GJ LAMP POWER LAMP 4.7KA D6834 MCI FN903 FN904 FN904 S1.8VPW FN901 FN902 FN907...
  • Page 106 16KK0.1MN R357 R358 ;16KK0.1AYH SDATA_PW R1351 R1352 TO GAMMA,S/H SCS_PW 1/16GJ10KA 1/16GJ10KA R1354 R1353 1/16GJ3.3KA 1/16GJ3.3KA SCL2_5V TO HDCP-ANALOG DDC %%oOE2 SDA2_5V C1351 %%oOE1 16KK0.1MN ;16KK0.1AYH ;16KK0.1AXH DCLK DB[0-9] DG[0-9] DR[0-9] C3853 16KK0.47GQ ;16KK0.47LBYA R3853 1/10GJ270C IC891 R321 R322 HD74LVC14T 1/16GJ3.3KA 1/16GJ3.3KA SDA0_33V...
  • Page 107 Printed Wiring Board Diagrams ! CAUTION LINE FILTER (SIDE:B) LINE FILTER ( SIDE:A) This projector is isolated from AC line by using the internal converter transformer. Please pay attention to the following notes in servicing 1. D o not touch the part on hot side (primary circuit) or both parts on hot and cold sides (secondary circuit) at the same time. F601 2. Do not shorten the circuit between hot and cold sides. 1AA4B10C5890B_X B SIDE F601A F601A F601B F601B A SIDE LF901 3. T he grounding lead must be connected to the ground of the same circuit when measur- TYPE215008 T8AH250V ing of voltages and waveforms.
  • Page 108 MAIN (SIDE:A) TEMP. “K48E” 1LG4B10W0140A_ A FB3623 IC9882 A SIDE(1st Reflow) L3633 R5622 L3634 A30C5 FN905 R4836 C5619 C4808 TWAR_LED D3623 L3624 R5626 TP8106 TREP_LED FB2891 R2891 TP8107 R3622 D6831 FN904 D3622 L3626 Q6846 D6832 FB3621 FN902 FB3626 C401 C424 Q7812 R3627 C426 C402...
  • Page 109 MAIN (SIDE:B) POWER LAMP BALLAST “K6R” UNIT L4801 R4803 R4802 D3624 A30C5 C5842 C5617 L5841 C5618 PB11 FB609 R5841 FB3624 C5867 IC5801 C2892 R5812 C5602 C5705 Q5841 L2892 C5811 R/CS C2891 L5861 R5811 C5862 C5809 IC401 D2891 R2892 R5601 “K29D” R419 L3636 C5866 RB432...
  • Page 110 POWER (SIDE:A) POWER (SIDE:B) C611 C685 C681 C683 R684 C683 C691 C611 C685 L616 L611 1AA4B10C5890A L614 T601 R679 D681 D682 B SIDE D682 D681 FB601 L603 L603 FB601 MAIN A30C5 PC602 R648 R650 “K8R” Q602 Q601 D604 D604 Q601 Q602 D654 R674...
