Extended Configuration Submenu

Maintenance
Extended Configuration
The submenu shown in Table 9 is used to set system control and video memory cache mode. This
submenu becomes available when User Defined is selected under Extended Configuration.
Table 9.

Extended Configuration Submenu

Feature
Extended Configuration
Video Memory Cache Mode
Main Advanced
Options Description
• Default
User-Defined allows setting memory control and video
(default) memory cache mode. If selected here, will also display in
the Advanced Menu as "Extended Menu: Used."
• User-Defined
• USWC
Selects Uncacheable Speculative Write-Combining
(USWC) video memory cache mode. Full 32 byte contents
of the Write Combining buffer are written to memory as
required. Cache lookups are not performed. Both the
video driver and the application must support Write
Combining.
Selects Uncacheable (UC) video memory cache mode.
• UC (default)
This setting identifies the video memory range as
uncacheable by the processor. Memory writes are
performed in program order. Cache lookups are not
performed. Well suited for applications not supporting
Write Combining.
