Intel Desktop Boards D850MD and D850MV Product Guide

Add-In Card and Peripheral Interface Connectors

Figure 25 shows the add-in card and peripheral interface connectors for the D850MD board.
A
Figure 25. D850MD Board Add-in Card and Peripheral Interface Connectors
70
B C D
2
1
2
1
H
Item Description
A CNR (optional)
B PCI bus connector 3
C PCI bus connector 2
D PCI bus connector 1
E
40
39
40
2
1
39
G F
Item Description
E AGP
F Diskette drive
G Primary IDE
H Secondary IDE
34
33
OM11840
