Hunter 23947 Parts Manual

Hardware
(Drawn to Scale)
x 1
x 2
x 4
x 2
x 3
x 4
x 1
Kit de
x 1
equilibrado
Empalme
x 4
plástico
Low Profile
Washer
3" Wood Screw
Hanger
Flat Washer
Bracket
Assembly
1.5" Wood Screw
Low Profile
Screw
Canopy Screw
Set Screw
Blade
Assembly
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all
parts are included in the box.
If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model # 23948

Parts List

Asm. Dwg. # 98085-01
Finish White
Item Name Qnty Part #
* Hanging System Kit 1 96970-03
Ceiling Plate
Canopy
Canopy Trim Ring
Hanger Ball / Downrod Assembly
Setscrew
Low Profile Washer
Canopy Screw
Wood Screw 1.5"
Wood Screw 3"
Flat Washer
Mounting Isolator
* Screw, Low Profile
Blade Set 1 G0253-11
Blade Iron Set 1 76267-05
Switch Housing Assembly 1 99808-03
Hardware Kit 1 98085-00-860 98085-00-861
Wire Connector
Screw, Switch Housing Assembly
Balancing Kit 1 07570-01
Hunter Fan Company • 7130 Goodlett Farms Pkwy. #400 • Memphis, TN 38016 • www.hunterfan.com • 98000-01-831 02-02-2010 •
23947
98085-02
New Bronze
Part #
96970-30
G0253-12
76267-05
99808-30
07570-01
2010
©
