Table 14. Peripheral Configuration Submenu (continued)
Feature
Parallel port
Mode
Base I/O address
(This feature is displayed
only if Parallel Port is set
to Enabled.)
Interrupt
(This feature is displayed
only if Parallel Port is set
to Enabled.)
Audio Device
LAN Device
Legacy USB Support
Options Description
• Disabled
Configures the parallel port.
• Enabled
Auto assigns LPT1 the address 378h and the interrupt
IRQ7.
• Auto (default)
An * (asterisk) displayed next to an address indicates a
conflict with another device.
• Output Only
Selects the mode for the parallel port. Not available if the
parallel port is disabled.
• Bi-directional
(default) Output Only operates in AT
• EPP
Bi-directional operates in PS/2-compatible mode.
• ECP
EPP is Extended Parallel Port mode, a high-speed
bi-directional mode.
ECP is Enhanced Capabilities Port mode, a high-speed
bi-directional mode.
• 378 (default)
Specifies the base I/O address for the parallel port.
• 278
• IRQ 5
Specifies the interrupt for the parallel port.
• IRQ 7 (default)
• Disabled
Enables or disables the onboard audio subsystem.
• Enabled (default)
• Disabled
Enables or disables the LAN device.
• Enabled (default)
• Disabled
Enables or disables USB legacy support.
• Enabled (default)
Using the Setup Program
†
-compatible mode.
